Home > Metallurgy, Mineral & Energy > Steel & Products > Stainless Steel > Large Caliber Uns N08904/ASTM A269/1.4529 Stainless Steel Pipe for Paper Processing 904L Steel Tube
Large Caliber Uns N08904/ASTM A269/1.4529 Stainless Steel Pipe for Paper Processing 904L Steel Tube
US$ 45 - 50
MOQ: 100 Kilograms
Key Specifications
Get Latest Price
Type:
Stainless Steel Pipes
Certification:
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other
Shape:
Round
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
8 days
Related Products
-
Stock ASTM A269 /Uns N08904/ASTM A213 Stainless Steel Tube for Paper Processing AISI 904L PipeUS$ 45 - 50MOQ: 100 Kilograms -
1.4539 N08904 ASTM A240 904L Steel PipeUS$ 1500 - 3000MOQ: 1 Ton
-
Supply 201 304 316 Stainless Steel Pipe Manufacturers 90mm Diameter 6m Length Stainless Steel PipeUS$ 800 - 1100MOQ: 1 Ton
-
China Brand ASTM A240 904L /1.4539/N08904 Seamless Steel Tube for Boiler TubeUS$ 12000 - 50000MOQ: 1 Ton
-
Spot Supply of 304 316 316L Welded Pipe Price Concessions Can Be Talked About Seamless Stainless Steel PipeUS$ 800 - 1100MOQ: 1 Ton
Type
Stainless Steel Pipes
Certification
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other
Shape
Round
Grade
Other
Technique
Other
Surface Treatment
Polished
Standard
ASTM, AISI, GB, JIS, DIN, EN, Other
Specification
OEM
Trademark
ZHONGZHENG INTERNATIONAL
Origin
China
Basic Info.
Type
Seamless
Technique
Cold Rolled
Material
Stainless Steel
Key Words
904L Tube
Thickness
0.3 -45mm
Outside Diameter
6.0 - 2800mm
Length
as Your Requirments
Diameter Tolerance
H9, H11, H13, K9, K11, K13 etc
Sample
Free-Sample
Surface
Lack, Peeled, Polishing, Bright, Sand Blast, Hl
MOQ
100kgs
Stock
in Stock
Transport Package
Wooden Package
Specification
904L pipe
Trademark
ZHONGZHENG
Origin
China
HS Code
7505120000
Production Capacity
50000kg/Month
Introduction
ZHEJIANG ZHONGZHENG STAINLESS STEE MANUFACTURING CO. LTD. iis a special stainless steel manufacturer with 20 years of manufacturing experience.
15-7PH is a chromium-nickel-molybdenum-aluminium, semi-austenitic precipitation-hardening stainless steel used for applications requiring moderate corrosion resistance and high strength. The alloy is weldable by conventional methods, although the material has less superior weldability when compared to other PH steels, such as 17-4PH, due to the amount of aluminium included in the alloying process. The product retains its excellent mechanical properties up to temperatures of 482°C (900°F). 15-7PH is easily formed in the annealed condition and offers minimum distortion after heat treatment.
Duplex Stainless 904L Applications
▪ Wiring in electrostatic precipitators
▪ Oil refinery components
▪ Seawater cooling devices
▪ Gas scrubbing plants
▪ Pulp and paper processing industries
▪ Acetic, phosphoric and sulphuric acid proc
Possible Alternative Grades
| Grade | Reasons for choosing grade 904L |
| 316L | A lower cost alternative, but with much lower corrosion resistance. |
| 6Mo | A higher resistance to pitting and crevice corrosion is needed. |
| 2205 | A very similar corrosion resistance, with the 2205 having higher mechanical strength, and at a lower cost to 904L. (2205 not suitable for temperatures above 300°C.) |
| Super duplex | Higher corrosion resistance is needed, together with a higher strength than 904L. |
904L Pipe Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu | |
| 904L | max. | 0.02 | 2 | 1 | 0.045 | 0.035 | 19-23 | 4-5 | 23-28 | 1-2 |
904L Duplex Stainless Sheet Pipe Mechanical Properties
Available Sizes And Specifications
| Tensile strength Rm | 650 - 850 MPa |
| Yield point Rp0.2 | ≥ 300 MPa |
| Hardness | ≤ 260 HB |
| Elongation | ≥ 35% |
| Modulus of elasticity, E | 195 GPa |
| Density | 8.10 kg/dm³ |
| Annealing | 1050 - 1150ºC |
Available Sizes And Specifications
| 904L stainless steel pipe sizes and specifications | |
| Grade | 904L |
| Stainless steel seamless pipe | Outside diameter: 4.0 - 1219mm, Thickness: 0.5 -100mm, Length: 24000mm |
| Stainless steel welded pipe | Outside diameter: 6.0 - 2800mm, Thickness: 0.3 -45mm, Length: 18000mm |
| Stainless steel capillary pipe | Outside diameter: 0.4 - 16.0mm, Thickness: 0.1 -2.0mm, Length: 18000mm |
| Stainless steel welded sanitary pipe | Outside diameter:8.0- 850mm, Thickness: 1.0 -6.0mm |
| Stainless steel seamless sanitary pipe | Outside diameter: 6.0- 219mm, Thickness: 1.0 -6.0mm |
| Stainless steel square pipe | Side Length: 4*4 - 300*300mm, Thickness: 0.25 - 8.0mm, Length: 18000mm |
| Stainless steel rectangular pipe | Side Length: 4*6 - 200*400mm, Thickness: 0.25 - 8.0mm, Length: 18000mm |
| Stainless steel coil pipe | Outside diameter: 0.4 - 16mm, Thickness: 0.1 - 2.11mm |
| Standard | American Standard: ASTM A312, ASME SA269, ASTM A269, ASME SA213, ASTM A213 ASTM A511 ASTM A789, ASTM A790, ASTM A376, ASME SA335, B161, SB163, SB338, SB667/668 Germany Standard: DIN2462.1-1981, DIN17456-85, DIN17458-85· European Standard: EN10216-5, EN10216-2 Japanese Standard: JIS G3463-2006, JISG3459-2012 Russian Standard: GOST 9941-81 |
