ASTM A693/Uns N08904/ASTM A312 Steel Tube for Aerospace Components 15-7pH Stainless Steel Pipe
US$ 35 - 50
MOQ: 100 Kilograms
Key Specifications
Get Latest Price
Type:
Stainless Steel Pipes
Certification:
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other
Shape:
Round
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
8 days
Related Products
-
Uns N08904/ASTM A312 Stainless Steel Pipe for Oil Refinery Components 904L Austenitic Steel TubeNegotiableMOQ: 100 Kilograms -
Uns N08904/ASTM A312 Stainless Steel Pipe for Oil Refinery Components 904L Austenitic Steel TubeUS$ 35 - 50MOQ: 100 Kilograms
-
From China Factory Supply Ss 301 304 316 321 Welded Pipe Seamless Stainless Steel PipeUS$ 800 - 1100MOQ: 1 Ton
-
Industrial ASTM A312 A213 TP304 316 316L 310S 321 No. 1 Finish Stainless Steel PipeUS$ 1500MOQ: 1 Ton
-
Large Caliber Uns N08904/ASTM A269/1.4529 Stainless Steel Pipe for Paper Processing 904L Steel TubeUS$ 45 - 50MOQ: 100 Kilograms
Type
Stainless Steel Pipes
Certification
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other
Shape
Round
Grade
Other
Technique
Other
Surface Treatment
Polished
Standard
ASTM, AISI, GB, JIS, DIN, EN, Other
Specification
OEM
Trademark
ZHONGZHENG INTERNATIONAL
Origin
China
Basic Info.
Grade
15-7pH
Certification
ISO, AISI, ASTM, GB
Shape
Round
Technique
Cold Rolled
Surface Treatment
Pickling
Key Words
15-7pH Pipe/Tube
Thickness
2mm - 100mm
Outside Diameter
4mm - 1219 mm
Length
as Your Requirments
Diameter Tolerance
H9, H11, H13, K9, K11, K13 etc
Sample
Free-Sample
Surface
Lack, Peeled, Polishing, Bright, Sand Blast, Hl
MOQ
100kgs
Stock
in Stock
Transport Package
Wooden Package
Specification
15-7PH
Trademark
ZHONGZHENG
Origin
China
HS Code
7219350000
Production Capacity
50000kg/Month
Introduction
ZHEJIANG ZHONGZHENG STAINLESS STEE MANUFACTURING CO. LTD. iis a special stainless steel manufacturer with 20 years of manufacturing experience.
15-7PH is a chromium-nickel-molybdenum-aluminium, semi-austenitic precipitation-hardening stainless steel used for applications requiring moderate corrosion resistance and high strength. The alloy is weldable by conventional methods, although the material has less superior weldability when compared to other PH steels, such as 17-4PH, due to the amount of aluminium included in the alloying process. The product retains its excellent mechanical properties up to temperatures of 482°C (900°F). 15-7PH is easily formed in the annealed condition and offers minimum distortion after heat treatment.
600 Series Stainless 15-7PH Applications
Grade 15-7 stainless steel is used in the following applications:
Diaphragms
Welded and brazed honeycomb panels
Retaining rings
Aircraft bulkheads
Springs
Other applications requiring high strength at elevated temperatures
Weldability
Grade 15-7 stainless steel can be welded using common arc and resistance methods. Inert gas shielding is avoided in order to prevent oxidation of aluminum.
Annealing
Grade 15-7 stainless steel is annealed at 1038°C (1900°F) followed by cooling rapidly.
Machinability
Grade 15-7 stainless steel has good machinability in the hardened condition.
Cold Working
Grade 15-7 stainless steel is limited to cold working.
Hot Working
Grade 15-7 stainless steel has good hot working capacity. This process should be followed by annealing in order to respond heat treatment.
Grade 15-7 stainless steel can be welded using common arc and resistance methods. Inert gas shielding is avoided in order to prevent oxidation of aluminum.
Annealing
Grade 15-7 stainless steel is annealed at 1038°C (1900°F) followed by cooling rapidly.
Machinability
Grade 15-7 stainless steel has good machinability in the hardened condition.
Cold Working
Grade 15-7 stainless steel is limited to cold working.
Hot Working
Grade 15-7 stainless steel has good hot working capacity. This process should be followed by annealing in order to respond heat treatment.
15-7ph (632) Chemical Composition
| Standard | Chemical composition % | ||||||||||
| C: | Si: | Mn: | P: | S: | Cr: | Mo: | Al: | Ni: | |||
| EN | 1.4532 - X8CrNiMoAl15-7-2 | ||||||||||
| 14.0-16.0 | 2.0-3.0 | 0.7-1.50 | 6.50-7.80 | ||||||||
| NF | Z10CNDA15-07 | ||||||||||
| 14.0-16.0 | 2.0-3.0 | 0.75-1.50 | 6.50-7.75 | ||||||||
| NF | Z9CNDA15-07 | ||||||||||
| 14.0-16.0 | 2.0-3.0 | 0.75-1.50 | 6.50-7.75 | ||||||||
| LW | 1.4574 | ||||||||||
| 14.0-16.0 | 2.0-3.0 | 0.75-1.50 | 6.50-7.75 | ||||||||
| ASTM | 15-7PH / PH15-7Mo - AISI 632 - UNS S15700 | ||||||||||
| 14.0-16.0 | 2.0-3.0 | 0.75-1.50 | 6.50-7.70 | ||||||||
17-7PH Mechanical Properties
| Properties | Metric | Imperial |
| Tensile strength | 1275 MPa | 184900 psi |
| Yield strength | 1030 MPa | 149000 psi |
| Fracture toughness (longitudinal, 44 HRC) | 76 MPa-m½ | 69.2 ksi-in½ |
| Elastic modulus | 204 GPa | 29588 ksi |
| Poisson's ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break | 6% | 6% |
| Reduction of area | 10% | 10% |
| Hardness, Rockwell C | 41 | 41 |
Product advantages
- Minimum distortion on heat treatment
- Good corrosion resistance
- High strength
- Easy formed once annealed
- Minimum distortion on heat treatment
- Good corrosion resistance
- High strength
- Easy formed once annealed
Available Sizes And Specifications
| 632 stainless steel plate sizes and specifications | |
| Grade | 632 |
| Stainless steel seamless pipe | Outside diameter: 4.0 - 1219mm, Thickness: 0.5 -100mm,Length: 24000mm |
| Stainless steel welded pipe | Outside diameter: 6.0 - 2800mm, Thickness: 0.3 -45mm,Length: 18000mm |
| Stainless steel capillary pipe | Outside diameter: 0.4 - 16.0mm, Thickness: 0.1 -2.0mm,Length: 18000mm |
| Stainless steel seamless sanitary pipe | Outside diameter: 6.0- 219mm, Thickness: 1.0 -6.0mm |
| Stainless steel square pipe | Side Length: 4*4 - 300*300mm, Thickness: 0.25 - 8.0mm, Length: 18000mm |
| Stainless steel rectangular pipe | Side Length: 4*6 - 200*400mm, Thickness: 0.25 - 8.0mm, Length: 18000mm |
| Stainless steel coil pipe | Outside diameter: 0.4 - 16mm, Thickness: 0.1 - 2.11mm |
| Standard | American Standard: ASTM A312, ASME SA269, ASTM A269, ASME SA213, ASTM A213 ASTM A511 ASTM A789, ASTM A790, ASTM A376, ASME SA335, B161, SB163, SB338, SB667/668 Germany Standard: DIN2462.1-1981, DIN17456-85, DIN17458-85· European Standard: EN10216-5, EN10216-2 Japanese Standard: JIS G3463-2006, JISG3459-2012 Russian Standard: GOST 9941-81 |
