Ventura AERO M3-44-8 P/N 32845-001 Main Battery 32248-001 Aviation Equipment

　　Battery 32845-001

　　Part#32845-001

　　Manufacturer VENTURA

　　M3-44-8 44 Ah MicroMaintenance Battery

　　The model M3-44-8(P/N 32845-001)is a 19-cell Micro-Maintenance battery,with a nominal voltage of 24V,and a nominal capacity of 44Ah,at a weight of only 81 lbs.(max).The M3-44-8 will provide an Imp(15-second discharge maximum power transfer)of 1335 amps at room temperature.Current EMB-145 operators are at extended battery maintenance intervals of 2,000 Flight Hours.

　　SKU:32845-001

　　Categories:44 Ah Aircraft Batteries,MicroMaintenance Aircraft Batteries

　　Tags:44 Ah,aircraft battery,Batteries,Embraer,MicroMaintenance

　　Features

　　Specifications

　　Documents

　　The M3-2-44-8 is currently on the Embraer 145 Fleet AIPC(Aircraft Illustrated Parts Catalogue)which includes EMB-135,EMB-140 and EMB-145.

　　The M3-2-44-8 is designed as a low-maintenance replacement for our 44Ah BTSP-4445L batteries.

　　Ventura is the leader in Aerospace and Defense aircraft battery solutions,providing innovative,reliable,and high-performance power.Designed with advanced technology,each aircraft battery ensures exceptional durability,reduced maintenance,and optimal performance in all conditions.Trust Ventura aircraft battery products for unmatched dependability and value.

　　17 Ah 25 Ah 33 Ah 44 Ah Actuator Airbus aircraft battery Aircraft folding struts ATR 42 Series ATR 72 Series Augusta Westland Batteries Beech Beechcraft Bell Boeing Bombardier CASP 1200H CASP 2000 CASP2500H cessna charger/analyzer Chargers Christie CTC-500 GPU Ground Power Unit Helicopter Hold Open Rod Honeywell McDonnell Douglass Mechanical Products MicroMaintenance mini charger mustang Norco Power Supplies Remote Release System RF80 Saab Strut SuperPower Support Tensol Lock Trickle Chargers

　　Ventura®32845-001 Ni-Cad Battery,M3-44-8

　　Ventura

　　Part#32845-001=2H Mfr.Part#32845-001

　　Ventura 32845-001 battery incorporates a state-of-the-art negative pasted electrode that provides high volumetric and gravimetric energy density.This,along with the standard sintered positive electrode,provides a high-capacity battery with excellent power.Other characteristics of the battery include our standard,internally threaded butt terminals,long life separators,nylon cell cases and covers.The design of the battery increases the electrolyte reserve to more than two times the standard nickel cadmium battery.The M3 32845-001 battery was designed to increase the battery maintenance interval.This design has reduced electrolyte consumption,coupled with an increased electrolyte reserve,results in an increased maintenance interval of two to six times.

　　FEATURES

　　•Compact design with high performance

　　•Quick and easy installation

　　•Increased capacity and power

　　BENEFITS

　　•Significantly increased maintenance intervals

　　•Very low water consumption

　　•Excellent capacity retention during extended cycling

　　•Durable and steady performance

　　•Enhanced safety

　　SPECIFICATIONS

　　•Series:M3-44-8

　　•Battery Type:Nickel Cadmium

　　•Battery Capacity:44 Ah

　　•Voltage Rating:24 V

　　•Length:15.66 in

　　•Width:6-1/2 in

　　•Height:10-1/8 in

　　•Number of Cells:19

　　•Maximum Discharge Current:1335 A

　　•Connector Type:MS-3509

　　•Suitable For Use With:Embraer 145 Fleet Aircraft

　　•Domestic/Import:Domestic

　　TECHNICAL INFORMATION

　　•TSO Approved

　　AIRCRAFT ELIGIBILITY

　　•Embraer 145

　　*NOTE:ALL NICAD BATTERIES ARE UNCHARGED*

　　Log in to view availability

　　NSN

　　Cage Code

　　Country of origin

　　United States

　　ECCN/USML

　　EAR99

　　Schedule B

　　8507300000

　　Dimensions(L x W x H)

　　13 x 11 x 10 IN

　　Total Shelf Life(days)

　　No Information

　　Hazmat Code

　　Hazmat fees or exemptions may apply.

　　Package Weight

　　15 LB

　　FAA Approval Code

　　TSO

　　ISBN

　　Condition

　　Color

　　Brand

　　Hazmat(Y/N)

　　Y

　　LTL(Y/N)

　　N

　　8130-3 Eligible

　　Yes

　　Forecasted

　　No

　　Item Replacement History

　　Part Number:M3-44-8 Ventura®M3-44-8 Battery,USE 32845-001=2H

　　Part#:32845-001

　　Model:M3-44-8

　　Desc:Micro Maintenance Battery

　　OEM:Ventura

　　Sched-B:8507300000

　　ECCN:EAR99

　　FEATURES

　　The M3-44-8 is designed as a low-maintenance replacement for our 44Ah TSP-434 batteries

　　Incorporates a state-of-the-art negative pasted electrode that provides high volumetric and gravimetric energy density

　　Designed to increases the electrolyte reserve to more than two times the standard Ni-Cd battery

　　Long life separators

　　Nylon cell cases and covers

　　Significantly increased maintenance intervals

　　Very low water consumption

　　Excellent Capacity retention during extended cycling

　　Same physical size as standard Ni-Cd

　　Same weight as standard Ni-Cd

　　Greater Capacity than the standard Ni-Cd

　　Equal or better power than the standard Ni-Cd

　　SPECIFICATIONS

　　Voltage:24.0 volts(nominal)Capacity:44Ah minimum(at C-rate)

　　Length:15.66”max Width:6.5”max

　　Height:10.125”max Weight:81 lbs.(80 lbs.typical)

　　Imp:1335A 15 seconds(Discharge current at maximum power transfer)Connector:MS3509

　　Part Number:Description:

　　32845-001 Micro Maintenance Battery
