Specification of our 904L Stainless Steel Plate
| Products | 904L stainless steel plate |
| Thickness | 0.6 - 30.0mm |
| Width | 1000mm 1219mm 1500mm or cutting as request |
| Length | 2000mm 2438mm 3000mm 6000mm or as request |
| Standard | ASTM A240 / EN 10088-2 / JIS G4305 |
| Standard size | 1000*2000mm 1219*2438mm 1500*3000mm 1500*6000mm |
| Surface | 2B NO.1 |
| Brand | TISCO BAOSTEEL POSCO JISCO |
| Other Grade | 201 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 444 2205 2507 254SMO 253MA.etc |
| Service | Laser Cutting, bending |
Introduce of 904L Stainless Steel
Grade 904L stainless steel is a non-stabilized austenitic stainless steel with low carbon content. This high alloy stainless steel has added copper to improve its resistance to strong reducing acids, such as sulphuric acid. The steel is also resistant to stress corrosion cracking and crevice corrosion. Grade 904L stainless steel is non-magnetic, and offers excellent formability, toughness and weldability. Grade 904L contains high amounts of expensive ingredients, such as molybdenum and nickel. Today, most of the applications that employ grade 904L are replaced by low-cost duplex stainless steel 2205.
Grade 904L stainless steels have excellent resistance to warm seawater and chloride attack. The high resistance of grade 904L against stress corrosion cracking is due to the presence of high amounts of nickel in its composition. Moreover, the addition of copper to these grades develops resistance to sulphuric acid and other reducing agents in both aggressive and mild conditions.
The corrosion resistance of grade 904L is intermediate between super austenitic grades, with 6% molybdenum content, and standard 316L austenitic grades. Grade 904L is less resistant than grades 304L and 310L, which are free of molybdenum. This steel grade needs to be solution treated following cold working, to achieve maximum stress corrosion cracking resistance under critical environments.
Feather of 904L Stainless Steel
Non-magnetic
Stronger corrosion properties than Type 316L an 317L
Good resistance to sulphuric, phosphoric and acetic acids
High resistance to crevice and stress corrosion cracking
Excellent formability and weldability
Chemical Composition of 904L Stainless Steel
| C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
| 0.02 | 2.00 | 1.0 | 0.045 | 0.035 | 19.0-230 | 4.0-5.0 | 23.0-280 | 1.0 - 2.0 |
Typical application of 904L Stainless Steel
Cooling equipment for seawater
Chemical processing of sulphuric, phosphoric and acetic acids
Heat exchangers
Condenser tubes
Gas washing
Control and instrumentation
Oil and gas industry
Pharmaceutical production
Wiring in electrostatic precipitators
Size of 904L stainless steel plate in stock
| Number | Thickness | Size | |
| 1 | 2.0 | 1219*2438mm | |
| 2 | 2.5 | 1219*2438mm | |
| 3 | 3.0 | 1219*2438mm | 1500*6000mm |
| 4 | 4.0 | 1500*6000mm | |
| 5 | 5.0 | 1500*6000mm | |
| 6 | 6.0 | 1500*6000mm | |
| 7 | 8.0 | 1500*6000mm | 1800/2000mm width |
| 8 | 10.0 | 1500*6000mm | 1800/2000mm width |
| 9 | 12.0 | 1500*6000mm | 1800/2000mm width |
| 10 | 14.0 | 1500*6000mm | 1800/2000mm width |
| 11 | 16.0 | 1500*6000mm | 1800/2000mm width |
| 12 | 18.0 | 1500*6000mm | |
| 13 | 20.0 | 1500*6000mm | |
| 14 | 22.0 | 1500*6000mm | |
| 15 | 24.0 | 1500*6000mm | |
| 16 | 26.0 | 1500*6000mm | |
| 17 | 28.0 | 1500*6000mm | |
| 18 | 30.0 | 1500*6000mm | |
