Home > Metallurgy, Mineral & Energy > Steel & Products > Stainless Steel > Cold Rolled/Hot Rolled N08904/ASTM A213/ASTM A269/ASTM A312 Flat Steel Sheet for Seawater Cooling Equipment 904L Duplex Steel Plate
Cold Rolled/Hot Rolled N08904/ASTM A213/ASTM A269/ASTM A312 Flat Steel Sheet for Seawater Cooling Equipment 904L Duplex Steel Plate
US$ 35 - 50
MOQ: 100 Kilograms
Key Specifications
Get Latest Price
Type:
Stainless Steel Sheets
Certification:
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other
Shape:
Square
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
8 days
Related Products
-
Uns N08904 DIN1.4539 ASTM A240 904L Stainless Steel SheetUS$ 15 - 3000MOQ: 1 Ton -
Premium AISI JIS ISO 316 321 304 Stainless Steel Plates in BulkUS$ 1500MOQ: 2 Tons
-
A240 904L N08904 Duplex Stainless Steel Sheet 1.4539US$ 1500 - 3000MOQ: 1 Ton
-
1.4845 310S 1.4404 316L 1.4539 904L Wear Resistant Steel PlateUS$ 1500 - 3000MOQ: 1 Ton
-
904L Stainless Steel Plate ASTM A240 Low Cost 1.0mm-15mm Baosteel Brushed Surface for Food Equipment 904L Stainless SteelUS$ 1500 - 3000MOQ: 1 Ton
Type
Stainless Steel Sheets
Certification
ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other
Shape
Square
Grade
Other
Technique
Other
Surface Treatment
Polished
Standard
ASTM, AISI, GB, JIS, DIN, EN, Other
Specification
OEM
Trademark
ZHONGZHENG INTERNATIONAL
Origin
China
Basic Info.
Model NO.
904L sheet
Grade
904L
Certification
ISO, AISI, ASTM, GB, EN, DIN, JIS
Shape
Square
Technique
Cold Rolled
Surface Treatment
Pickling
Key Words
Uns S32760 (Zeron 100) Bar
Diameter
0.3mm- 16.0mm
Length
as Your Requirments
Diameter Tolerance
H9, H11, H13, K9, K11, K13 etc
Sample
Free-Sample
Surface
Lack, Peeled, Polishing, Bright, Sand Blast, Hl
MOQ
100kgs
Stock
in Stock
Transport Package
Wooden Package
Specification
S32205 bar
Trademark
ZHONGZHENG
Origin
China
HS Code
7505120000
Production Capacity
50000kg/Month
Introduction
ZHEJIANG ZHONGZHENG STAINLESS STEE MANUFACTURING CO. LTD. iis a special stainless steel manufacturer with 20 years of manufacturing experience.
15-7PH is a chromium-nickel-molybdenum-aluminium, semi-austenitic precipitation-hardening stainless steel used for applications requiring moderate corrosion resistance and high strength. The alloy is weldable by conventional methods, although the material has less superior weldability when compared to other PH steels, such as 17-4PH, due to the amount of aluminium included in the alloying process. The product retains its excellent mechanical properties up to temperatures of 482°C (900°F). 15-7PH is easily formed in the annealed condition and offers minimum distortion after heat treatment.
Duplex Stainless 904L Applications
▪ Wiring in electrostatic precipitators
▪ Oil refinery components
▪ Seawater cooling devices
▪ Gas scrubbing plants
▪ Pulp and paper processing industries
▪ Acetic, phosphoric and sulphuric acid proc
Possible Alternative Grades
| Grade | Reasons for choosing grade 904L |
| 316L | A lower cost alternative, but with much lower corrosion resistance. |
| 6Mo | A higher resistance to pitting and crevice corrosion is needed. |
| 2205 | A very similar corrosion resistance, with the 2205 having higher mechanical strength, and at a lower cost to 904L. (2205 not suitable for temperatures above 300°C.) |
| Super duplex | Higher corrosion resistance is needed, together with a higher strength than 904L. |
Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu | |
| 904L | max. | 0.02 | 2 | 1 | 0.045 | 0.035 | 19-23 | 4-5 | 23-28 | 1-2 |
Mechanical Properties
Available Sizes And Specifications
| Tensile strength Rm | 650 - 850 MPa |
| Yield point Rp0.2 | ≥ 300 MPa |
| Hardness | ≤ 260 HB |
| Elongation | ≥ 35% |
| Modulus of elasticity, E | 195 GPa |
| Density | 8.10 kg/dm³ |
| Annealing | 1050 - 1150ºC |
Available Sizes And Specifications
| 904L stainless steel plate sizes and specifications | |
| Grade | 904L |
| Cold rolled stainless steel plate | Thickness: 0.3mm- 16.0mm, Width: 1000mm - 2000mm, Length: as requirements, Surface: 2B/BA/SB/8K/HL/1D/2D etc |
| Hot rolled stainless steel sheet | Thickness: 3.0mm - 300mm, Width: 1000mm - 3000mm Length: as requirements, Surface: No.1/pickling |
| Standard | ASTM A240/A480, ASTM B688, ASTM B463/SB463, ASTM B168/SB168, ASTM B443/SB443/B424/SB424B625/SB625 B575/SB575, JIS G4303, BS 1449, DN17441, G4305 |
| Stainless steel plate | Thickness: 8.0mm - 300mm, Width: 1000mm - 3000mm Length: as requirements, Surface: No.1/pickling |
