Home > Products > Steel coil sheet and plate > Cold Rolled/Hot Rolled N08904/ASTM A213/ASTM A269/ASTM A312 Flat Steel Sheet for Seawater Cooling Equipment 904L Duplex Steel Plate

Cold Rolled/Hot Rolled N08904/ASTM A213/ASTM A269/ASTM A312 Flat Steel Sheet for Seawater Cooling Equipment 904L Duplex Steel Plate

FOB Price

USD $35 - $50 / Kilogram

100 Kilograms(Min.Order)

Supply Ability 0 Kilogram / Kilograms per Month
Payment TermsT/T L/C PayPal D/P Western Union Other
Delivery Detail8 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Stainless Steel Sheets	Certification	ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other
Shape	Square	Grade	Other
Technique	Other	Surface Treatment	Polished
Standard	ASTM, AISI, GB, JIS, DIN, EN, Other	Specification	OEM
Trademark	ZHONGZHENG INTERNATIONAL	Origin	China

Product Description

Hastelloy C-276 alloy pipe

Basic Info.

Model NO.

904L sheet

Grade

904L

Certification

ISO, AISI, ASTM, GB, EN, DIN, JIS

Shape

Square

Technique

Cold Rolled

Surface Treatment

Pickling

Key Words

Uns S32760 (Zeron 100) Bar

Diameter

0.3mm- 16.0mm

Length

as Your Requirments

Diameter Tolerance

H9, H11, H13, K9, K11, K13 etc

Sample

Free-Sample

Surface

Lack, Peeled, Polishing, Bright, Sand Blast, Hl

MOQ

100kgs

Stock

in Stock

Transport Package

Wooden Package

Specification

S32205 bar

Trademark

ZHONGZHENG

Origin

China

HS Code

7505120000

Production Capacity

50000kg/Month

Introduction

ZHEJIANG ZHONGZHENG STAINLESS STEE MANUFACTURING CO. LTD. iis a special stainless steel manufacturer with 20 years of manufacturing experience.

15-7PH is a chromium-nickel-molybdenum-aluminium, semi-austenitic precipitation-hardening stainless steel used for applications requiring moderate corrosion resistance and high strength. The alloy is weldable by conventional methods, although the material has less superior weldability when compared to other PH steels, such as 17-4PH, due to the amount of aluminium included in the alloying process. The product retains its excellent mechanical properties up to temperatures of 482°C (900°F). 15-7PH is easily formed in the annealed condition and offers minimum distortion after heat treatment.

Duplex Stainless 904L Applications

▪ Wiring in electrostatic precipitators
▪ Oil refinery components
▪ Seawater cooling devices
▪ Gas scrubbing plants
▪ Pulp and paper processing industries
▪ Acetic, phosphoric and sulphuric acid proc

Possible Alternative Grades

Grade	Reasons for choosing grade 904L
316L	A lower cost alternative, but with much lower corrosion resistance.
6Mo	A higher resistance to pitting and crevice corrosion is needed.
2205	A very similar corrosion resistance, with the 2205 having higher mechanical strength, and at a lower cost to 904L. (2205 not suitable for temperatures above 300°C.)
Super duplex	Higher corrosion resistance is needed, together with a higher strength than 904L.

Chemical Composition

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	Cu
904L	max.	0.02	2	1	0.045	0.035	19-23	4-5	23-28	1-2

Mechanical Properties

Tensile strength Rm	650 - 850 MPa
Yield point Rp0.2	≥ 300 MPa
Hardness	≤ 260 HB
Elongation	≥ 35%
Modulus of elasticity, E	195 GPa
Density	8.10 kg/dm³
Annealing	1050 - 1150ºC

Available Sizes And Specifications

904L stainless steel plate sizes and specifications
Grade	904L
Cold rolled stainless steel plate	Thickness: 0.3mm- 16.0mm, Width: 1000mm - 2000mm, Length: as requirements, Surface: 2B/BA/SB/8K/HL/1D/2D etc
Hot rolled stainless steel sheet	Thickness: 3.0mm - 300mm, Width: 1000mm - 3000mm Length: as requirements, Surface: No.1/pickling
Standard	ASTM A240/A480, ASTM B688, ASTM B463/SB463, ASTM B168/SB168, ASTM B443/SB443/B424/SB424B625/SB625 B575/SB575, JIS G4303, BS 1449, DN17441, G4305
Stainless steel plate	Thickness: 8.0mm - 300mm, Width: 1000mm - 3000mm Length: as requirements, Surface: No.1/pickling
