ABB CI522A 3BSE018283R1 AF100 Interface Module

Guizhou Yuanmiao Automation Equipment Co., Ltd.
1Yr
ABB CI522A 3BSE018283R1 AF100 Interface Module thumbnail-1
ABB CI522A 3BSE018283R1 AF100 Interface Module thumbnail-2
ABB CI522A 3BSE018283R1 AF100 Interface Module thumbnail-3
ABB CI522A 3BSE018283R1 AF100 Interface Module photo-1
ABB CI522A 3BSE018283R1 AF100 Interface Module photo-2
ABB CI522A 3BSE018283R1 AF100 Interface Module photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Global universal model
Condition:
Other, Global universal model
Task:
Other, Global universal model
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Other, Global universal model
Condition Other, Global universal model
Task Other, Global universal model
Mathematical Model Other, Global universal model
Signal Other, Global universal model
Customized Non-Customized
Structure Other, Global universal model
Operating temperature -40℃~+85℃
Humidity 5%~95% (non-condensing)




Many products are not on the shelves yet, please contact us for more models.





1. Product Overview
Model: CI522A (Order No.: 3BSE018283R1)
Type: Communication Interface Module
Applicable Systems: ABB Advant Controller 400 Series, System 800xA
Function: Enables data exchange between controllers and field devices, supporting multiple industrial communication protocols.
2. Technical ParametersElectrical Parameters

  • Power Supply: 24V DC (±15%), power consumption ~5W

  • Interfaces:

    • 2 RS-232/RS-485 ports (configurable)

    • 1 Ethernet port (10/100Mbps)

  • Communication Protocols: Modbus RTU/TCP, Profibus DP, IEC 60870-5-101/104, DNP3, etc.

Environmental Conditions

  • Operating Temperature: -25°C ~ +70°C

  • Storage Temperature: -40°C ~ +85°C

  • Humidity: 5% ~ 95% (non-condensing)



ABB CI522A 3BSE018283R1 AF100 Interface Module



3. Installation GuideMechanical Installation

  1. Fix the module on a DIN rail or via screws in the control cabinet.

  2. Ensure a spacing of ≥25mm between modules for heat dissipation.

Wiring Instructions

  • Power Connection: Use 2.5mm² wires to connect 24V DC positive and negative poles, noting polarity.

  • Communication Interfaces:

    • RS-232: Connect via a DB9 serial cable.

    • RS-485: Adopt differential signal transmission; terminal resistors (120Ω) may be enabled as needed.

    • Ethernet: Use an RJ45 port with auto-negotiation support.

Grounding Requirements

  • The module casing must be reliably grounded (ground resistance ≤10Ω).




ABB CI522A 3BSE018283R1 AF100 Interface Module
