EU General Hot Sale Monel 400 Seamless Tubing Uns N04400 Welded Tubing Fitting Monel K500 Pipe
Negotiable
MOQ: 1 Ton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Seamless
Technique:
Cold Rolled
Surface Treatment:
Other
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
8 days
Related Products
-
EU General High-Quality Monel 400 Small Diameter Pipe for Industrial UseNegotiableMOQ: 1 Ton -
EU General Premium Monel 400 Nickel Alloy Round Bar for Industrial UseNegotiableMOQ: 1 Ton
-
EU General Uns N04400 Nickel Alloy 400 Round Bar Per Kg Monel 400 Rod Per Kg PriceNegotiableMOQ: 1 Ton
-
EU General Monel 400 N04400 Na12 Nu30 Nickel Alloy Bar RodNegotiableMOQ: 1 Ton
-
EU General Monel Round Bars Monel Rod Monel 400 N04400 Bars and RodsNegotiableMOQ: 1 Ton
Type
Seamless
Technique
Cold Rolled
Surface Treatment
Other
Material
Stainless steel
Section Shape
Round
Basic Info.
Model NO.
Monel 400 pipe
Purity
63%
Alloy
Alloy
Type
Nickel Bar
Powder
Not Powder
Elongation
35
Melting Point
1300-1390
Tensile Strength
480
Density g/cm3
8.83
Size
Customizable
Transport Package
Carton or Wooden Case
Specification
monel 500
Trademark
Victory
Origin
China
Production Capacity
500000
Product Description
Monel 400 is a nickel-copper alloy (about 67% Ni - 23% Cu) that is resistant to sea water and steam at high temperatures as well as to salt and caustic solutions. Alloy 400 is a solid solution alloy that can only be hardened by cold working. This nickel alloy exhibits characteristics like good corrosion resistance, good weldability and high strength. A low corrosion rate in rapidly flowing brackish or seawater combined with excellent resistance to stress-corrosion cracking in most freshwaters, and its resistance to a variety of corrosive conditions led to its wide use in marine applications and other non-oxidizing chloride solutions. This nickel alloy is particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated. As would be expected from its high copper content, alloy 400 is rapidly attacked and ammonia systems. Monel 400 has great mechanical properties at subzero temperatures, can be used in temperatures up to 1000° F, and its melting point is 2370-2460° F. However, alloy 400 is low in strength in the annealed condition so, a variety of tempers may be used to increase the strength.
Features:
* Resistant to seawater and steam at high temperatures
* Excellent resistance to rapidly flowing brackish water or seawater
* Excellent resistance to stress corrosion cracking in most freshwaters
* Particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated
* Offers some resistance to hydrochloric and sulfuric acids at modest temperatures and concentrations, but is seldom the material of choice for these acids
* Excellent resistance to neutral and alkaline salt
* Resistance to chloride induced stress corrosion cracking
* Good mechanical properties from sub-zero temperatures up to 1020° F
* High resistance to alkalis
Applications:
* Valves, pumps, shafts, fittings, and fasteners
* Industrial heat exchangers
* Chlorinated solvents
* Crude oil distillation towers
* Marine engineering
* Chemical and hydrocarbon processing equipment
* Gasoline and freshwater tanks
* Crude petroleum stills
* De-aerating heaters
* Boiler feed water heaters and other heat exchangers
Features:
* Resistant to seawater and steam at high temperatures
* Excellent resistance to rapidly flowing brackish water or seawater
* Excellent resistance to stress corrosion cracking in most freshwaters
* Particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated
* Offers some resistance to hydrochloric and sulfuric acids at modest temperatures and concentrations, but is seldom the material of choice for these acids
* Excellent resistance to neutral and alkaline salt
* Resistance to chloride induced stress corrosion cracking
* Good mechanical properties from sub-zero temperatures up to 1020° F
* High resistance to alkalis
Applications:
* Valves, pumps, shafts, fittings, and fasteners
* Industrial heat exchangers
* Chlorinated solvents
* Crude oil distillation towers
* Marine engineering
* Chemical and hydrocarbon processing equipment
* Gasoline and freshwater tanks
* Crude petroleum stills
* De-aerating heaters
* Boiler feed water heaters and other heat exchangers
| Item | Ni% | Cu% | Fe% | Mn% | C% | Si% | S% |
| Monel 400 | ≥63 | 28-34 | ≤2.5 | ≤2 | ≤0.3 | ≤0.5 | ≤0.025 |
| Item | Density | Melting Point | Tensile Strength | Yield Strength | Elongation | HB |
| (Rm N/mm2) | (RP0.2N/mmx) | (A5%) | ||||
| Monel 400 | 8.83 g/cm3 | 1300-1390ºC | 480 | 170 | 35% | ≥331 |
| Moenl 400 | Bar/Rod | Forging | Pipe | Sheet/Strip | Welding Wire |
| Standard | ASTM B164 | ASTM B564 | ASTM B165 | ASTM B127 | ErNiCu-7 |
| Item | Ni% | Cu% | Al% | Ti% | Fe% | Mn% | S% | C% | SI% |
| Monel K500 | ≥63 | 27-33 | 2.3-3.15 | 0.35-0.85 | ≤2 | ≤1.5 | ≤0.01 | ≤0.25 | ≤0.5 |
| Item | Density | Melting Point | Tensile Strength | Yield Strength | Elongation |
| (Rm N/mm2) | (RP0.2N/mmx) | (A5%) | |||
| Monel K500 | 8.05 g/cm3 | 1343ºC | 1100 | 790 | 20% |
| Moenl K500 | Bar/Rod | Forging | Pipe | Sheet/Strip | Welding Wire |
| Standard | ASTM B865 | AMS4676 | ASTM B865 | ASTM B564 | ErNiCu-7 |
