2V80F Double Cylinder Water-Cooled Diesel Engine
Product Spotlights
Double cylinder, strong & stable power
Water-cooled system, better heat dissipation
Low fuel consumption & low vibration
Reliable, long service life
Wide application for generator, pump, machinery
US$ 940
10 - 49 Pieces
US$ 920
50 - 99 Pieces
US$ 900
≥100 Pieces
Key Specifications
Get Latest Price
Type:
Other, two cylinder water-cooled diesel engine
Warranty:
1 year or 1000 hours
Fuel:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
30 days
Related Products
-
292F Double Cylinder Air-Cooled Diesel Engine Splined Shaft/keyway Shaft/tapered ShaftUS$ 900 - 940MOQ: 10 Pieces -
10KW Dual Power Electric Start Gasoline Generator for Home & IndustrialUS$ 1050 - 1100MOQ: 5 Pieces
-
12KW Portable Gasoline Generator Single/Three Phase for Home & IndustryUS$ 1100 - 1150MOQ: 5 Pieces
-
15KW Single Phase 220V Gasoline Generator With R999D Engine 100% Copper AlternatorUS$ 1400 - 1450MOQ: 5 Pieces
-
18KW Dual Power Gasoline Generator Single/Three PhaseUS$ 1420 - 1470MOQ: 5 Pieces
Type
Other, two cylinder water-cooled diesel engine
Warranty
1 year or 1000 hours
Fuel
Diesel
Speed
High Speed
After-sales Service
Exchange parts
Ignition Mode
Compression-Ignition
Cooling Cylinder
Water-Cooled
Intake Pressure Impulse
Naturally Aspirated
Piston Movement
Reciprocating
Number of Strokes
Four-Stroke
Cylinder Arrangement Form
V
Number of Cylinders
Double-Cylinder
Transport Package
wooden case
Specification
2V80F
Trademark
Belon Power
Origin
China
High Performance 2V80F Double Cylinder Water-Cooled Diesel Engine
| Model | 2V80 |
| Type | 2 cylinders，V Type，Water Cooled，4 strokes |
| Bore*Stroke（mm) | 80x79 |
| Rated Power/Speed（KW/RPM) | 12/3000,14/3600 |
| Max. Power/Speed（KW/RPM) | 13.2(18)/3000,15.4(21)/3600 |
| Rated Speed（RPM) | 3000/3600 |
| Compression Ratio | 23:1 |
| Max Torque/Speed（Nm/Rpm) | 42.7/2700 |
| Displacement(cc) | 794 |
| Fuel Consumption(g/kw.h) | ≤297 |
| Oil Tank Capacity（L) | 2.3 |
| Fuel Grade | Diesel 0#（summer）；-10#（winter） |
| Oil Grade | SAE10W30(CD grade or above） |
| Start Mode | Electric |
| Output Model | Crankshaft output |
| Size（mm) | 616x486x528 |
| Net Weight（kg) | 58 |
