Basic Info.
Mechanical Properties
The mechanical properties of INCOLOY alloy 800 are tabulated below.
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength(annealed) | 600 MPa | 87 ksi |
| Yield strength(annealed) | 275 MPa | 39.9 ksi |
| Elongation at Break | 45% | 45% |
Other Designations
Some of the designations used to denote INCOLOY alloy 800 are listed below:
| UNS N08800 | AMS 5766 | AMS 5871 | ASTM B163 | ASTM B366 |
| ASTM B407 | ASTM B408 | ASTM B409 | ASTM B514 | ASTM B515 |
| ASTM B564 | DIN 1.4876 |
| Incoloy | Incoloy 800 | Incoloy 800H | ||
| Element | Min | Max | Min | Max |
| Nickel + Cobalt | 30.0 | 35.0 | 30.0 | 35.0 |
| Cobalt | --- | 2.00 | --- | 2.00 |
| Chromium | 19.0 | 23.0 | 19.0 | 23.0 |
| Copper | --- | 0.75 | --- | 0.75 |
| Iron | Bal | Bal | ||
| Silicon | --- | 1.00 | --- | 1.00 |
| Manganese | --- | 1.50 | --- | 1.50 |
| Carbon | --- | 0.10 | 0.05 | 0.10 |
| Aluminum | 0.15 | 0.60 | 0.15 | 0.60 |
| Titanium | 0.15 | 0.60 | 0.15 | 0.60 |
| Sulfur | --- | 0.015 | --- | 0.015 |
| Form and Condition | Tensile Strength | Yield Strength (0.2% Offset) | Elongation, % | Hardness, Rockwell | ||
| ksi | Mpa | Ksi | Mpa | |||
| Wire | ||||||
| cold drawn | ||||||
| Annealed | 80-120 | 550-830 | 35-75 | 240-520 | 45-20 | - |
| No. 1 Temper | 105-135 | 725-930 | 70-105 | 480-725 | 35-15 | - |
| Spring Temper | 170-220 | 1170-1520 | 150-210 | 1035-1450 | 5-2 | |
-
Introduction
ZHEJIANG ZHONGZHENG STAINLESS STEE MANUFACTURING CO. LTD. is a professional supplier of stainless steel materials, located in Zhejiang, China with high speed of economic development. We are near shanghai port; the traffic is very convenient.The main stainless steel materials are stainless steel plate, pressure vessel stainless steel plate, high temperature boiler plate, corrosion resistant stainless steel plate, stainless steel seamless pipe, stainless steel industrial pipe, stainless steel welded pipe, stainless steel bar, stainless steel pipe and so on.With the aim of "quality first, timely delivery, good faith cooperation, considerate service and common development", the company has set up a good reputation in the industry for providing high quality stainless steel materials and perfect after-sales service.
- Incoloy 800h Application
These fantastic properties are the primary reasons of wide applications of Incoloy 800H nickel alloy, including condenser, steam heating pipe, heating element tube, etc.
▪ Industrial furnace components and equipment
▪ Petrochemical and chemical processing
▪ Equipment for Heat-Treating
▪ Pressure vessels and heat exchangers
▪ Hydrocarbon cracking- Incoloy 800 / 800H / 800HT Sheet & Plates Equivalent Grades :
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN OR Incoloy 800 1.4876 N08800 NCF 800 NA 15 ЭИ670 Z8NC32-21 X10NiCrAlTi32-20 XH32T Incoloy 800H 1.4958 / 1.4876 N08810 NCF 800H NA 15(H) ЭИ670 Z8NC33-21 X5NiCrAlTi31-20 XH32T Incoloy 800HT 1.4859 / 1.4876 N08811 NCF 800HT NA 15(HT) ЭИ670 - X8NiCrAlTi32-21 XH32T - Incoloy 800h Specifications
UNS W. Nr N08800 1.4876 - Incoloy 800h Chemical Composition
Composition Ni Cr Fe C Mn Si Cu S Al Ti P Content (%) Min 30 19 0.15 0.15 0.15 Max 35 23 0.10 1.5 1.0 0.75 0.015 0.60 0.60 0.03 - Incoloy 800h Mechanical Properties
Tensile Strength (σb/MPa) Yield Strength (σp0.2/MPa) Elongation (σ5/%) 450 180 35 - Incoloy 800h Product Forms And Standards
Bar Forging Sheet/Strip Wire Pipe ASTM B408 ASTM B564 ASTM B409 ASTM B408 ASTM B407
ASTM B514 - Available Sizes And Specifications
Incoloy 800H available sizes and specifications Grade Incoloy 800H Nickel plate Thickness: 0.3mm - 150.0mm
Width: 1000mm - 3000mmNickel strip/ nickel foil Thickness: 0.02mm - 16.0mm
Width: 5mm - 3000mmNickel coil Thickness: 0.3mm - 16.0mm
Width: 1000mm - 3000mmNickel pipe Outside diameter: 6mm - 1219mm
Thickness: 0.5mm - 100mmNickel Capillary Pipe Outside diameter: 0.5mm - 6.0mm
Thickness: 0.05mm - 2.0mmNickel bar Diameter: Ф4mm - Ф600mm Nickel wire rod Diameter:Ф0.01mm - Ф6mm
Transoprt
Why choose us?
-
• You can get the perfect material according to your requirement at the least possible price.
• We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
• The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)
• We guarantee to give a response within 24hours(usually in the same hour)
• Provide SGS, TUV,BV 3.2 report.
• We are fully dedicated to our customers. If it will not possible to meet your requirements after examining all options, we will not mislead you by making false promises which will create good customer relations.
• Provide one-stop service.
