Home > Products > Hygienic grade piping series > EU Genera Premium Hastelloy C2000 Nickel Alloy Sheet - ASME Sb575 Uns N06200

EU Genera Premium Hastelloy C2000 Nickel Alloy Sheet - ASME Sb575 Uns N06200

FOB Price

Negotiable / Ton

1 Ton(Min.Order)

Supply Ability 0 Ton / Tons per Month
Payment TermsT/T
Delivery Detail8 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Seamless	Technique	Cold Rolled
Surface Treatment	Other	Material	Stainless steel
Section Shape	Round

Product Description

Basic Info.

Model NO.

UNS N06200/W. Nr. 2.4675/Hastelloy C2000

Purity

Min 72%

Alloy

Type

Nickel Plate

Powder

Thickness

0.2-100mm

Width

Normally 1000mm/1219mm/1500mm

Length

Normally 2000mm/2438mm/6000mm

Mtc

En 10204/3.1

Keyword

Hastelloy C2000 Price

Trademark

ZYTC

Origin

Tianjin, China

HS Code

75062000

Production Capacity

500 Tons/Month

Product Description

Hastelloy C-2000 (UNS N06200 / W.Nr. 2.4675) is unique among the versatile nickel-chromium-molybdenum materials in having a deliberate copper addition. This provides greatly enhanced resistance to sulfuric acid. It also has a high chromium content, to maximize its resistance to oxidizing chemicals and process streams contaminated with ferric ions and dissolved oxygen.Hastelloy C-2000 Features:

Designed to resist an extensive range of corrosive chemicals, including sulfuric, hydrochloric, and hydrofluoric acids
Unlike previous Ni-Cr-Mo alloys, which were optimized for use in either oxidizing or reducing acids, C-2000 alloy extends corrosion resistance in both types of environments
The combination of molybdenum and copper (at levels of 16 and 1.6 wt. %, respectively) provide outstanding resistance to reducing media, while oxidizing acid resistance is provided by a high chromium content (23 wt. %).

Hastelloy C-2000 Specifications:

Trademark	GB	GOST	ASTM	UNS	DIN	W.Nr.	NF
Hastelloy C-2000	NS3405	-	Hastelloy C-2000	N06200	NiCr23Mo16Cu	2.4675	-

Hastelloy C-2000 Product Forms and Standards:

Rod, Bar, Wire and Forgings	ASTM B462, ASTM B472, ASTM B564, ASTM B574, ASME SB462, ASME SB472, ASME SB564, ASME SB574
Plate, Sheet and Strip	ASTM B575, ASME SB575
Pipe and Tube	ASTM B619, ASTM B622, ASTM B626, ASME SB619, ASME SB622, ASME SB626
Welding Product	AWS A5.14 ERNiCrMo-17, ASME SFA-5.14 ERNiCrMo-17, ASME F-No.43
Others	ASTM B366, ASTM B462, ASME SB366, ASME SB462, DIN 17744

Hastelloy C-2000 Chemical Compositions:

Alloy

Hastelloy C-2000

≤0.01

≤0.08

≤0.50

≤0.025

≤0.010

22.0-24.0

Bal

≤2.0

15.0-17.0

≤0.50

1.3-1.9

17.0-20.0

Hastelloy C-2000 Mechanical Properties (RT, Solution annealed)

Density, g/cm3	Melting Point, ºC	Tensile Strength, MPa	Yield Strength, MPa	ELongation, %	Hardness, HB
8.50	1328-1358	760	363	64	-

Hastelloy C-2000 Application:

Chemical process industry reactors, heat exchangers, columns, and piping
Pharmaceutical industry reactors and dryers
Flue gas desulfurization systems

Nickel Sheet
Thickness	0.3mm - 6.0mm
Width	1000mm - 2200mm
Length	Produce as requirement
Nickel Plate
Thickness	3.0mm - 300mm
Width	1000mm - 3000mm
Length	Produce as requirement
Nickel Strip / Nickel Foil
Thickness	0.02mm - 16.0mm
Width	5mm - 900mm
Nickel Coil
Thickness	0.3mm - 16.0mm
Width	1000mm - 3000mm
Nickel Pipe
Outside Diameter	6.0mm - 1219mm
Thickness	0.5mm - 100mm
Nickel Capillary Pipe
Outside Diameter	0.5mm - 6.0mm
Thickness	0.05mm - 2.0mm
Nickel Bar
Diameter	Ф4mm - Ф600mm
Nickel Wire Rod
Diameter	Ф0.01mm - Ф6.0mm
Material Classification
Inconel	Inconel 722, Inconel 725, Inconel X-750, Inconel 625, Inconel 686, Inconel 690, Inconel 702, Inconel 706, Inconel 713C, Inconel 600, Inconel 601, Inconel 602CA, Inconel 617, Inconel 718.
Incoloy	Incoloy 945, Incoloy A-286, Incoloy 901, Incoloy 903, Incoloy 907, Incoloy 909, Incoloy 925, Incoloy 926, Incoloy 330, Incoloy 800, Incoloy 800H, Incoloy 800HT, Incoloy 801, Incoloy 840, Incoloy 20, Incoloy 205, Incoloy 208
Hastelloy	Hastelloy C 276, Hastelloy G, Hastelloy W, Hastelloy X, Hastelloy G-30, Hastelloy G-35, Hastelloy G3, Hastelloy N, Hastelloy S, B-2, Hastelloy B-3, Hastelloy C2000, Hastelloy C22
Haynes	Haynes 75, Haynes 244, Haynes 25, Haynes 263, Haynes 282, Haynes 556, Haynes 188, Haynes 230, Haynes 233, Haynes 242
Monel	Monel 400, Monel K-500, Monel R405, Monel 401, Monel 404, Monel 405.
Nimonic	Nimonic 91, Nimonic C263, Nimonic PE11, Nimonic PE16, Nimonic PK33, Nimonic 80A, Nimonic 96, Nimonic 90, Nimonic 901, Nimonic 105, Nimonic 115
Other Nickel	Waspaloy, Multimet N155, Mumetal 80, Rene 41, Kovar, Maraging 250, Maraging 300, Maraging 350, MP159, MP35N, Alloy 46, Alloy 48, Alloy 52, Alloy 42, Alloy 45, Cobalt alloy 6b, Custom 455, Invar 36, Invar 42, Nickel 200, Nickel 201

Specifications

Nickel Sheet
Thickness	0.3mm - 6.0mm
Width	1000mm - 2200mm
Length	Produce as requirement
Nickel Plate
Thickness	3.0mm - 300mm
Width	1000mm - 3000mm
Length	Produce as requirement
Nickel Strip / Nickel Foil
Thickness	0.02mm - 16.0mm
Width	5mm - 900mm
Nickel Coil
Thickness	0.3mm - 16.0mm
Width	1000mm - 3000mm
Nickel Pipe
Outside Diameter	6.0mm - 1219mm
Thickness	0.5mm - 100mm
Nickel Capillary Pipe
Outside Diameter	0.5mm - 6.0mm
Thickness	0.05mm - 2.0mm
Nickel Bar
Diameter	Ф4mm - Ф600mm
Nickel Wire Rod
Diameter	Ф0.01mm - Ф6.0mm

Chemical Component

Inconel Alloy

Item	600	601	617	625	690	718	X750	825
C	≤0.15	≤0.1	0.05-0.15	≤0.1	≤0.05	≤0.08	≤0.08	≤0.05
Mn	≤1	≤1.5	≤0.5	≤0.5	≤0.5	≤0.35	≤1	≤1
Fe	6-10	rest	≤3	rest	7-11	rest	5-9	≥22
P	≤0.015	≤0.02	≤0.015	--	--	--	--	--
S	≤0.015	≤0.015	≤0.015	≤0.015	≤0.015	≤0.01	≤0.01	≤0.03
Si	≤0.5	≤0.5	≤0.5	≤0.5	≤0.5	≤0.35	≤0.5	≤0.5
Cu	≤0.5	≤1	--	≤0.3	≤0.5	≤0.3	≤0.5	1.5-3
Ni	≥72	58-63	≥44.5	50-55	≥58	50-55	≥70	38-46
Co	--	--	10-15	≤10	--	≤1	≤1	--
Al	--	1-1.7	0.8-1.5	≤0.8	--	0.2-0.8	0.4-1	≤0.2
Ti	--	--	≤0.6	≤1.15	--	--	2.25-2.75	0.6-1.2
Cr	14-17	21-25	20-24	17-21	27-31	17-21	14-17	19.5-23.5
Nb+Ta	--	--	--	4.75-5.5	--	4.75-5.5	0.7-1.2	--
Mo	--	--	8-10	2.8-3.3	--	2.8-3.3	--	2.5-3.5
B	--	--	≤0.006	--	--	--	--	--

Incoloy Alloy

Grade		800	800H	800HT	825	925
Chemical Composition (%)	C	≤0.1	0.05-0.1	0.06-0.1	≤0.05	≤0.03
	Mn	≤1.5	≤1.5	≤1.5	≤1	≤1
	Fe	rest	rest	rest	rest	rest
	P	--	--	--	≤0.02	≤0.03
	S	≤0.015	≤0.015	≤0.015	≤0.03	≤0.03
	Si	≤1	≤1	≤1	≤0.5	≤0.5
	Cu	≤0.75	≤0.75	≤0.75	1.5-3	1.5-3
	Ni	30-35	30-35	30-35	38-46	42-46
	Al	0.15-0.6	0.15-0.6	0.15-0.6	0.2-1	0.15-0.5
	Ti	0.15-0.6	0.15-0.6	0.15-0.6	0.6-1.2	1.9-2.4
	Cr	19-23	19-23	19-23	19.5-23.5	19.5-23.5
	Mo	--	--	--	2.5-3.5	2.5-3.5

Hastelloy Alloy

Grade		C276	C22	C4	B2	B3	N
Chemical Composition (%)	C	≤0.01	≤0.015	≤0.015	≤0.02	≤0.01	0.04-0.08
	Mn	≤1	≤0.5	≤1	≤1	≤3	≤1
	Fe	4-7	2-6	≤3	≤2	≤1.5	≤5
	P	≤0.04	≤0.02	≤0.04	≤0.04	--	≤0.015
	S	≤0.03	≤0.02	≤0.03	≤0.03	--	≤0.02
	Si	≤0.08	≤0.08	≤0.08	≤0.1	≤0.1	≤1
	Ni	rest	rest	rest	rest	≥65	rest
	Co	≤2.5	≤2.5	≤2	≤1	≤3	≤0.2
	Ti+Cu	--	--	≤0.7	--	≤0.4	≤0.35
	Al+Ti	--	--	--	--	≤0.5	≤0.5
	Cr	14.5-16.5	20-22.5	14-18	≤1	≤1.5	6-8
	Mo	15-17	12.5-14.5	14-17	26-30	≤28.5	15-18
	B	--	--	--	--	--	≤0.01
	W	3-4.5	2.5-3.5	--	--	≤3	≤0.5
	V	≤0.35	≤0.35	--	0.2-0.4	--	≤0.5

Inconel	Inconel 722, Inconel 725, Inconel X-750, Inconel 625, Inconel 686, Inconel 690, Inconel 702, Inconel 706, Inconel 713C, Inconel 600, Inconel 601, Inconel 602CA, Inconel 617, Inconel 718.
Incoloy	Incoloy 945, Incoloy A-286, Incoloy 901, Incoloy 903, Incoloy 907, Incoloy 909, Incoloy 925, Incoloy 926, Incoloy 330, Incoloy 800, Incoloy 800H, Incoloy 800HT, Incoloy 801, Incoloy 840, Incoloy 20, Incoloy 205, Incoloy 208
Hastelloy	Hastelloy C 276, Hastelloy G, Hastelloy W, Hastelloy X, Hastelloy G-30, Hastelloy G-35, Hastelloy G3, Hastelloy N, Hastelloy S, B-2, Hastelloy B-3, Hastelloy C2000, Hastelloy C22
Haynes	Haynes 75, Haynes 244, Haynes 25, Haynes 263, Haynes 282, Haynes 556, Haynes 188, Haynes 230, Haynes 233, Haynes 242
Monel	Monel 400, Monel K-500, Monel R405, Monel 401, Monel 404, Monel 405.
Nimonic	Nimonic 91, Nimonic C263, Nimonic PE11, Nimonic PE16, Nimonic PK33, Nimonic 80A, Nimonic 96, Nimonic 90, Nimonic 901, Nimonic 105, Nimonic 115
Other Nickel	Waspaloy, Multimet N155, Mumetal 80, Rene 41, Kovar, Maraging 250, Maraging 300, Maraging 350, MP159, MP35N, Alloy 46, Alloy 48, Alloy 52, Alloy 42, Alloy 45, Cobalt alloy 6b, Custom 455, Invar 36, Invar 42, Nickel 200, Nickel 201
