ASTM |
ASTM A270 / ASME SA 270 |
Type |
Ferritic/Austenitic Stainless Steel and Seamless and Welded Austenitic Sanitary Tubing |
Wall |
16 Gauge (0.065") |
OD. |
1/2” |
OD Tolerance |
+/-0.005” / +/-0.13MM |
Length |
20′ |
Length Tolerance |
+1/8” / +3.18MM |
WT Tolerance |
+/-10% |
Standard |
3A / ASTM A270 / A270M |
Material |
SS 304L, SS 304, SS 316,SS 316L |
Polish |
Mechanical Polished |
Packing |
Ends Capped, Sleeved, Wooden Boxed |
Finish |
20Ra ID / 32Ra OD |
Certification |
3A – Food / Dairy Grade |
Type |
Seamless |
Mill Test Certificate |
EN10204 3.1 |
In stainless steel tubing for sanitary applications, precision and quality are two of the most important factors. The ASTM A270 standard plays a crucial role in ensuring that hygienic tubing meets the stringent requirements of industries such as food and beverage, pharmaceuticals, and biotechnology. We will cover what ASTM A270 is, its significance, and how it distinguishes itself from other similar quality standards.
What is ASTM A270?
ASTM A270 is a set of standards developed by the American Society for Testing and Materials (ASTM) that specifically addresses the requirements for seamless and welded austenitic stainless steel sanitary tubing intended for use in dairy and food industry and having special surface finishes. The standard encompasses various dimensions, mechanical properties, and surface finish requirements to ensure the tubes’ suitability for hygienic applications.
Key Features of ASTM A270:
· Material Specifications:
ASTM A270 focuses on austenitic stainless steel, which is known for its corrosion resistance and high levels of hygiene. Common grades include 304 and 316 stainless steel.
· Dimensional Specifications:
The standard specifies the dimensions of tubes, including outside diameter, wall thickness, and length. This ensures consistency and compatibility in various systems.
· Mechanical Properties:
ASTM A270 outlines mechanical properties such as tensile strength, yield strength, and elongation. These properties are crucial for withstanding the mechanical stresses that tubing may experience during installation and use.
· Surface Finish:
One of the key differentiators of ASTM A270 is its emphasis on surface finish. The standard categorizes surface finishes into specific classes, such as mechanically polished and electropolished, to meet the stringent cleanliness requirements of industries like pharmaceuticals.
Comparison with Other Standards:
While there are other standards related to stainless steel tubing, ASTM A270 stands out in its focus on hygienic applications. Let’s briefly compare it with some other relevant standards:
· ASTM A249:
ASTM A249 covers general stainless steel tubing, but it lacks the specific focus on the hygienic requirements found in ASTM A270. A249 may be suitable for less critical applications where surface finish and cleanliness are not as crucial.
· ASME BPE (Bioprocessing Equipment):
ASME BPE shares similarities with ASTM A270 but is specifically tailored for bioprocessing applications. It delves deeper into requirements for surface finish, materials, and fabrication techniques applicable to the pharmaceutical and biotechnology industries.
· DIN 11850:
This German standard is similar to ASTM A270 but caters to European markets. While it covers stainless steel tubes for food and chemical industries, the specifics may differ from ASTM A270.
Conclusion:
ASTM A270 stands as a benchmark for hygienic stainless steel tubing, ensuring that it meets the stringent requirements of industries where cleanliness and corrosion resistance are paramount. While other standards exist, their focus may differ, and choosing the right standard depends on the specific needs of the application. When it comes to hygienic tubing, ASTM A270 sets the standard for precision, quality, and reliability.
Dimensional Tolerances of Sanitary Stainless Steel Tubing
TUBE |
SIZE OD |
NOMINAL WALL THICKNESS |
OUTSIDE DIAMETER TOLERANCE |
LENGTH TOLERANCE |
WALL THICKNESS TOLERANCE |
||||
(in) |
(mm) |
(in) |
(mm) |
(in) |
(mm) |
(in) |
(mm) |
(%) |
|
Sanitary Tubing |
½ |
12.7 |
0.065 |
1.65 |
+/-0.005 |
+/-0.13 |
+⅛, -0 |
+3.18, -0 |
+/-10.0% |
Stainless Steel Sanitary Tubing |
¾ |
19.1 |
0.065 |
1.65 |
+/-0.005 |
+/-0.13 |
+⅛, -0 |
+3.18, -0 |
+/-10.0% |
Sanitary Stainless Tubing |
1 |
25.4 |
0.065 |
1.65 |
+/-0.005 |
+/-0.13 |
+⅛, -0 |
+3.18, -0 |
+/-10.0% |
SS Sanitary Tube |
1½ |
38.1 |
0.065 |
1.65 |
+/-0.008 |
+/-0.20 |
+⅛, -0 |
+3.18, -0 |
+/-10.0% |
Sanitary Tubing |
2 |
50.8 |
0.065 |
1.65 |
+/-0.008 |
+/-0.20 |
+⅛, -0 |
+3.18, -0 |
+/-10.0% |
Stainless Steel Sanitary Pipe |
2½ |
63.5 |
0.065 |
1.65 |
+/-0.010 |
+/-0.25 |
+⅛, -0 |
+3.18, -0 |
+/-10.0% |
Sanitary Stainless Tubing |
3 |
76.2 |
0.065 |
1.65 |
+/-0.010 |
+/-0.25 |
+⅛, -0 |
+3.18, -0 |
+/-10.0% |
Sanitary Stainless Pipe |
4 |
101.6 |
0.083 |
2.11 |
+/-0.015 |
+/-0.38 |
+⅛, -0 |
+3.18, -0 |
+/-10.0% |
Stainless Steel Sanitary Tubing |
6 |
152.4 |
0.109 |
2.77 |
+/-0.030 |
+/-0.76 |
+1, -0 |
+25.4, -0 |
+/-10.0% |
Schedule Chart of Stainless Steel Welded Sanitary Tubing
PIPE |
NB SIZES |
SCH 5 |
SCH 10 |
SCH 40 |
SCH 80 |
SCH 160 |
SS Sanitary Tube |
1/8″ |
√ |
√ |
√ |
√ |
|
Sanitary Tubing |
1/4″ |
√ |
√ |
√ |
√ |
|
Stainless Steel Sanitary Tubing |
3/8″ |
√ |
√ |
√ |
√ |
|
Sanitary Stainless Tubing |
1/2″ |
√ |
√ |
√ |
√ |
√ |
SS Sanitary Tube |
3/4″ |
√ |
√ |
√ |
√ |
√ |
Sanitary Tubing |
1″ |
√ |
√ |
√ |
√ |
√ |
Stainless Steel Sanitary Pipe |
1 1/4″ |
√ |
√ |
√ |
√ |
√ |
Sanitary Stainless Tubing |
1 1/2″ |
√ |
√ |
√ |
√ |
√ |
Sanitary Stainless Pipe |
2″ |
√ |
√ |
√ |
√ |
√ |
Stainless Steel Sanitary Tubing |
2 1/2″ |
√ |
√ |
√ |
√ |
√ |
Sanitary Tubing |
3″ |
√ |
√ |
√ |
√ |
√ |
Stainless Steel Sanitary Tubing |
4″ |
√ |
√ |
√ |
√ |
√ |
Sanitary Stainless Tubing |
5″ |
√ |
√ |
√ |
√ |
|
SS Sanitary Tube |
6″ |
√ |
√ |
√ |
√ |
Inner Surface
Hygienic class |
Inner surface |
Seam area inside |
H1 |
Ra |
Ra |
H2 |
Ra |
Ra |
H3 |
Ra |
Ra |
H4 |
Ra |
Ra |
H5 |
Ra |
Ra |
Outer Surface
· with nominal Ra value: typ. ground Ra
· without nominal Ra value: pickled or bright-annealed
DIN 11866 Range A / 304L – 316L
OUTSIDE DIAMETER (MM) |
WALL- THICKNESS (MM) |
NOMINAL OUTSIDE DIAMETER |
NOMINAL WALL THICKNESS |
DIMENSIONAL STANDARD |
8,00 |
1,00 |
DN 6 |
R.A |
DIN 11866 Reihe A |
10,00 |
1,00 |
DN 8 |
R.A |
DIN 11866 Reihe A |
13,00 |
1,50 |
DN 10 |
R.A |
DIN 11866 Reihe A |
19,00 |
1,50 |
DN 15 |
R.A |
DIN 11866 Reihe A |
23,00 |
1,50 |
DN 20 |
R.A |
DIN 11866 Reihe A |
29,00 |
1,50 |
DN 25 |
R.A |
DIN 11866 Reihe A |
35,00 |
1,50 |
DN 32 |
R.A |
DIN 11866 Reihe A |
41,00 |
1,50 |
DN 40 |
R.A |
DIN 11866 Reihe A |
53,00 |
1,50 |
DN 50 |
R.A |
DIN 11866 Reihe A |
70,00 |
2,00 |
DN 65 |
R.A |
DIN 11866 Reihe A |
85,00 |
2,00 |
DN 80 |
R.A |
DIN 11866 Reihe A |
104,00 |
2,00 |
DN 100 |
R.A |
DIN 11866 Reihe A |
129,00 |
2,00 |
DN 125 |
R.A |
DIN 11866 Reihe A |
154,00 |
2,00 |
DN 150 |
R.A |
DIN 11866 Reihe A |
204,00 |
2,00 |
DN 200 |
R.A |
DIN 11866 Reihe A |
DIN 11866 Range B / 304L – 316L
OUTSIDE DIAMETER (MM) |
WALL- THICKNESS (MM) |
NOMINAL OUTSIDE DIAMETER |
NOMINAL WALL THICKNESS |
DIMENSIONAL STANDARD |
10,20 |
1,60 |
DN 6 |
R,B |
DIN 11866 Reihe B |
13,50 |
1,60 |
DN 8 |
R,B |
DIN 11866 Reihe B |
17,20 |
1,60 |
DN 10 |
R,B |
DIN 11866 Reihe B |
21,30 |
1,60 |
DN 15 |
R,B |
DIN 11866 Reihe B |
26,90 |
1,60 |
DN 20 |
R,B |
DIN 11866 Reihe B |
33,70 |
2,00 |
DN 25 |
R,B |
DIN 11866 Reihe B |
42,40 |
2,00 |
DN 32 |
R,B |
DIN 11866 Reihe B |
48,30 |
2,00 |
DN 40 |
R,B |
DIN 11866 Reihe B |
60,30 |
2,00 |
DN 50 |
R,B |
DIN 11866 Reihe B |
76,10 |
2,00 |
DN 65 |
R,B |
DIN 11866 Reihe B |
88,90 |
2,30 |
DN 80 |
R,B |
DIN 11866 Reihe B |
114,30 |
2,30 |
DN 100 |
R,B |
DIN 11866 Reihe B |
139,70 |
2,60 |
DN 125 |
R,B |
DIN 11866 Reihe B |
168,30 |
2,60 |
DN 150 |
R,B |
DIN 11866 Reihe B |
219,10 |
2,60 |
DN 200 |
R,B |
DIN 11866 Reihe B |
DIN 11866 Range C / 304L – 316L
OUTSIDE DIAMETER (MM) |
WALL- THICKNESS (MM) |
NOMINAL OUTSIDE DIAMETER |
NOMINAL WALL THICKNESS |
DIMENSIONAL STANDARD |
6,35 |
0,89 |
DN 8 |
R,C |
DIN 11866 Reihe C |
9,53 |
0,89 |
DN 10 |
R,C |
DIN 11866 Reihe C |
12,70 |
1,65 |
DN 15 |
R,C |
DIN 11866 Reihe C |
19,05 |
1,65 |
DN 20 |
R,C |
DIN 11866 Reihe C |
25,40 |
1,65 |
DN 25 |
R,C |
DIN 11866 Reihe C |
38,10 |
1,65 |
DN 40 |
R,C |
DIN 11866 Reihe C |
50,80 |
1,65 |
DN 50 |
R,C |
DIN 11866 Reihe C |
63,50 |
1,65 |
DN 65 |
R,C |
DIN 11866 Reihe C |
76,20 |
1,65 |
DN 80 |
R,C |
DIN 11866 Reihe C |
101,60 |
2,11 |
DN 100 |
R,C |
DIN 11866 Reihe C |
152,40 |
2,77 |
DN 150 |
R,C |
DIN 11866 Reihe C |
Supply Cut to length ASTM A270 S2 Sanitary Tubes in all sizes as per Client requirement, see dimensions
Sizes chart of SS Sanitary Tubes
Tube OD |
Product Type |
Thikness |
Grade |
1/2 |
SS Sanitary Tube |
0.065 |
304 |
1/2 |
Sanitary Tubing |
0.065 |
316 |
3/4 |
Stainless Steel Sanitary Tubing |
0.065 |
304 |
3/4 |
Sanitary Stainless Tubing |
0.065 |
316 |
1 |
SS Sanitary Tube |
0.065 |
304 |
1 |
Sanitary Tubing |
0.065 |
316 |
1 1/2 |
Stainless Steel Sanitary Pipe |
0.065 |
304 |
1 1/2 |
Sanitary Stainless Tubing |
0.065 |
316 |
2 |
Sanitary Stainless Pipe |
0.065 |
304 |
2 |
Stainless Steel Sanitary Tubing |
0.065 |
316 |
2 1/2 |
Sanitary Tubing |
0.065 |
304 |
2 1/2 |
Stainless Steel Sanitary Tubing |
0.065 |
316 |
3 |
Sanitary Stainless Tubing |
0.065 |
304 |
3 |
SS Sanitary Tube |
0.065 |
316 |
4 |
Sanitary Tubing |
0.083 |
304 |
4 |
Stainless Steel Sanitary Pipe |
0.083 |
316 |
6 |
Sanitary Stainless Tubing |
0.109 |
304 |
6 |
Sanitary Stainless Pipe |
0.109 |
316 |
8 |
Stainless Steel Sanitary Tubing |
0.109 |
304 |
8 |
Sanitary Tubing |
0.109 |
316 |
Do you belong to following locations Please see what we supply here
Chile, Philippines, Iran, Canada |
38*1.5mm Food Grade Sanitary 304/316L Stainless Steel Tube |
United Arab Emirates (UAE), Europe, Norway, Romania |
Stainless Steel Sanitary Triclamp Tube End Cap |
Netherlands, Sweden, Russia, Malaysia |
Food Grade 304 304L 316 316L 310S 321 Sanitary Seamless Stainless Steel Tube |
Egypt, Malaysia, Mexico, Los Alamos -Mexico |
Polished Stainless Steel Seamless Sanitary Tube |
United Kingdom -UK, Singapore, Malaysia, NY 12203 (USA) |
Sanitary Stainless Steel Welded Tubes Inner Polished 320g |
UK, Dammam -KSA, Poland, Philippines |
Sanitary Stainless Steel 304 Tube |
Singapore, Qatar, Malaysia, Europe |
Tp316 Seamed Stainless Steel Sanitary Grade Tube for Evaporator Concentrator |
Malaysia, Czechia, Japan, Thailand |
SS 304 Food Grade Stainless Steel Sanitary Welded Tube |
China, Malaysia, Colombia, Bangladesh |
316L 304 Mirror Polished Stainless Steel Pipe Sanitary Tube |
Philippines, South Africa, Taiwan, Kuwait |
A312/A270 Annealed 3A Stainless Steel Sanitary Tube/Square Tube |
Malaysia, Bahrain, South Korea, Singapore |
Stainless Steel Sanitary Pipe and Tube |
Belgium, Philippines, Indonesia, UK |
ASTM A213 TP304L Sanitary Grade Stainless Steel Pipe Steel Tube |
Thailand, Oman, France, Hong Kong |
Sanitary Spool Tube with Clamp Ends, Stainless Steel 304 |
Turkey, Malaysia, Germany |
Stainless Steel Sanitary Welded Tube for Beer Industry |
Finland, Dubai, USA, Malaysia |
ASTM A270 Bright Annealed TP304 Sanitary Seamless Stainless Steel Tube |
Brazil, UK, Saudi Arabia (KSA), Spain |
Medical Sanitary Food Grade Welded Small Diameter Thin Wall Round Seamless Stainless Steel Capillary Tube |
Singapore, UAE, South Africa, Europe |
Sanitary Welded Stainless Steel Tube |
Nigeria, Ellington -United States, Australia, Canada |
Food Grade Stainless Steel Sanitary Shell and Heat Exchanger Copper Tubes |
UAE, Singapore, Malaysia, Italy |
Sanitary Grade 201 304 316 Polished Brushed Mirror Stainless Steel Square Pipe/Tube |
Stainless Steel Seamless Sanitary Tube Pressure Rating
AVE. WALL INCHES |
MIN YIELD STRENGTH (PSI) |
MIN TENSILE STRENGTH (PSI) |
THEORETICAL BURST PRESSURE * (PSI) |
WORKING PRESSURE (PSI) 25% OF BURST |
THEORETICAL YIELD POINT ** (PSI) |
COLLAPSE PRESSURE *** (PSI) |
|
0.250 |
0.020 |
30,000 |
75,000 |
14,286 |
3,571 |
5,714 |
4,416 |
0.250 |
0.028 |
30,000 |
75,000 |
21,649 |
5,412 |
8,660 |
5,967 |
0.250 |
0.035 |
30,000 |
75,000 |
29,167 |
7,292 |
11,667 |
7,224 |
0.250 |
0.049 |
30,000 |
75,000 |
48,355 |
12,089 |
19,342 |
9,455 |
0.250 |
0.065 |
30,000 |
75,000 |
81,250 |
20,313 |
32,500 |
11,544 |
0.375 |
0.020 |
30,000 |
75,000 |
8,955 |
2,239 |
3,582 |
3,029 |
0.375 |
0.028 |
30,000 |
75,000 |
13,166 |
3,292 |
5,266 |
4,145 |
0.375 |
0.035 |
30,000 |
75,000 |
17,213 |
4,303 |
6,885 |
5,077 |
0.375 |
0.049 |
30,000 |
75,000 |
26,534 |
6,634 |
10,614 |
6,816 |
0.375 |
0.065 |
30,000 |
75,000 |
39,796 |
9,949 |
15,918 |
8,597 |
0.500 |
0.020 |
30,000 |
75,000 |
6,522 |
1,630 |
2,609 |
2,304 |
0.500 |
0.028 |
30,000 |
75,000 |
9,459 |
2,365 |
3,784 |
3,172 |
0.500 |
0.035 |
30,000 |
75,000 |
12,209 |
3,052 |
4,884 |
3,906 |
0.500 |
0.049 |
30,000 |
75,000 |
18,284 |
4,571 |
7,313 |
5,304 |
0.500 |
0.065 |
30,000 |
75,000 |
26,351 |
6,588 |
10,541 |
6,786 |
0.500 |
0.083 |
30,000 |
75,000 |
37,275 |
9,319 |
14,910 |
8,307 |
0.625 |
0.020 |
30,000 |
75,000 |
5,128 |
1,282 |
2,051 |
1,859 |
0.625 |
0.028 |
30,000 |
75,000 |
7,381 |
1,845 |
2,953 |
2,568 |
0.625 |
0.035 |
30,000 |
75,000 |
9,459 |
2,365 |
3,784 |
3,172 |
0.625 |
0.049 |
30,000 |
75,000 |
13,947 |
3,487 |
5,579 |
4,335 |
0.625 |
0.065 |
30,000 |
75,000 |
19,697 |
4,924 |
7,879 |
5,591 |
0.625 |
0.083 |
30,000 |
75,000 |
27,124 |
6,781 |
10,850 |
6,910 |
0.625 |
0.095 |
30,000 |
75,000 |
32,759 |
8,190 |
13,103 |
7,734 |
0.625 |
0.109 |
30,000 |
75,000 |
40,172 |
10,043 |
16,069 |
8,639 |
0.750 |
0.028 |
30,000 |
75,000 |
6,052 |
1,513 |
2,421 |
2,156 |
0.750 |
0.035 |
30,000 |
75,000 |
7,721 |
1,930 |
3,088 |
2,669 |
0.750 |
0.049 |
30,000 |
75,000 |
11,273 |
2,818 |
4,509 |
3,664 |
0.750 |
0.065 |
30,000 |
75,000 |
15,726 |
3,931 |
6,290 |
4,749 |
0.750 |
0.083 |
30,000 |
75,000 |
21,318 |
5,330 |
8,527 |
5,905 |
0.750 |
0.095 |
30,000 |
75,000 |
25,446 |
6,362 |
10,179 |
6,637 |
0.750 |
0.109 |
30,000 |
75,000 |
30,733 |
7,683 |
12,293 |
7,453 |
0.750 |
0.120 |
30,000 |
75,000 |
35,294 |
8,824 |
14,118 |
8,064 |
0.875 |
0.020 |
30,000 |
75,000 |
3,593 |
898 |
1,437 |
1,340 |
0.875 |
0.028 |
30,000 |
75,000 |
5,128 |
1,282 |
2,051 |
1,859 |
0.875 |
0.035 |
30,000 |
75,000 |
6,522 |
1,630 |
2,609 |
2,304 |
0.049 |
30,000 |
75,000 |
9,459 |
2,365 |
3,784 |
3,172 |
|
0.875 |
0.065 |
30,000 |
75,000 |
13,087 |
3,272 |
5,235 |
4,126 |
0.875 |
0.083 |
30,000 |
75,000 |
17,560 |
4,390 |
7,024 |
5,152 |
0.875 |
0.095 |
30,000 |
75,000 |
20,803 |
5,201 |
8,321 |
5,807 |
0.875 |
0.109 |
30,000 |
75,000 |
24,886 |
6,221 |
9,954 |
6,543 |
0.875 |
0.120 |
30,000 |
75,000 |
28,346 |
7,087 |
11,339 |
7,100 |
1.000 |
0.028 |
30,000 |
75,000 |
4,449 |
1,112 |
1,780 |
1,633 |
1.000 |
0.035 |
30,000 |
75,000 |
5,645 |
1,411 |
2,258 |
2,027 |
1.000 |
0.049 |
30,000 |
75,000 |
8,149 |
2,037 |
3,259 |
2,796 |
1.000 |
0.065 |
30,000 |
75,000 |
11,207 |
2,802 |
4,483 |
3,647 |
1.000 |
0.083 |
30,000 |
75,000 |
14,928 |
3,732 |
5,971 |
4,567 |
1.000 |
0.095 |
30,000 |
75,000 |
17,593 |
4,398 |
7,037 |
5,159 |
1.000 |
0.109 |
30,000 |
75,000 |
20,908 |
5,227 |
8,363 |
5,827 |
1.000 |
0.120 |
30,000 |
75,000 |
23,684 |
5,921 |
9,474 |
6,336 |
1.000 |
0.134 |
30,000 |
75,000 |
27,459 |
6,865 |
10,984 |
6,963 |
1.250 |
0.035 |
30,000 |
75,000 |
4,449 |
1,112 |
1,780 |
1,633 |
1.250 |
0.049 |
30,000 |
75,000 |
6,380 |
1,595 |
2,552 |
2,260 |
Stainless Steel Sanitary Seamless Tube Hs Code
HS Code |
Description |
73269099 |
STAINLESS STEEL FITTING CSE BRAND FOR EXHIBITORS-SMS A270 SANITARY WELDED TUBING L=400.0mm ID/OD POLISHED |
73269099 |
STAINLESS STEEL FITTING CSE BRAND FOR EXHIBITORS-D11850-2 A270 SANITARY WELDED TUBING L=400.0mm ID/OD POLISHED |
73069090 |
A55800014G0002004W BPE WLD TUBING 1.65T SF4 2 316L (STAINLESS STEEL SANITARY FITINGS) |
73069090 |
A55800014G0001504W BPE WLD TUBING 1.65T SF4 11/2 316L (STAINLESS STEEL SANITARY FITINGS) |
73072900 |
A55800014G0000754T BPE SML TUBING 1. 65T SF4 3/4 316L (STAINLESS STEEL SANITARY FITINGS) |
73072900 |
A55800014G0001004W BPE WLD TUBING 1. 65T SF4 1 316L (STAINLESS STEEL SANITARY FITINGS) |
73069090 |
A55800014G0001004W BPE WLD TUBING 1.65T SF4 1 316L PIPE SML, SS316L, (STAINLESS STEEL SANITARY FITINGS) |
73069090 |
A5580014G0000504T BPE SML TUBING 1.65T SF4 1/2 316L PIPE,SMLS,SS316L, (STAINLESS STEEL SANITARY FITINGS) |
Food-grade Stainless Steel Tubing Chemical Composition
Element |
304 (wt%) |
316L (wt%) |
Carbon (max) |
0.035 |
0.035 |
Manganese (max) |
2.00 |
2.00 |
Phosphorus (max) |
0.040 |
0.040 |
Sulfur (max) |
0.030 |
0.030** |
Silicon (max) |
0.75 |
0.75 |
Nickel |
8.0 – 13.0 |
10.0 – 15.0 |
Chromium |
18.0 – 20.0 |
16.0 – 18.0 |
Molybdenum |
N/A |
2.0 – 3.0 |
Iron |
Balance |
Balance |
Copper |
N/A |
N/A |
Nitrogen |
N/A |
N/A |
Mechanical Properties of Stainless Steel Sanitary Tube
Material |
Heat |
Temperure |
Tensile Strength |
Yield Strength |
Elongation %, Min |
Treatment |
Min. |
Ksi (MPa), Min. |
Ksi (MPa), Min. |
||
º F(º C) |
|||||
TP304 |
Solution |
1900 (1040) |
75(515) |
30(205) |
35 |
TP304L |
Solution |
1900 (1040) |
70(485) |
25(170) |
35 |
TP316 |
Solution |
1900(1040) |
75(515) |
30(205) |
35 |
TP316L |
Solution |
1900(1040) |
70(485) |
25(170) |
35 |
Equivalent Grades of ASTM A270 Sanitary Tubing
GRADE |
UNS NO |
DIN/ WERKSTOFF |
Stainless Steel Sanitary Tube 304 |
S30400 |
1.4301 |
304L |
S30403 |
1.4306 |
Stainless Steel Sanitary Tube 316 |
S31600 |
1.4436 |
316L |
S31603 |
1.4404 |
Send Inquiry to This Supplier
You May Also Like
-
Stainless Steel Bar Stainless Super Duplex Bar Duplex Steel Uns S32760 S32750 2507 ASTM A789NegotiableMOQ: 1 Ton
-
ASTM A789 General Purpose Ferritic/austenitic Stainless Steel Seamless and Welded Steel PipesNegotiableMOQ: 1 Ton
-
ASTM A778/A789/A358 Welded Stainless Steel Pipe for Chemical/Petroleum 1/4\" 3/8\" 1/2\"NegotiableMOQ: 1 Ton
-
ASTM A778/A789/A358 Welded Stainless Steel Pipe for Chemical/Petroleum 1/4\" 3/8\" 1/2\"NegotiableMOQ: 1 Ton
-
ASTM A789 General Purpose Ferritic/austenitic Stainless Steel Seamless and Welded Steel PipesNegotiableMOQ: 1 Ton
-
150mm Diameter ASTM A789 Uns32750/2507 Welded Rectangular 50mm 304 2mm Thickness Small StainlesNegotiableMOQ: 1 Ton
-
ASTM A789 Stainless Steel Welded Tube for High Pressure Heat ExchangerNegotiableMOQ: 1 Ton
-
High Quality Titanium Alloy Welded Pipe Special Steel Products With Cutting Service Outer Diameter From 12.7mm to 325mm Industry Price Good ServiceNegotiableMOQ: 100000 Tons
-
Ss 310S 316ti 904L 904 2205 2507 317 8K Stainless Steel Pipe/Square/Round/Seamless Steel Pipe/Welded/Galvanized/Titanium AlloyNegotiableMOQ: 100000 Tons
-
ASTM B622 Hastelloy C276 Seamless Tube Wooden Box Packing, Cardboard Boxes, Plastic Wrapping, Using Hardened Paper With PE Meshing From FactoryNegotiableMOQ: 1 Ton
