Product Description:
This Roll To Sheet Cutting Machine is suitable for heat shrinkable casing, PVC casing, fiberglass tube, PE tube, silicone pipe, electrolytic capacitor PVC sleeve, PVC plastic belt, wire line, plastic hose, nylon tube, tube, insulating paper, Mica, Myra, diffusion sheet, rubber sheet, silicon film, stickers, wallpaper, kraft paper, Barley paper, Fast bar paper, off-type paper, insulating paper, plastic belt, packing tape, copper foil, copper belt, Nickel belt, non-weaving, acetic acid cloth, conductive cloth, cotton yarn belt, elastic belt, magic sticker, zipper and other ribbon or film (tube) shape and other fixed long cutting can be.
Machine Features:
High-speed automatic feeding, by microcomputer program control accuracy up to 0.1mm.
Both Automatic and manual operation, can forward feed or back, and can be manually cut off .
With forward back function, automatic counting, to several downtime, power outage to save memory function
Mirco control Computer pipe cutting machine cutter speed adjustable, full Chinese liquid crystal display
The cutting length and speed of the computer pipe cutting machine can be adjusted arbitrarily and continuously
Computer pipe cutting machine automatic grouping accumulation and total cumulative count
Batch suspension and delay time can be set
Can be fully automatic cutting of a variety of flake, tubular materials, the machine after the installation of the Feed belt wheel, can be automatically suitable for the ribbon coil plate discharge and feeding
High speed stepper motor precisely control the length of the pipe, the length and speed of the walking belt can be adjusted
The cutting time protection of the computer pipe cutting machine; the total number setting; the sub-set; The suspension time can be adjusted
Computer pipe cutting machine with a variety of manual operation, easy to debug
Computer pipe Cutting Machine LCD large screen intuitive Chinese display, simple and convenient operation
The use of special mechanical structure and special tools, with special software control, to achieve incision level, length accurate
Machine Parameters:
| Cutting Speed | 80M/MIN |
| Cutting Width | 0.1-1500mm |
| Cutting Knife | High speed steel SKD-11 |
| Cutting Length | 0.1-9999.9mm |
| Cutting Motor | AC Reducer Motor |
| Feeding Motor | High Precision Stepper Motor |
| Accuracy | 0.1mm |
Working Video 1: youtu.be/Cm8hEPbZ1i8
Working Video 2: youtu.be/MPu32U5k51I
Working Video 3: youtu.be/GjXsh3G6kTM
