Platinum Vulcanized Steel Wire Silicone Hose
Application: High cleanliness industries such as food, beverages, drinking water, cosmetics, pharmaceuticals, etc
Construction: Type SQ is manufactured from High purity platinum cured Silicone with single stainless steel helix and 4 layers of polyester reinforcement.
Temp. Range: -60°C and 200°C. (+260°C on request)
Colour: Translucent (Coloured covers available)
Smooth inner and outer surface to resist material adhesion
Suitable for pressure and vacuum.
Suitable for CIP and SIP cleaning
Odourless, Tasteless, Non-Toxic
Note: If it is required to use high-temperature steam above 121 ℃ for a long time, it can be customized.
Length: Standard length is 4m, 6m or 10m.
PRESSURE DECREASE BY 1% FOR EVERY 1°C ABOVE 100°C.
| CORD | ID | OD | Bending | W.P | B.P | Vacuum | |
| in. | mm | mm | mm | bar | bar | bar | |
| 006 | 1/4" | 6.4 | 17 | 29 | 13 | 39 | 0.91 |
| 008 | 5/16" | 7.9 | 19 | 31 | 12 | 36 | 0.91 |
| 010 | 3/8" | 9.5 | 21 | 35 | 11 | 33 | 0.91 |
| 013 | 1/2" | 12.7 | 24 | 40 | 10 | 30 | 0.91 |
| 016 | 5/8" | 15.9 | 27 | 50 | 9 | 27 | 0.91 |
| 019 | 3/4" | 19 | 30 | 60 | 8.5 | 25.5 | 0.91 |
| 025 | 1" | 25.4 | 36 | 80 | 7.5 | 22.5 | 0.91 |
| 032 | 1-1/4" | 32 | 43 | 110 | 6.5 | 19.5 | 0.91 |
| 038 | 1-1/2" | 38 | 49 | 160 | 5.5 | 16.5 | 0.91 |
| 045 | 1-3/4" | 45 | 56 | 200 | 5 | 15 | 0.91 |
| 051 | 2" | 50.8 | 63 | 250 | 4.5 | 13.5 | 0.91 |
| 064 | 2-1/2" | 63.5 | 75 | 350 | 4 | 12 | 0.91 |
| 076 | 3" | 76.2 | 88 | 550 | 3 | 9 | 0.91 |
| 089 | 3-1/2" | 89 | 102 | 700 | 2.5 | 7.5 | 0.91 |
| 102 | 4" | 102 | 115 | 800 | 2 | 6 | 0.91 |
