Commercial Aluminum Cans Crusher Steel Crushing Recycling Machine
US$ 7653
≥1 Set
Key Specifications
Get Latest Price
Material:
Alloy
Certification:
CE, ISO9001
Warranty:
1 year
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
15 days
Related Products
-
Waste Car Radiator Crushing Separating Machine Scrap AC Radiator Recycle MachineUS$ 37865MOQ: 1 Set -
Horizontal Oil Drum Dual-Shaft Shredding Line & Pipe CrusherUS$ 12999MOQ: 1 Combo
-
Fully Automatic Motorcycle Dual-Shaft Shredding Equipment & Refrigerator ShredderUS$ 5333 - 53333MOQ: 1 Set
-
High-Efficiency Motorcycle Dual-Shaft Shredding Line & Sheet Metal ShredderUS$ 5333 - 53333MOQ: 1 Set
-
Large-Scale Waste Aluminum Dual-Shaft Shredding Line & Bulky Waste ShredderUS$ 5333 - 53333MOQ: 1 Set
Material
Alloy
Certification
CE, ISO9001
Warranty
1 year
Application
Metal Recycling Machine
Standard
ASTM, GB, ANSI
After-sales Service
Engineer Ready To Serve
Customized
Customized
Condition
New
Transport Package
40HQ Container
Specification
WALLE INDUSTRY
Trademark
WALLE INDUSTRY
Origin
china
Product Description
Metal scrap hammermill shredder metal scrap crusher is for the light material. bulky material or the steel wire scrap to process them into smaller density material through the hammer squezing, rubbing,crashing of hammer and the material, to down size of material, meanwhile to get out the impurities .cut off the cost of transportation, increase the melting ratio. there is fit with jet pulse filter to proect environment.
| Type | power | feeder | rotary | capacity | size | weight |
| PGS-800 | 37-55 KW | 800 mm | 1250 rpm | 0.7-1 t/h | 3800*1600*1800mm | 3.2t |
| PGS-1000 | 45-75 KW | 1000 mm | 1250 rpm | 0.8-1.5t/h | 2560*1800*2200 mm | 7.6t |
| PGS-1300 | 90-150 KW | 1300 mm | 860 rpm | 2-4 t/h | 4000*3500*3200 mm | 11.5-26t |
| PGS-1600 | 200-280 KW | 1600 mm | 750 rpm | 4-6 t/h | 4800*4000*3800 mm | 16.6-35 t |
| PGS-1800 | 220-450 KW | 1800 mm | 650 rpm | 6-10 t/h | 4800*4100*4000 mm | 32-48 t |
| PGS-2000 | 315-630 KW | 2000 MM | 650 rpm | 8-12 T/H | 5000*4500*4300 MM | 35-65 T |
| PGS-2200 | 500-900 KW | 2200 MM | 650 rpm | 15-20 T/H | 5000*4500*4500 MM | 35-65 T |
| PGS-2400 | 1250-2250 KW | 2400 MM | 650 rpm | 20-45 T/H | 6300*4800*4500 MM | 85-120T |
| PGS-2800 | 1600-3000 KW | 2600 MM | 650 rpm | 70-100 T/H | 6400*5200*4800 MM | 145-230T |
| PGS-3000 | 3300-4400 KW | 3000 MM | 650 rpm | 110-140 T/H | 8500*7200*5500 MM | 280-760T |
Features of the hammermill shredder
1.The hammer is made of high maganese
2. construction is robust and durable, dense reinforcement plate to ensure strong box.
3. Liner Special alloy to ensuare in operation and uptime.
4. Ejection device to avoid damage the hammer and electronics.
5. Hydraulic cyclinder to facilitate mechanical maintenance and repair.
6. PLC controller system to confirm the safety
8 the force feeding device, two stage pressing the bulky material to the crushing chamber . improve the processing efficiency. 9.Robust frame and liar to keep continue uptime.
10. Eject design to avoid heavy material damage the core part.
11. Hydraulic cylinder to open caps , which is convenient to speed up offtime.
12. The New hammer design with the cover to expand working hours.
13. The crushing chamber takes the thickness and durable material to reliable and keep Operation hours. 14. expedition of sorting device, Zig zag separator , and drum magnetic separator equipped.
