Light Transmittance Meter DB22-TM275/DB22-TM275P/DB22-TM275P6

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	DUBAN		Place of Origin	China
Model Number	DB22-TM275/DB22-TM275P/DB22-TM275P6		Shape	Other

【Product Descriptions】

Field measurement for automobile manufacturing and testing, glass products, aerospace and other

industries. Measurement of transmittance of protective film, PC, acrylic and other plastic products.

Other transparent or semitransparent material transmittance measurement. (Note: printed, frosted

and milky materials are not suitable for measurement by this machine)

【Product Features】

* Simple operation, fast measurement speed, good sensitivity, high measurement accuracy

* DB22-TM275P/P6 can be connected to a printer to print test data

* Instrument startup automatic calibration and manual calibration

* Large capacity storage, can store 500 measurement data

【Product Specifications】

Model	DB22-TM275	DB22-TM275P	DB22-TM275P6
Points	1	1	6
Printer	×	√	√
Measurement range	0.0%-100%
Measurement quantity	%beam transmission
Thickness of the object to be measured	<30mm
Volume of the measured object	<10mm*10mm
Shutdown mode	Automatic shutdown or manual shutdown can be set
Backlight	LED backlight
Resolution	0.1%
Host size	76mm140mm32mm
Probe size	φ37mm*136mm
Power	4*1.5v AAA(UM-4)
Operating temperature	0°C-40C
operating humidity	<85%
Wavelength range	380nm-780nm
