【Applications】
Widely used in data collection for boiler, refrigeration industry, ventilation duct, environment monitor, navigation measurement, weather forecast, collection of the weather datum for outdoor busywork and fire department.
【Features】
* Multifunctional.the measurement unit can be selected according to different requirements.
* Maximum value data hold function.
* DATA HOLD function for storing 24 groups of datas.
* Low-friction ball-bearing design allows free vane movement.
* Separate type design,convenient to measure.
* Wide applications: use to check air conditioning & heating systems , measure air velocities, wind speeds,temperature etc.
* Auto power shut off.
* Use USB data output and RS-232 data output with connection PC.
* Provide Bluetooth ™ data output choice. -
【Specifications】
Measurement unitAir Flow:CMM(m3/min) CFM(ft3/min) Beaufort scale:Force Direction: °from the North direction Wave Height:m TEMP:℃&℉ Data hold Maximum Value Data memorized 24 groups Sampling rate reading per second approx Sensors Air velocity/flow sensor: 3-cup probe Direction probe: Low friction probe Temperature sensor: Precision thermistor Automatic Power off 0-9 minutes set by users Operating Temperature -10℃ - 60℃(14℉ ~ 140℉) Operating Humidity Max. 80% RH Power Supply 4x1.5AAA size Dimensions Main Unit：140x77x32mm 3-cup probe：65x65x115mm Direction probe：86x69x115mm Weight 310g，including probe 【Range Specifications 】
Air Velocity Range Resolution Accuracy m/s (meters per sec)
0.4-45.0 0.1 m/s ±(2%+0.1m/s)
km/h (kilometers/hour)
1.4~162.0 0.1 km/hr ±(2%+0.1km/h)
ft/min (feet per minute)
80~8860 0.1 ft/min ±(2%+1ft/min)
knots (nautical MPH)
0.8~88.0 0.1knots ±(2%+0.1nots)
Air Flow CMM (cubic meters/min)
0~9999 0.001~1 ±(2%+1m³/min)
CFM (cubic ft/min)
0~9999 0.001~1 ±(2%+1ft³/min)
Beaufort Scale
0~12 0.1 ±0.5 Wave Height(meters) 0~14 0.1 ±0.1 Air Temperature
32~140 ℉ 0.1 ℉ 0.9 ℉ 0~60 ℃ 0.1 ℃ 0.5 ℃
