Titanium Plate Product Detail Page Template
1. Product Overview
Product Name: Titanium Grade X Plate (Gr1/Gr2/Gr5/Gr7/Gr12)Model: Customizable Thickness & SizeMaterial: Pure Titanium Alloy (Grade X)Production Process: Hot Rolling/Cold Rolling/Annealing/PolishingCertifications: ASTM B265 (Gr1/Gr2/Gr5), ISO 9001:2015, Mill Test Certificates
2. Core Advantages
Grade |
Unique Selling Points (USPs) |
Gr1 |
✅ Commercial Pure Titanium (99.5% purity)✅ Excellent formability & corrosion resistance✅ ASTM B265 certified for industrial applications✅ Custom cut to size within 24 hours |
Gr2 |
✅ Annealed for enhanced ductility & weldability✅ ISO 9001:2015 certified factory✅ 5,000+ tons in stock for immediate shipment✅ Mill finish (Ra≤12.5μm) for easy machining |
Gr5 |
✅ Ti-6Al-4V alloy (aerospace grade)✅ High strength (UTS ≥ 1,000 MPa) & temperature resistance (up to 600℃)✅ CNC machining available for precision components✅ AS9100D certified for aerospace supply chain |
Gr7 |
✅ Ti-Pd alloy (0.12-0.25% Pd)✅ Excellent crevice corrosion resistance in seawater/acidic environments✅ Medical-grade polish (Ra≤0.8μm) for implantable devices✅ FDA/CE MDR compliant for medical applications |
Gr12 |
✅ Ti-0.3Mo-0.8Ni alloy (industrial grade)✅ Superior weldability & formability for pipeline projects✅ Mill test certificates provided (chemical composition & mechanical properties)✅ Competitive pricing for bulk orders (≥10 tons) |
3. Technical Specifications
Parameter |
Gr1 |
Gr2 |
Gr5 |
Gr7 |
Gr12 |
Chemical Composition |
Ti≥99.5%, Fe≤0.20% |
Ti≥99.2%, Fe≤0.30% |
Ti-6Al-4V (balance) |
Ti-0.15Pd, Fe≤0.30% |
Ti-0.3Mo-0.8Ni |
Tensile Strength |
≥240 MPa |
≥345 MPa |
≥895 MPa |
≥345 MPa |
≥345 MPa |
Elongation |
≥25% |
≥20% |
≥10% |
≥20% |
≥20% |
Thickness Range |
0.5mm-100mm |
1mm-200mm |
2mm-300mm |
0.5mm-50mm |
3mm-150mm |
Standard Sizes |
ASTM B265, ASME SB-265 |
ASTM B265, GB/T 3621 |
AMS 4928, ASTM B265 |
ASTM B265, ISO 5832-2 |
ASTM B265, JIS H4631 |
Surface Finish |
Mill finish |
Annealed finish |
Rough/Polished finish |
Mirror polish (Ra≤0.2μm) |
Pickled/Brushed finish |
4. Applications
Industrial Manufacturing (Gr1/Gr2/Gr12):Ideal for chemical tanks, heat exchangers, pressure vessels, and structural components in petroleum, metallurgy, and power industries.
Aerospace & Defense (Gr5):Used in aircraft frames, engine parts, landing gear components, and missile structures requiring high strength-to-weight ratio and fatigue resistance.
Medical Devices (Gr7):Suitable for surgical instruments, orthopedic implants (bone plates/screws), and dental prosthetics due to biocompatibility and corrosion resistance.
Marine & Offshore (Gr7/Gr12):Perfect for seawater-resistant applications like ship hulls, offshore pipelines, and desalination equipment.
New Energy (Gr5/Gr12):Used in hydrogen fuel cell bipolar plates, solar panel frames, and wind turbine components requiring lightweight and high-temperature resistance.
5. Certification & Compliance
Quality Assurance:
ISO 9001:2015 certified manufacturing process
100% non-destructive testing (NDT) for critical applications
Mill test certificates (MTC) including chemical composition, mechanical properties, and heat treatment records
Regional Compliance:
North America: ASTM, ASME, ITAR compliant (Gr5)
Europe: CE, REACH registered, UKAS certified
Asia: JIS, GB/T compliant, RoHS compliant
6. Services & Support
Customization Options:✅ Cut to size (tolerance ±0.5mm)✅ Surface treatment (polishing, anodizing, coating)✅ Special packaging (wooden crates for marine shipping)✅ OEM/ODM logos etching (minimum order 5 tons)
Order & Delivery:
MOQ: 1 ton (negotiable for samples)
Lead Time: 7-15 days for standard orders; 20-30 days for customized specifications
Shipping: FOB/CIF/DDP available; global logistics partners (DHL, Maersk, FedEx)
After-Sales:
2-year warranty against material defects
24/7 technical support (engineering team available for material selection advice)
Free sample testing (up to 3 pieces per grade)
7. Why Choose Us?
Direct Manufacturer: 15+ years of titanium processing experience; no middleman markup.
Stock Availability: 10,000+ tons of raw materials in inventory for fast turnaround.
Testing Capabilities: In-house lab for chemical analysis (ICP-MS), tensile testing, and corrosion resistance testing.
Global Footprint: Served 500+ clients in 30+ countries, including Boeing, Medtronic, and Shell.
8. Call to Action (CTA)
� Request a Quote: Send us your size/quantity requirements for an exclusive factory price!
� Contact Us: Click "Inquire Now" to discuss customization, samples, or bulk discounts.
� Download Catalog: Get detailed datasheets and certification files for all titanium grades.
9. Packaging & Shipping
Packaging:
Inner: Plastic film wrapping to prevent scratches
Outer: Wooden pallets with steel strapping (suitable for container shipping)
Port of Loading: Shanghai/Ningbo/Tianjin, China
Delivery Time:
Samples: 3-7 days via express (DHL/UPS)
Bulk orders: 2-4 weeks via sea freight
10. Frequently Asked Questions (FAQs)
Q1: Can I get a sample before placing a bulk order?A: Yes, free samples (100x100mm) are available upon request; shipping cost is buyer’s responsibility.
Q2: What payment terms do you accept?A: T/T (30% deposit, 70% before shipment), L/C at sight, Western Union, PayPal (for samples).
Q3: Do you provide third-party inspection reports?A: Yes, we can arrange SGS/BV inspection at an additional cost; contact us for details.
