Six-station Holding Press Machine Cell Phone Case Holding Equipment Cell Phone Holder Cold Pressing Holding Equipment After Dispensing

1、Equipment specifications and technical parameters:

Equipment name: six-station keeping pressure machine

Overall dimensions: 350 (H) * 300 (W) * 800 (L) mm

Allowable range of pressure: 1~8Mpa

Working voltage: 24V DC

Working Temperature: -10-60°C

Storage temperature：-40℃-70℃

Working humidity: 40%-80

2, equipment use method:

First of all, make sure the power supply and gas source is connected, turn on the power switch, check whether the air pressure value of the filter pressure gauge is normal or not (generally 3~4Mpa), and put the timer on.

3~4Mpa), adjust the timer to the required pressure maintaining time, then turn on the press fit switch of the press fit station, put the bonded products on the top of the press fit fixture, and put the bonded products on the top of the press fit fixture.

Next, turn on the press switch of the press fitting station, put the bonded product on the top of the press fitting, and then push the press fitting inward until it reaches the trigger switch, and then the press fitting cylinder will press downward on its own.

Note: Hands should not be placed on top of the product to avoid pressure injury!
