SOIL LOAD PENETROMETER & GROUND BEARING CAPACITY DETECTOR DB25-207DJ

SOIL LOAD PENETROMETER & GROUND BEARING CAPACITY DETECTOR DB25-207DJ thumbnail-1
SOIL LOAD PENETROMETER & GROUND BEARING CAPACITY DETECTOR DB25-207DJ thumbnail-2
SOIL LOAD PENETROMETER & GROUND BEARING CAPACITY DETECTOR DB25-207DJ thumbnail-3
SOIL LOAD PENETROMETER & GROUND BEARING CAPACITY DETECTOR DB25-207DJ thumbnail-4
SOIL LOAD PENETROMETER & GROUND BEARING CAPACITY DETECTOR DB25-207DJ thumbnail-5
SOIL LOAD PENETROMETER & GROUND BEARING CAPACITY DETECTOR DB25-207DJ photo-1
SOIL LOAD PENETROMETER & GROUND BEARING CAPACITY DETECTOR DB25-207DJ photo-2
SOIL LOAD PENETROMETER & GROUND BEARING CAPACITY DETECTOR DB25-207DJ photo-3
SOIL LOAD PENETROMETER & GROUND BEARING CAPACITY DETECTOR DB25-207DJ photo-4
SOIL LOAD PENETROMETER & GROUND BEARING CAPACITY DETECTOR DB25-207DJ photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
DUBAN
Place of Origin:
China
Model Number:
DB25-207DJ
Contact Supplier Request Quote Chat Now
Guangdong Duban Technology Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
3 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name DUBAN
Place of Origin China
Model Number DB25-207DJ

  • 【Product Descriptions】

    Universal type penetrometer is based on the geotechnical experiment: the penetration of soil and the dry density of soil,

    the relationship between the relationship between the penetration and water content of soil and the relationship between soil water volume and compactness, through a lot of penetration and ring cutting parallel contrast test And establish the regression equation, the rate of penetration resistance between the dry density and the related data sheet. By measuring the penetration resistance and looking up the table, the dry density

    can be quickly obtained, and then the compaction coefficient can be quickly calculated. Two, main technical parameters



  • 【Product Features】

    * High accuracy and high resolution.

    * With 4 measurement unit for selection and conversion, kgf, gf, N, Lbf

    * With peak value hold function.

    * can memorize 99 groups of data.

    * Digital display with no guessing or errors.

    * With 10 minutes auto power off and manual power off.

    * Either alkaline battery Power supply or 5V DC power.

    * Use USB cable or Bluetooth adapter for data output.


    【Product Specifications】


    Measuring range 0kg-100kg (0N-1000N)
    Test depth

    0cm-30cm
    Material tested all kinds of backfill soil, clay, sand and mixed soil after rolling
    Application environment

    highway, railway, reservoir, dike, dam and civil building, etc
    Power 2 AA batteries(5 V dc matching)
    Accuracy of the test ≤0.25%
    Weight (excluding battery)

    instrument 415g, handle 295g,proberod 380g.


Product Tags: SOIL LOAD PENETROMETER , GROUND BEARING CAPACITY DETECTOR , Measurement & Analysis Instruments
