Help CenterAPI5CT 5.5in TenarisBlue Casing 8.05-12.7mm Range
Related Products
-
6.625in API5CT MetalSeal Gas Casing 9.19mm ThickUS$ 390MOQ: 1 Metric Ton -
7in API5CT ExtremeGrip Casing 10.36mm WallUS$ 400MOQ: 1 Metric Ton
-
4.5in Premium Casing: 5.21-15.88mm WT, J55/K55US$ 410MOQ: 1 Metric Ton
-
5in Hydril511 Casing, 7.52mm WT, API-CertifiedUS$ 420MOQ: 1 Metric Ton
-
5.5in TenarisBlue Tech Casing, 8.05-12.7mmUS$ 430MOQ: 1 Metric Ton
Product 3: 20" (508.0mm) API5CT P110 Offshore Platform Casing
Wall Thickness: 20.62mm
Material: Mo-Enhanced High-Strength Steel (P110 Grade)
Design Code: API RP 2RD (Offshore Application)
Critical Parameters:
· Yield Strength: 758–965 MPa
· Charpy Impact Value: ≥75J @ -10°C
· Dimensional Tolerance:
o OD: ±0.75% | WT: +15%/-12.5% (API 5CT Table 8)
Deployment Scenarios:
· Subsea wellhead systems in 500m+ water depth
· Saltwater cementing with CRA (Corrosion Resistant Alloy) clad
Packaging & Logistics:
· VCI+PE Composite Wrap (ISO 21809-2)
· 40-day Lead Time (FOB Qingdao Port)
Advantages/Features:
1.Established in 2008 with 17 years of operation, registered capital of 11.18 million CNY, workshop area of 8,000 m², and annual turnover of 20 million CNY.
2.Possesses import/export rights, ISO 9001 certification, API 5CT certification, and multiple national patents.
3.Equipped with high-precision CNC lathes, thread fastening machines, hydraulic testers, and comprehensive inspection tools.
4.Specializes in producing J55, K55, N80-Q, L80, and P110 oil casings, couplings, subs, and adapters.
5.Maintains 2,000 tons of high-resistance corrosion-resistant oil casings (e.g., 80S, 90S, 110S, L80-1Cr/3Cr/13Cr) in stock.
6.Offers custom threading (e.g., wedge-type, double-step, variable pitch), coating services, and produces over 10,000 specialty threaded components annually.
| OD (inch/mm) | Wall Thickness Range (mm) | Typical Chemical Composition | Application Scenarios |
| 4½" (114.3mm) | 5.21-15.88 | C 0.34-0.39%, Mn 1.25-1.50% (J55/K55) | Shallow oil wells, low-pressure gas wells |
| 5" (127.0mm) | 5.59-12.70 | C 0.34-0.38%, Mn 1.45-1.70% (N80) | Medium-depth wells, conventional oil/gas |
| 5½" (139.7mm) | 6.20-22.22 | C 0.15-0.22%, Cr 12-14% (L80-13Cr) | Sour gas wells, hydrogen sulfide (H₂S) environments |
| 6⅝" (168.3mm) | 7.32-12.06 | C 0.26-0.35%, Mo 0.15-0.25% (P110) | Deep wells, high-pressure gas reservoirs |
| 7" (177.8mm) | 8.05-12.70 | C 0.34-0.38%, Mn 1.45-1.70% (N80) | Shale gas horizontal wells, fracturing operations |
| 9⅝" (244.5mm) | 8.94-12.70 | C 0.15-0.22%, Cr 12-14% (L80-13Cr) | Ultra-deep wells, high-temperature/pressure reservoirs |
| 13⅜" (339.7mm) | 15.88 | C 0.34-0.39%, Mn 1.25-1.50% (J55/K55) | Surface casing, shallow cementing |
| 20" (508.0mm) | 20.62 | C 0.26-0.35%, Mo 0.15-0.25% (P110) | Offshore platform wells, large-diameter well completions |
Product Name: API-5CT Seamless Casing and Tubing
Steel Grade: J55, N80, P110, H40, K55, L80, L80-3Cr/9Cr/13Cr, M65, C90, T95, Q125
Material: 34CrMo4, H40, J55, K55, N80, L80, M65, C90, T95, P110, Q125
Standard: API 5CT/ISO 11960
Technique: Cold Drawn/Hot Rolled
Application: Oil and Gas Pipes
Outer Diameter Ranges:
Tubing: 48.26mm~114.3mm (1.05 inches~4 1/2 inches)
Casing: 114.3mm~762mm (4 1/2 inches~30 inches)
Wall Thickness: 2.87mm~30mm (compliant with API 5CT standards)
Length Ranges:Tubing:
R1: 6.10m~7.32m
R2: 8.53m~9.75m
R3: 11.58m~12.80m
Casing:
R1: 4.88m~7.62m
R2: 7.62m~10.36m
R3: 10.36m~14.63m
End-Finish Types:Tubing: P, I, N, U
Casing: P, S, B, L
Product Features:
Material Optimization:
Cr-Mo series steel with precise chemical composition control ensures resistance to Sulfide Stress Corrosion Cracking (SSCC).
Quenching and tempering heat treatment forms a uniform and fine sorbite structure, achieving high hardness and tempering stability.
Heat Treatment Process:
Strict temperature-controlled quenching and tempering guarantee consistent mechanical properties, narrow yield strength ranges, and controllable hardness.
Sulfide Corrosion Resistance:
Microstructure of fully tempered martensite is suitable for H₂S-containing acidic oil and gas environments.
Passes NACE standard tests, maintaining excellent SSC resistance even under 85%~90% SMYS (Specified Minimum Yield Strength).
Inspection Standards:
Non-destructive Testing:
Full-body inspection for longitudinal/transverse defects on inner and outer surfaces, with standard notch depth ≤5% of wall thickness.
Compliant with API 5CT standards, ensuring freedom from cracks, pores, and other defects.
Packaging & Delivery:
Packaging: Seawater-resistant steel shelves, iron pallets, or customized solutions per customer requirements.
Delivery Time: 20–55 days (varies based on order size and process complexity).
Minimum Order Quantity (MOQ): 20 tons.
Application Scenarios:
Sour Oil and Gas Fields: High-corrosion environments with H₂S and CO₂.
Deep/Ultra-Deep Wells: Resistant to high pressure and temperatures (up to 200°C+).
Cementing and Workover: Supports wellbore stability and isolates formation fluids.
Certification & Surface Treatment:
Certification: API pipe certification.
Surface Treatment: Black paint, varnish coating; cross-sectional shape: round.
Origin: China.
Note: This product is non-secondary processed and supports customization. Contact the supplier for technical agreements.
Tianjin Grand Victory Petroleum Equipment Co., Ltd. is a comprehensive enterprise for production, processing, sales, technology research and development, and spot storage. Located in Jinghai District, Tianjin, China, it was founded in 2008 with a registered capital of 11.18 million yuan. It has import and export rights, ISO9001 quality system certification, American Petroleum Institute API 5CT certification and a number of national patent certificates. The production workshop is equipped with several types of equipment such as highprecision CNC lathes, thread tightening machines, hydraulic presses, etc., and complete inspection and measurement instruments. Products includewww.longkailai.com
