Laser Particle Counter ND-6330S
Laser particle counter ND-6300(1CFM/ 28.3L/min or 50L/min) is a kind of instrument used to measure the size and quantity of dust particles in unit volume air of clean environment, which can directly detect A and D class clean environment. With features of using diode laser light source, large touch-screen display, small size, light weight, high precision, simple operation, microprocessor control, storing & printing the measurement results and so on, this product is widely used in electronics, optical, chemical, food, cosmetics, health,biological products,aerospace, etc.
User friendly interface-color touch screen operation, stainless steel shell, no buttons, easy to clean.
Small size,light weight-portable and easy to transport
Low noise fan, with a theoretical lifespan of 20000 hours
Automatic flow regulation function
6 channels display
95% UCL calculation, automatic determination of cleanliness level
Capable of printing, storing, and U disk output
Optional accessories ,such as compressed air (e.g. GC101, etc.)
Audit tracking function（optional）
Model | ND-6330S
| |
FLow Rate | 28.3L/min | |
Channel | 0.3,0.5,1.0,3.0,5.0,10.0μm | |
Overall dim.(cm) | 23x 18x 18cm（WxDxH） | |
Display | 7-inch ultra large LCD display screen | |
Weight(approx.） | 4.5kg | |
Standard | Automatic calculation, C-GMP ,EU-GMP,GMP（2010）、ISO-14644-1:2015,ISO14644-11999 total 7 types | |
Cycle | 0-9999sec
| |
Zero Count | ≤10min | |
Printer | Built-in Thermal Printer | |
Power Supply | DC 12.6V built-in battery
| |
Power | 50W
| |
Maximum sampling concentration | 35000 P/L
| |
Working Time
| 10 hours | |
Light source and lifetime | Semiconductor laser (with a lifespan greater than 30000 hours) | |
Storage
| Sampling 8000 | Report 800
|
Environmental condition
| Temperature10℃-35℃,Humidity20%-75%,Pressure 86kPa-106kPa | |
