Description
A pinching machine that uses pressure to deform metal and stamp it into various required structures. The functions of a punch press include punching and shearing, metal material forming, deep drawing, and forging metal.
Application
It is usually used in conjunction with a mold and is an important equipment for producing metal mechanical parts.
Technical parameter
Type |
J23-80T |
|
Nominal Pressure（kn） |
800 |
|
Nominal Pressure Stroke（mm） |
8 |
|
Ram Stroke（mm） |
120 |
|
Slipper stroke times（t/min) |
50 |
|
Max Closing Height（mm） |
380 |
|
Closing Height Adjuster（mm） |
100 |
|
Distance between slipper centre and machine（mm） |
260 |
|
Work bench dimension |
Front to back (mm) |
480 |
Right to left (mm) |
750 |
|
Diameter of blank-holding hole |
Front to back(mm) |
220 |
Right to left (mm) |
340 |
|
Diameter(mm) |
190 |
|
Slipper underside bore |
Front to back (mm) |
240 |
|
Right to left (mm) |
370 |
||
Size of die handle bore |
Diameter(mm) |
60 |
|
Depth(mm) |
80 |
||
Pole distance (mm) |
300 |
||
Diatance between bench to guideway(mm) |
380 |
||
Max tilting angle (°) |
20 |
||
Pad thickness (mm) |
90 |
||
Motor power(kw) |
7.5 |
||
Dimension |
Front to back (mm) |
1750 |
|
Right to left (mm) |
1300 |
||
Height (mm) |
2600 |
||
