Specifications
Model |
DR-H305 |
Internal dimension (WxDxH) |
500*600*500mm |
External dimension (WxDxH) |
1000*1000*1750mm |
Temperature range |
RT+10~ 60℃ (suggest to use 40℃±2℃) |
Temperature Fluctuation |
±1℃ |
Ozone concentration |
50~1000 pphm, adjustable |
Ozone concentration deviation |
±10% |
Sample holder |
SUS#304 stainless steel |
Temperature controller |
Programmable touch screen controller |
Ozone concentration analysis |
Concentration analysis meter |
Ozone generator |
High pressure silence discharge type |
Protection system |
Leakage, short circuit, over temperature, over heat |
Test criteria |
ASTM D1149, ISO 1431, JIS K6259... |
In the production and application process of rubber products, ozone aging resistance is a key indicator to assess their quality and service life. As a professional testing equipment, rubber products ozone aging chamber can simulate the ozone environment that may be encountered in the actual use of rubber products, and carry out accelerated aging test on them to help enterprises and researchers accurately assess the ozone resistance of rubber products. In this article, we will introduce the functions, advantages, application scenarios and maintenance points of rubber products ozone aging chamber.
I. Product Overview
Rubber products ozone aging chamber is a testing equipment integrating advanced technology and intelligent control system, which is mainly used to evaluate the aging performance of rubber products under ozone environment. By precisely controlling the ozone concentration, temperature and humidity, the equipment simulates the harsh environment that rubber products may encounter in actual use, accelerates the aging process, and thus quickly evaluates the ozone resistance of rubber products. The equipment is widely used in rubber product manufacturers, scientific research institutions and quality testing organizations, providing a reliable means of testing for the quality control and research and development of rubber products.
Second, product features
1. Precise ozone concentration control
-
High-precision ozone generator: The equipment is equipped with a high-precision ozone generator, which can accurately control the ozone concentration, ranging from 0.1 ppm to 500 ppm, to meet different testing needs. Precise control of ozone concentration is the key to evaluate the ozone resistance of rubber products. The equipment ensures the stability and accuracy of ozone concentration through the advanced ozone generator and control system.
-
Real-time monitoring and adjustment: The equipment is equipped with a built-in ozone concentration sensor, which can monitor the ozone concentration in the test chamber in real time and automatically adjust the working status of the ozone generator according to the set value to ensure the stability of the test environment. This real-time monitoring and adjustment mechanism effectively avoids the impact of ozone concentration fluctuations on the test results, and improves the reliability and repeatability of the test.
2. Intelligent touch screen operation
-Intuitive and convenient operation interface
Intuitive and convenient operation interface: The equipment adopts intelligent touch screen operation interface, which allows users to easily set the test parameters, such as ozone concentration, temperature, humidity, test time, etc. The operation interface is intuitive and clear. The operation interface is intuitive and clear, even operators without professional background can quickly get started. The touch screen interface also supports multiple language switching, which is convenient for users from different regions.
-
Real-time data monitoring and recording: The touch screen can display the ozone concentration, temperature, humidity and other key parameters in the test chamber in real time, so that the user can always understand the progress of the test and the operating status of the equipment. The equipment can also automatically record the test data and generate a detailed test report, which is convenient for users to analyze the data and evaluate the results.
3. High-precision temperature and humidity control
-
Temperature control: The equipment is equipped with high-precision temperature sensors and intelligent control system, which can accurately control the temperature inside the test chamber. The temperature range is usually between room temperature and 60℃, and the temperature fluctuation can be controlled within ±0.5℃. Precise temperature control helps simulate the aging behavior of rubber products under different temperature conditions, which guarantees the accuracy of the test results.
-
Humidity control: the equipment also has a humidity adjustment function that can simulate different humidity environments. The humidity range is between 30% - 98% RH and the humidity fluctuation can be controlled within ±2% RH. Humidity control is especially important for evaluating the aging performance of rubber products under high humidity conditions, especially when testing the aging performance of rubber products against heat and humidity.
4. Safety and environmental design
-
Multiple safety protection: The equipment is equipped with multiple safety protection devices such as over-temperature protection, water shortage protection, power leakage protection, overload protection, etc. to ensure the safety of the equipment and operators. In the test process, once an abnormal situation occurs, the equipment will automatically alarm and stop running to prevent accidents. The multiple safety protection devices provide a reliable guarantee for the operation of the equipment and reduce the operation risk.
-
Environmentally friendly design: the equipment adopts environmentally friendly materials and energy-saving technology to reduce the impact on the environment. Equipped with an efficient exhaust gas treatment device, it purifies and treats the exhaust gas generated during the test process to ensure that the emission meets the environmental protection standards. The environmentally friendly design not only meets the environmental requirements of modern society, but also reduces the operating costs of the equipment.
