Home > Products > Spring Roll Sheet Production Line > Automatic Spring Roll Sheet Making Machine Samosa Sheets Production Line AJ-5029
Automatic Spring Roll Sheet Making Machine Samosa Sheets Production Line AJ-5029
- Qingdao
- T/T
- 30 days
You May Like
-
Rectangle Shape Automatic Samosa Sheets Forming Machine Samosa Wrapper Production Line AJ-8045
-
Automatic Dry noodle making machine Stick Noodle Maker Noodle Forming Machine
-
Automatic Fresh noodle making machine Noodle Maker Noodle Forming Machine
-
Automatic Flour mixer Powder Mixing Machine for noodle making machine
-
Automatic Dry Stick Noodle Cutting machine
-
Automatic Diamond Chinchin Cutting Machine Chinchin Making Machine
Product Details
| Brand Name | ANJIN | Place of Origin | China | |
| Model Number | AJ-5029 | Type | Pastry | |
| After-sales Service Provided | Engineers available to service machinery overseas | Warranty | 1 year | |
| Weight | 520kg | Dimension(L*W*H) | 5200*950*1350mm | |
| Production Capacity | 1000-1500pcs/h (Capacity based on product size) | Voltage | 380/220V（50/60HZ） 1/3phase | |
| Certification | CE | Condition | New | |
| Power(W) | 18kw |
Product Description
Automatic Spring Roll Sheet Making Machine Samosa Sheets Production Line AJ-5029
Spring roll sheet making machine can make round ,square and rectangle shape spring roll sheets, it can also making samosa sheets with different sizes. With gas and electric heating 2 version choice. Capacity based on the product diameter sizes and range from 500-3000PCS/H .
Processing steps:
Batter paste mixing – batter filter – batter printing to the baking drum – sheets baking – cooling conveyor – counting and folding part – finished product conveyor belt – packing machine.
Application:
Spring roll sheets, samosa sheets, Egg roll
Round,rectangle, square shape
Finished Product:
Application:
Widely used in chain stores, central kitchens, food factories, restaurants, fast food restaurants, and other units.
Feature:
Advanced temperature control system that accurately displays and controls the temperature.
It boasts a high heat utilization rate with minimal heat loss, fulfilling the goals of energy conservation and environmental protection.
The machine has a low production cost and a simple operating system, allowing it to be operated by a single person, thereby saving on labor.
Temperature and thickness can be adjusted.
Parameter data:
| Model | AJ-3620 | AJ-5029 | AJ-8045 | AJ-12060 |
| Voltage | 380/220V（50/60HZ） | |||
| Dia. of heating Cylinder | 400mm | 500mm | 800mm | 1200mm |
| Power | 8/10kw or gas | 18kw or gas | 40kw or gas | 59kw or gas |
| Capacity | 500-1000pcs/h | 1000-1500pcs/h | 3500pcs/h | 9000pcs/h |
| Dimension | 4100*950*1350mm | 5200*950*1350mm | 6200*1100*1600mm | 6500*1300*2300mm |
| Rotating speed | 1-2.5r/min | 1-2.5r/min | 1-3r/min | 1-3r/min |
| Weight | 330kg | 520kg | 1000kg | 1750kg |
| Size of the Sheet ( Max.) | 200mm | 300mm | 450mm | 600mm |
| Thickness of the Sheet | 0.5-2.0mm | |||
| Note | Capacity based on spring roll sheet size, | |||
| the actual capacity is subject to the quotation list. | ||||
Service:
24h After-sale service
Life Long Technical support
Latest marketing information update
Basic Recipe support
FAQ : About crepe making machine
Q1: The machine can use what kind of flour to make the batter paste?
A: This machine is most suitable for work with wheat flour.
Q2: How does the machine work?
A: The machine typically mixes flour and water to create a batter. After preparing the batter, the machine proceeds to spread it uniformly onto a heated surface, where it cooks to perfection and takes shape as the wrapper. After cooking, the machine automatically removes the wrapper from the surface.
Q3: What is the production capacity of the machine?
A: Production capacity varies based on the machine’s size and design. Capacities can range from a few hundred to thousands of wrappers per hour.
Q4: I’m a new beginner to spring roll sheet crepe making, what model I should choose?
A: Please provide your product specifications and hourly output. We will create a flow diagram and our engineer will design a custom factory based on your location.
