Durable Baler Logger Whole Car Baling

Durable Baler Logger Whole Car Baling thumbnail-1
Durable Baler Logger Whole Car Baling thumbnail-2
Durable Baler Logger Whole Car Baling thumbnail-3
Durable Baler Logger Whole Car Baling thumbnail-4
Durable Baler Logger Whole Car Baling thumbnail-5
Durable Baler Logger Whole Car Baling photo-1
Durable Baler Logger Whole Car Baling photo-2
Durable Baler Logger Whole Car Baling photo-3
Durable Baler Logger Whole Car Baling photo-4
Durable Baler Logger Whole Car Baling photo-5
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
After-sales Service Provided:
Engineers available to service machinery overseas
Contact Supplier Request Quote Chat Now
Henan Walle Industry Co., Ltd
Gold Verified Supplier
2Yrs
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO PORT
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
After-sales Service Provided Engineers available to service machinery overseas
Mainstructure
①　body
Themachine body is composed of left and right side frames, front frames,underframes, rear frames, door covers, main pressure heads, side pressureheads, oil cylinder supports and beams. Guard plates are installed in thecompression chamber to facilitate repair and replacement after wear.
②　Door cover cylinder
The doorcover cylinder is a double acting single piston rod cylinder, which is hingedon the beam support frame with two shafts. The piston rod and the door coverare hinged with a pin shaft to drive the door cover to rotate at 90 º to lockor loosen the door cover.
③　Main thrust cylinder

Themain push cylinder is a double acting single piston rod oil cylinder, which isinstalled at the lower part of the cross beam and connected to the rear frameof the machine body with a pin shaft. The piston rod is connected with the mainpressure head with a pin shaft to push the main pressure head back and forth.It is used for secondary compression to preliminarily form the materials

in thecompression chamber.

④　Side pressure cylinder

The side cylinder isa double acting single piston rod oil cylinder, which is connected to the sidecylinder support with a flange, and the piston rod is connected with the sidepressure head with a pin shaft to push the side pressure head to move back andforth left and right for ultimate compression, so that the materialspreliminarily formed in the compression chamber finally form a package.


Q：What is the delivery period for the baler?

A：WLB-5000 using cartridge valves, valve control mode 3 + 2, due to this set of customized valves production cycle is long, the general cycle time is 45 days

Item
Parameter
Note
1
Main
Model
YG320/220-4000
1/320T
Cylinder
Nominal thrust
1826KN
Trip
4000MM
2
Level①
Model
YG200/140-600
2/200T
Pressing material
Cylinder
Nominal thrust
785KN*3
Trip
600MM
3
Level②
Model
YG200/140-600
2/200T
Pressing material
Cylinder
Nominal thrust
785KN*3
Trip
514MM
4
Box size (L*W*H)（MM）
5000*2000*1500
5
Bale size（L*W*H）（MM）
(~600)*1000*1000
6
Working pressure（Mpa）
21.5 Mpa
7
Output bale mode
Crane
8
Bale density(Kg/m3)
≥2000(Fe)
9
Single cycle time
≥130S
10
Operation mode
Handle operation
11
Equipment weight
30T
12
Dimensions of equipment
6500*2400*2700mm
13
Engine
Model
HBE
Power
150HP
Rolling
2000r/min
Quantity
1
14
Oil pump
Model
A4V180+180
Pressure
31.5Mpa
Flow
376ml/r
Quantity
1
15
Average fuel consumption
15L/h
