Rapid Temperature Change Test Chamber Humidity and Heat Test Chamber

The constant temperature and humidity testing machine, also known as the environmental testing machine, tests the heat resistance, cold resistance, dry resistance, and moisture resis- tance of various materials. Suitable for testing the quality of electronic, electrical, communication, instrumentation, vehi- cles, plastic products, metals, food, chemistry, building materi- als, medical, aerospace and other products.

CHARACTERISTIC

1. High quality appearance, the body adopts a curved shape, the surface is treated with mist stripes, and a flat non reaction handle is used, which is easy to operate, safe and reliable.

2. A rectangular laminated glass viewing window can be used for observing the test object during the experiment. The window is equipped with an anti sweat electric heating device to prevent water vapor from condensing water droplets, and a high brightness PL fluorescent lamp to maintain illumination inside the box.

3. The double-layer isolation and airtightness of the box door can effectively isolate internal temperature leaks. Equipped with an external water supply system, it is convenient to supplement the humidification bucket water supply and automatically recycle it for use.

4. The compressor circulation system adopts the French "Taikang" brand, which can effectively remove lubricating oil between the cold pipe and capillary, and the entire series uses environmentally friendly refrigerants (R23, R404, R507)

5. The controller adopts an imported LCD display screen, which can simultaneously display measured values, set values, and time.

6. The controller has multi-stage program editing and can be used for quick (OUICK) or slope (SLOP) control of temperature and humidity.

7. The built-in mobile pulley is easy to move and place, and has strong positioning screws to fix the position.
