8DI 4AI 4DO SCADA Remote IO Module for Solar Monitoring System Data Transmission

8DI 4AI 4DO SCADA Remote IO Module for Solar Monitoring System Data Transmission thumbnail-1
8DI 4AI 4DO SCADA Remote IO Module for Solar Monitoring System Data Transmission thumbnail-2
8DI 4AI 4DO SCADA Remote IO Module for Solar Monitoring System Data Transmission thumbnail-3
8DI 4AI 4DO SCADA Remote IO Module for Solar Monitoring System Data Transmission thumbnail-4
8DI 4AI 4DO SCADA Remote IO Module for Solar Monitoring System Data Transmission thumbnail-5
8DI 4AI 4DO SCADA Remote IO Module for Solar Monitoring System Data Transmission photo-1
8DI 4AI 4DO SCADA Remote IO Module for Solar Monitoring System Data Transmission photo-2
8DI 4AI 4DO SCADA Remote IO Module for Solar Monitoring System Data Transmission photo-3
8DI 4AI 4DO SCADA Remote IO Module for Solar Monitoring System Data Transmission photo-4
8DI 4AI 4DO SCADA Remote IO Module for Solar Monitoring System Data Transmission photo-5
US$ 115.43 - 136.61 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
BLIIOT
Place of Origin:
China
Model Number:
M150T
Contact Supplier Request Quote Chat Now
Shenzhen Beilai Technology Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BLIIOT
Place of Origin China
Model Number M150T

Product Description

Modbus TCP I/O Modules M150 is designed for Industrial Internet of Things, the data acquisition module comes with 8DI, 4DO, 4AI, compatible with MQTT, Modbus RTU, Modbus TCP, SNMP V1/V2 Protocol. Remote I/O M150 comes with RS485 serial port and Ethernet port, the current monitoring and acquisition module suppots Modbus TCP server and client, Modbus RTU master and slave.

1. Industrial automation data acquisition and control;
2. Smart grid data acquisition and control;
3. Smart transportation data acquisition and control;
4. Cold storage temperature monitoring, fruit and vegetable storage room, industrial computer room, transformer cabinet, etc.;
5. Warehousing and libraries temperature and humidity data acquisition and
monitoring;
6. Solar monitoring system data transmission;
7. Data transmission of ATM, POS, electric meter, PLC, DAQ and other equipment;
8. Agricultural temperature and humidity data acquisition and monitoring;
9. Breeding temperature and humidity data acquisition and monitoring;
10. Charging pile data acquisition and transmission;
11. Meteorological station data acquisition and monitoring;
12. Environmental protection data acquisition and control;
13. Occasions where other monitoring points are scattered;

Application

Product Parameters

Item Parameter Description
Power Input voltage

  1. Models without AO: 9~36VDC

  2. Models with AO: 24~36VDC
Power consumption Typical standby power consumption: ≤ 2W
Power Output

  1. 1 channel

  2. Output voltage: 9~36V DC

  3. Output current: 1500mA@12V(MAX)
Protection Reverse wiring prevention;
ESD Air: 15KV; Surge: 4KV
Ethernet Specification 1 x RJ45, 10M/100Mbps
Protection ESD contact: 8KV, Surge: 4KV(10/1000us)
Protocol Modbus RTU, Modbus TCP, MQTT
Serial port QTY 1 x RS485
Baud Rate 2400, 4800, 9600, 14400, 19200, 38400, 57600, 115200, 128000
Data Bit 7, 8
Parity Bit None, Even, Odd
Stop Bit 0.5, 1, 1.5, 2
Protocol Modbus RTU(slave), Modbus RTU(master)
Protection ESD contact: 8KV  Surge: 4KV(8/20us)
Digital input QTY 8 channel
Type Support Wet contact(NPN, PNP) and Dry contact.
Default: Wet contact
Dry contact

  1. Close: Short circuit

  2. Open: Open circuits

Wet contact

  1. Close: 10~30VDC

  2. Open: 0~3VDC

Others Support DIN1 as a pulse counter: Support high-speed pulse and low-speed pulse mode, default high-speed pulse frequency is up to 700KHz, and the optional low-speed pulse frequency is up to 10KHz.
Support DIN2~DIN12 as low-speed pulse counter: The anti-jitter time can be set from 1~2000ms, default is 1ms, and the corresponding pulse frequency is up to 1KHz.
Isolated protection 2KVrms
Sampling Rate 100Hz
Digital output QTY 4 channels
Type SINK
Capacity 500mA per contact
Overvoltage protection 50VDC
Pulse output The first DO supports pulse output, pulse output frequency: 10Hz~300KHz
Analog input (12bit) QTY 4 channels
Method Differential input
Type 4-20mA, 0-20mA, 0-5V, 0-10V
Resolution 12Bit
Accuracy

  1. ±0.1% FSR @ 25°C

  2. ±0.3% FSR @ -10 and 60°C

  3. ±0.5% FSR @ -40 and 75°C
Sampling Rate 20Hz
Input Impedance

  1. Voltage type: >1M ohms

  2. Current type: 162 ohms
Analog input (16bit) QTY
4 channels
Method Differential input
Type 4-20mA, 0-20mA, 0-5V, 0-10V
Resolution

  1. 16Bit
Accuracy

  1. ±0.5‰FSR @ 25°C
Input Impedance

  1. Voltage type: >1M ohms

  2. Current type: 162 ohms
Software Protocols IPV4, TCP/UDP, DNS, Modbus RTU, Modbus TCP, MQTT
Protocol conversion Support Modbus TCP and RTU protocol conversion
Support Modbus RTU to MQTT and Modbus TCP to MQTT
Indicator light Power, Link, RS485_RXD, RS485_TXD, IO status
User configuration PC software configuration, support WIN XP, WIN 7, WIN 8, WIN 10
Map data bool: 300
16bit: 300
Login Package Support custom login package
Heartbeat Package Support custom heartbeat package
Environment Working -20~70°C, 5~95%RH
Storage -40~85°C, 5~95%RH
Others Case Metal
Dimension 82mm×40mm×100mm
Protection grade IP30
Net Weight 450g
Installation DIN rail mounted, Wall-mounted
