Product name: N connector
Product design level: Universal connector
Operating voltage: 1000V r.m.s
Operating temperature: -55℃ ~ +125℃
Operating frequency range: DC-6GHz
Characteristic impedance: 50Ω
Contact resistance: inner conductor ≤1mΩ Outer conductor ≤1mΩ
Insulation resistance: ≥5000MΩ
Medium voltage: 2500V
Inner conductor holding force: ≥0.56N
Retaining force of connecting screw sleeve: ≥450N
Salt spray resistance: > 48H
Shenzhen Sihanming technology Co, LTD (Shenzhen Sihan Communication Technology) was established in 2006,is a company that sets professional design,development,production,sales as one.Our main products are RF coaxial connectors,RF jumper,MMCX connectors for earphone,test connectorfor Mobile phone,fakra automotive connectors,High freguency low loss test cable,tRF adapter and RF antennas..ln the same time,we are the agent of the Japanese ipex , Japanese Murata and Japanese Hirose.
2010:Company independently research and develop for automotive connector Fakra series products and formally put into production.And get several patents of appearance and utility model.
2012:Shenzhen Sihanming Technology Co., Ltd passed the assessment of ISO9001.
2013:Shenzhen Sihanming Technology Co., Ltd passed the assessment of TS16949.
2015:The LOGO SH-Link register successfully. ln the same year our company was identified as"high-tech enterprise by "shenzhen science and technology innovation and technology commission "and issue a certificate.
2018:Shenzhen Sihanming Technology Co., Ltd passed the assessment of IATF16949 and ISO14001
