Easy To Operate Powder Coating Paint Spray Filter

Easy To Operate Powder Coating Paint Spray Filter thumbnail-1
Easy To Operate Powder Coating Paint Spray Filter thumbnail-2
Easy To Operate Powder Coating Paint Spray Filter thumbnail-3
Easy To Operate Powder Coating Paint Spray Filter thumbnail-4
Easy To Operate Powder Coating Paint Spray Filter thumbnail-5
Easy To Operate Powder Coating Paint Spray Filter photo-1
Easy To Operate Powder Coating Paint Spray Filter photo-2
Easy To Operate Powder Coating Paint Spray Filter photo-3
Easy To Operate Powder Coating Paint Spray Filter photo-4
Easy To Operate Powder Coating Paint Spray Filter photo-5
US$ 103 - 103 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Huaxiang
Place of Origin:
China
Model Number:
41
Contact Supplier Request Quote Chat Now
Hangzhou Huaxiang Coating Equipment Co.,Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Huaxiang
Place of Origin China
Model Number 41
Certification SGS
After-sales Service Provided Engineers available to service machinery overseas
Weight 5.5KG
Dimension(L*W*H) 20X20X30 cm
Voltage /
Power /
Application Machinery & Hardware
Condition New
Automatic Grade Other
Driven Type Other
Packaging Material Other, Wood
Packaging Type Other
Product descriptions from the supplier
Overview
Easy To Operate Powder Coating Paint Spray Filter

Features:

(1) Suitable for the filtration of very fine dust type in welding fumes Mechanical processing, pharmaceutical and construction industries And sticky dust collection.
(2) Spun bonded polyester with PTFE membrane, microspore Offers 99.99% filter efficiency.
(3) Wide pleat spacing and smooth, hydrophobic PTFE provides excellent particle release.
(4) Excellent resistance to chemical erosion.
(5) Electrochemical plate/stainless steel top and bottom, no rust Perforated zinc galvanized metal inner core allows good airflow.






Spun bond media filter cartridge has very high filtration efficiencies on fine particulate, along with high resistance to abrasion and chemicals. This media provides superior dust cake release properties compared to paper media. Spun bond media is particularly suitable for pharmaceutical manufacturing, powder coating or fibrous materials such as wood or fiber glass.


Model
Outer Dimension
Inner Dimension
Length
Filtration surface( m ² )
SFF/P3266
Φ324mm
Φ213mm
660mm
9.4m ²
SFF/P3566
Φ352mm
Φ241mm
660mm
9.4m ²
SFF/P3275
Φ324mm
Φ213mm
750mm
10.7m ²
SFF/P3288
Φ324mm
Φ213mm
880mm
12.5m ²
SFF/P3290
Φ324mm
Φ213mm
915mm
13.0m ²
Material:

1. Base media: Spunbonded polyester
2. Operating efficiency: 99.9% on 1 micron
3. Washable: Several times
4. Maximum operating temperature: 200°F/93℃
5. Abrasion resistance: Excellent
6. Chemical tolerance: Excellent
7. Optional flame retardant media(FR): To order


Enhance your coating process with advanced electrostatic powder coating machines, precision powder coating spray guns, comprehensive powder coating systems, and efficient powder coating lines from Hangzhou Huaxiang Coating Equipment Co., Ltd. Designed for reliability and high-quality finishes, our solutions meet all your industrial coating needs. Contact us at sale3@cncolourspray.com
