Home > Auto, Motorcycle Parts & Accessories > Auto Parts > Auto Compressor > AVENTICS 0820055051 HF03-LG 5/2-directional Valve
AVENTICS 0820055051 HF03-LG 5/2-directional Valve
CNY 500 - 600
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Aventics
Place of Origin:
France
Model Number:
0820055051
Payment & Shipping
Payment Methods:
Port of Shipment:
KUNSHAN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
AVENTICS Pneumatic Directional Valve 0820024125 AVENtics Solenoid ValveNegotiableMOQ: 1 Piece -
Aventics Pneumatic Valve 0820055101NegotiableMOQ: 1
-
Aventics Pneumatic Valve 0820055601US$ 150 - 200MOQ: 1 Set
-
Shotmay STM-8037 Avent Breast Pump for WholesalesUS$ 80 - 150MOQ: 1 Unit
-
AVENTICS Cylinders ActuatorsEUR 1 - 2222MOQ: 1 Bag
Brand Name
Aventics
Place of Origin
France
Model Number
0820055051
Type
Valves
0820055051 AVENTICS 5/2-directional valve, Series HF03-LG
Activation
Electrically
Switching principle
5/2, with spring return
Actuating control
Single Solenoid
Manual override
with detent
Pilot
External
Nominal flow Qn
850 l/min
Min. working pressure
-0.9 bar
Max. working pressure
10 bar
Operational↩voltage
24 V DC
Voltage tolerance DC
-15% / +20%
Protection class with connection
IP65
Reverse polarity protection
Protected against polarity reversal
Sealing principle
16 mm, Soft seal
Power consumption DC
0.35 W
Duty cycle
100 %
Typ. switch-on time
16 ms
Typ. switch-off time
23 ms
Certificates
UR (Underwriters Laboratories) ‒ pilot valve only
Min. ambient temperature
0 °C
Max. ambient temperature
50 °C
Weight
0.082 kg
Housing material
Polyamide fiber-glass reinforced
