Sea Water DC Type Mini Air Cooled Type Chiller

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T L/C
Delivery Detail30 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin

China

Product Description

Sea water DC type mini air cooled type chiller

DC series small chillers use DC power supply, using coolant as heat transfer medium, transferring heat generated by other instruments or equipment that need to be cooled, and dissipating heat to the outside of the equipment through the refrigeration system, thus ensuring that the equipment works within the normal temperature range.

/dc-small-portable-chiller/

Technicial parameter：
Small size DC air to water chiller for sea water parameter table
Item	Description	Unit	Parameter
1	Water cooled chiller	Model	HTB-M1.2F-24/36D-S
2	Power		DC24V/ DC36V
3	Cooling capacity	W	1200
3	Cooling capacity	Kcal/h	1032
4	Power consumption	W	320
5	Running Amps	A	13.6
6	Compressor	Type	Small DC compressor
		Quantity	1
		Starting method	Direct start
7	Refrigerant	Type	R134A
		Quantity	400g
		Control	Capillary
9	Evaporator	Type	Casing type heat exchanger- Titanium material
		Water inlet temp (℃)	30
		Water outlet temp (℃)	24
		Water flow rate (L/h)	300
		Water pipe	3/4”
10	Condenser	Type	Finned type heat exchanger after electrophoresis treatment
		Using ambient temp (℃)	0-43
		Air volume (M3/h)	450
13	Dimension (estimated)	LWH（MM）	508500475
14	Weight (estimated)	KG	48.48

Configuration table:
High Performance Spare Parts & Accessories
Item	Specification	Brand	Country of origin
1	DC Compressor	Highly	China
2	Evaporator( Casing type heat exchanger- Titanium material)	Shenshi	China
3	Condenser( Finned type heat exchanger after electrophoresis treatment)	Customized	China (Huazhao)
4	Dry filter	Customized	China (Huazhao)
5	Capillary	Customized	China (Huazhao)
6	Microcomputer controller	Customized	China (Huazhao)
7	Pressure Switch	Match-Well	China
8	Refrigeration	DuPont	America
9	Fan	Maer/Dayang	China
10	Water line	PVC pipe	For sea salt water
