Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Engineering & Construction Machinery Parts > GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI Turbocharger Core for Opel Astra G 2.2 DTI 24445061 860050 860098

GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI Turbocharger Core for Opel Astra G 2.2 DTI 24445061 860050 860098

GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI Turbocharger Core for Opel Astra G 2.2 DTI 24445061 860050 860098 photo-1
GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI Turbocharger Core for Opel Astra G 2.2 DTI 24445061 860050 860098 photo-2
GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI Turbocharger Core for Opel Astra G 2.2 DTI 24445061 860050 860098 photo-3
GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI Turbocharger Core for Opel Astra G 2.2 DTI 24445061 860050 860098 photo-4
GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI Turbocharger Core for Opel Astra G 2.2 DTI 24445061 860050 860098 photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2007
Overseas Office:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI turbocharger core for Opel Astra G 2.2 DTI  24445061 860050 860098



Welcome to contact us :

Whatsapp / Wechat :+86 18262294090 Skype : _15

QQ: 1127776325

Product description

Part Number717625-5001S
Previous Version717625-0001, 717625-1
OE Number24445061, 860050, 860098
Year2002-
DescriptionOpel, Vauxhall Astra, Zafira, Vectra
CHRA703890-0018
Turbo ModelGT1849V, GTA1849V
EngineY22DTR
Engine ManufacturerOpel
Displacement2.2L, 2200 ccm
KW92
RPM Max4000
FuelDiesel
Angle α (compressor housing)321.4
Angle β (turbine housing)300
Bearing Housing722282-0013
Turbine Wheel704580-0001
Comp. Wheel436132-0003 (replaces 436132-3/703925-3) $65.20
Back plate700593-0006/703682-0045 (OD 99 mm/10 mm P/Ring)
Heat shield Number433112-0001
Nozzle Ring Assembly704013-0011/704013-0013
Repair Kit732252-0001
Turbine Housing717624-0002
Compressor Cover703896-0003
Turbine Housing ARVNT2
Actuator434855-0060
Settings Waste gate (pressure)0.197-0.203/0.530-0.570 bar
Settings Waste gate (lift rod)0.5-4.0/0.2 mm
Gasket (turbine inlet)210505
Gasket oil inlet210511
Gasket (oil outlet)210243

Applications

2002- Opel Astra with Y22DTR Engine

2002- Opel Zafira with Y22DTR Engine



Products show







GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI turbocharger core for Opel Astra G 2.2 DTI 24445061 860050 860098GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI turbocharger core for Opel Astra G 2.2 DTI 24445061 860050 860098GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI turbocharger core for Opel Astra G 2.2 DTI 24445061 860050 860098GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI turbocharger core for Opel Astra G 2.2 DTI 24445061 860050 860098GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI turbocharger core for Opel Astra G 2.2 DTI 24445061 860050 860098GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI turbocharger core for Opel Astra G 2.2 DTI 24445061 860050 860098



Turbo parts

The turbocharger parts  including Turbo  Chra ( turbo  core / cartridge  ) , Turbo actuator valve, Nozzle Ring ,Repair  kit ,Compressor  wheel,Turbine wheel,Turbine  shaft , Journal bearing ,Thrust collar,Bearing housing ,Turbine housing,Compressor housing,Bypass-valve and so on

 GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI turbocharger core for Opel Astra G 2.2 DTI 24445061 860050 860098











Package

GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI turbocharger core for Opel Astra G 2.2 DTI 24445061 860050 860098

Company Profile



1.Wuxi Booshiwheel Power Technology Co,Ltd.,established in 2002,is engaged in designing and producing turbochargers and turbo parts that are used in vehicle and engineering machinery.We can also provide maintenance and technological services.



2.The company has imported Japanese advanced equipments,such as assembly line,processing production line and high speed balance,as well as the latest testing facilities.



3.The company’s business concept are “make contribution to the development of society by technology” and “talent is the biggest and unique wealth”,focus on manufacturing global the most cost-effective turbochargers.





Last ,we are looking forward to cooperating with you .





 GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI turbocharger core for Opel Astra G 2.2 DTI 24445061 860050 860098





Welcome to inquiry!



GT1849V 717625 717625-5001S for Opel Zafira A 2.2 DTI turbocharger core for Opel Astra G 2.2 DTI 24445061 860050 860098
