Help CenterHE351V 3770973 2834603 4046264 5325947 Turbocharger Ram 2500 All Engine ISB 2842406 2834900 2835908
Related Products
-
TD025 Turbocharger 49173-02010 A1320900180 080115139 A1320900180 080115139 A1320900080 1320900080 1515A099 Engine 3B21 M132.930NegotiableMOQ: 1 -
Factory Directly Supply Turbocharger 781504-6 1.4T E-55565353 for A14NET Engine 781504-5004SNegotiableMOQ: 1
-
TD04 Turbocharger 49477-01510 4947701510 Turbo 25194653 25187703 25185866 Engine PartsNegotiableMOQ: 1
-
TD04L6 Turbocharger 49477-06100 189005MSH020M3 TD04 Turbo Accord 2LX Passenger Car AP4T 2.0L Engine 4947706100NegotiableMOQ: 1
-
GT1241Z 824756-0003 FPLA-6K682-CC Turbo ChargerNegotiableMOQ: 1
Welcome to contact us :
Whatsapp / Wechat :+86 13606178432 Skype : _15
QQ: 1127776325
Products description
| Part Number | 5325947 |
| Previous Version | 2834603, 2842406, 2834900, 2835908, 2837649, 2838190, 3768087, 3770973, 3790481, 3799833, 3799840H |
| OE number | 2882075, 4955876, 2881755, 4955447, 68003401AA, 68027068AA, 68048234AD, 68031095AA, R8048234AG, R8048234AH |
| Year | 2003-12 |
| Description | Dodge Ram 2500 3500 Truck |
| Manufacturer Part Number | 2834955, 2835910, 2837647, 2838191, 2842407, 3768088, 3770974, 3790483, 3799840, 4046837, 5325950 |
| CHRA | (1000020127) |
| Turbo Model | HE300VG, HE351VE, HE351CW |
| Engine | ISB, ISB 6.7 Raptor, ISB5.9, ISB6, ISB 6.7 Blackbird, ISB EPA 07 |
| Engine Manufacturer | Cummins |
| Displacement | 6.7L, 6700 ccm |
| KW | 350 HP |
| Fuel | Diesel |
| Angle α (compressor housing) | 175° |
| Angle β (turbine housing) | 189° |
| Bearing Housing | (1900011227) |
| Turbine Wheel | (1100016231) (Ind. 70.2 mm, Exd. 60.0 mm, 12 Blades) $176.22 |
| Compressor Wheel | (Ind. 50.3 mm, Exd. 72.6 mm, 6+6 Blades, Billet)(1200016234) $159.00 NEW IN STOCK |
| Back Plate | (1300016093) $75.03 |
| Nozzle Ring | (3000016048) $299.00 NEW IN STOCK |
| Repair Kit | (1154351752) $138.00 NEW IN STOCK |
| Turbine Housing AR | VGT |
| Actuator | Electronic |
| Replaced By | 3770973, 2834603, 4046264 |
Applications
2003-12 Dodge Ram 2500 All Engine ISB
