G30 G30-770 Turbocharger Standard Rotation Ball Bearing Cast Iron Turbine Turbo

G30 G30-770 Turbocharger Standard Rotation Ball Bearing Cast Iron Turbine Turbo photo-1
G30 G30-770 Turbocharger Standard Rotation Ball Bearing Cast Iron Turbine Turbo photo-2
G30 G30-770 Turbocharger Standard Rotation Ball Bearing Cast Iron Turbine Turbo photo-3
G30 G30-770 Turbocharger Standard Rotation Ball Bearing Cast Iron Turbine Turbo photo-4
G30 G30-770 Turbocharger Standard Rotation Ball Bearing Cast Iron Turbine Turbo photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2007
Overseas Office:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

G30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine Turbo





Welcome to contact us :

November Gao.

Mob/Wechat/WhatsApp: 8618912476630



produtct description

G30-770
The G-Series G30-770 turbocharger is compatible with 2.0L - 3.5L engine displacements and capable of producing up to 770 horsepower. G Series 30 turbochargers are highly efficient and will outflow all comparable products on the market.

  • G SERIES COMPRESSOR AERODYNAMICS FOR MAXIMUM HP
  • 58mm TURBOCHARGER COMPRESSOR WHEEL
  • 76% MAXIMUM COMPRESSOR EFFICIENCY
  • MAR-M ALLOY TURBINE WHEEL RATED UP TO 1050° C
  • NEW TURBINE AERO PROVIDES HIGHER FLOW AND EFFICIENCY
  • STAINLESS STEEL TURBINE HOUSINGS RATED UP TO 1050° C
  • OIL RESTRICTOR AND WATER FITTINGS INCLUDED
  • FULLY MACHINED SPEED SENSOR AND PRESSURE PORTS
  • STANDARD ROTATION SUPERCORE 880693-5002S
  • REVERSE ROTATION SUPERCORE 880694-5002S

Horsepower: 475 - 770HP
Displacement: 2.0 - 3.5L

  • Garrett® G Series Compressor Aerodynamics for maximum HP.
  • Fully machined Speed Sensor and pressure ports.
  • New Turbine Wheel Aero constructed of MAR-M alloy rated 1055ºC
  • Stainless Steel wastegated and non wastegated turbine housing option capable of 1050°C.
  • Oil restrictor and water fittings included.
  • Reverse rotation.
  • Compressor side: TRIM 65 A/R 0.72
  • Compressor Air Inlet: Hose 4.00" (101.60mm)
  • Compressor Air Outlet: Hose 2.00" (51.15mm)
  • Bearing housing: Water and Oil cooled system.






Product show

 G30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine TurboG30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine TurboG30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine TurboG30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine TurboG30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine TurboG30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine Turbo









Packages

plastic papershock bubble, neutral carton,pallet or as your requirements



G30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine Turbo





Company Information



CVE Electron Beam Welding from UK



Studer CNC grinding machine from Switzerland



Okuma CNC machine from Japan



Schenck balancing machine from Germany



G30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine Turbo

Production capacity



G30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine Turbo







G30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine Turbo







G30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine Turbo





G30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine Turbo







G30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine Turbo

Exhibition show

Booshiwheel has attended the Auto exhibition in Thailand ,Turkey,Dubai, Russia,Germany,U.S.A and Panama in 2018 year

G30 G30-770 turbocharger Standard Rotation Ball Bearing cast iron turbine Turbo





Company Profile



1.Wuxi Booshiwheel Power Technology Co,Ltd.,established in 2002,is engaged in designing and producing turbochargers and turbo parts that are used in vehicle and engineering machinery.We can also provide maintenance and technological services.



2.The company has imported Japanese advanced equipments,such as assembly line,processing production line and high speed balance,as well as the latest testing facilities.



3.The company's business concept are "make contribution to the development of society by technology" and "talent is the biggest and unique wealth",focus on manufacturing global the most cost-effective turbochargers.



Last ,we are looking forward to cooperating with you .

FAQ
1:Are you factory or only company?

we have factory to produce turbo products ,such as ship turbos,performance turbos,aftermarket turbos,etc .And also we have the agent for some other brand.

2:Why we can choose you?
1):Reliable-we are the real company, we dedicate in win-win.
2):Professional-we offter the turbo products exactly you want.
3):Factory-we have factory,so have compective price,fast delivery time,high quality goods.

3:How about the shipping cost?
If your goods is not large,we can send goods to you via express,such as FEDEX,DHL,EMS,TNT,etc.if your goods is large ,we will send to u via sea or air,we can quote the price base on EXW,FOB,CIF&CNF as you like, you can choose whether to use our forwarder or yours.

4:How about the price ? Can you make it cheaper?
the price depends on the item your demand quantity,Final quotation according to receiving full description of the item you want.

5:How about the sample time ?What is the payment ?
Sample time: 3-10days after e-proof confirmed and your payment received. T/T, 30% deposit ,and the balance before the shipment.

Welcome to contact us!
