Performance Turbo G35-1050 V-Band Turbine Turbo Flange Conversion Convertor Stainless Steel Flange Cover
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
G25 G25-550 V-Band Ring Stainless Steel Flange Cover for Turbine Housing Turbo Flange Conversion Convertor 877895-5001S
-
Top Modify Turbo Charger G42-1450 879779-5016S Cast Iron Turbine Standard Rotation A/R 1.01 V-band 879779-5016 G42 1450 879779
-
New G42 G42-1450 Standard Rotation AR 1.01 V-Band Cast Iron Turbine Turbo 879779-5016S 860778-5006S
-
G42-1200 G42 Compressor Housing Standard Rotation 879779-5016S 860778-5006S for Performance Turbocharger
-
G35 G35-900 880696 V-Band Turbo Flange Conversion Convertor Stainless Steel Flange Cover 880696-5001S 880696-0001 Turbocharger
-
G30 G30-660 Flange Conversion Convertor Stainless Steel Flange Cover 880694-5001S 880694
Product Description
Product Description
- Horsepower: 700 - 1050HP
Displacement: 2.5 - 5.5L - Garrett® G Series Compressor Aerodynamics for maximum HP.
- Fully machined Speed Sensor and pressure ports.
- New Turbine Wheel Aero constructed of MAR-M alloy rated 1055ºC
- Stainless Steel wastegated and non wastegated turbine housing option capable of 1050°C.
- Oil restrictor and water fittings included.
- Reverse rotation.
- Compressor side: TRIM 65 A/R 0.75
- Compressor Air Inlet: Hose 4.00" (101.60mm)
- Compressor Air Outlet: Hose 2.00" (51.15mm)
- Bearing housing: Water and Oil cooled system.
- Product Description:
- Garrett® G35-1050 REVERSE Rotation Supercore (Turbo without turbine housing).
Product Features:- New G Series compressor wheel aerodynamics
- Fully machined speed sensor and pressure ports
- Standard and reverse rotation configurations available
- Oil restrictor and water fittings included with purchase
- One piece center housing and backplate for increased durability
- 4 water jacket ports for customizable installation
- Mar-M turbine wheel material rated up to 1050° C | 1922° F
- Product Specifications:
- Compressor Wheel Inducer: 68mm
- Compressor Wheel Exducer: 84mm
- Compressor Wheel Trim: 65
- Compressor Housing A/R: 0.72
- Turbine Wheel Inducer: 68mm
- Turbine Wheel Exducer: 62mm
- Turbine Wheel Trim: 84
- Coolant (Water) & Oil Fittings, Flanges, and Components Solutions:
- Coolant - Water Options (Requires 2 units): 14mm Coolant Fitting & Lines
- Oil feed fitting with .035" restrictor: ATP-OIL-021
- Oil drain flange: Product Code: ATP-FLA-010
- Oil drain gasket: Product Code: GRT-GSK-008
- Oil drain fasteners: Product Code: MIA-FST-034
- Boost Pressure Port Fitting: ATP-FTG-198
NOTE: Alternate coolant and oil fittings and flanges are available.
