K26 Turbocharger 53269886292 53269706292 4LH-DTE Engine Turbocharger for Sigma Yanmar Ship 53269886291 53269706291 11917318011
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2007
Overseas Office:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
K365 53369706737 53369706783 Turbo for MAN Marine With D2866LE401 Engine 51091007552 53369707090 53369706793NegotiableMOQ: 1 -
RHF5WB Turbo VB660064 MG8 VA660064 VC660064 VD660064 18900HW59020M1 Turbo for Honda PWC Marine Aquatrax F12-R12 With HW1 EngineNegotiableMOQ: 1
-
MG11 18900HW59020M1 VB660064 HW5-9020 RHF5WB Turbocharger for Honda PWC Marine Aquatrax F12-R12 With HW1 EngineNegotiableMOQ: 1
-
53369706737 53369886737 5336-970-6737 MAN Marine Ship With D2866LE401 Engine K365 Turbo 5109100755 533698867832NegotiableMOQ: 1
-
K365 Turbocharger 53369886734 53369706734 51.09100-7490 51091007490 Turbo for MAN Ship With D2876LE401 EngineNegotiableMOQ: 1
Specification
Part Number |
53269886292 |
Previous Part Number |
5326-988-6292, 5326 988 6292, 53269886291 |
OE number |
11917318011, 119173-18011, 11917318850, 119173-18850 |
Year |
1989-05 |
Description |
Yanmar Ship Sigma Marine |
Manufacturer Part Number |
53269706292, 53269-706-292, 5326 970 6292 |
CHRA |
53267100058 (5326-710-0058)(USE 5326-710-0067) $774.35 NEW IN STOCK |
Turbo Model |
K26-3262MGA8.71GAAXB |
Engine |
4LH-DTE |
Displacement |
3.45L, 3450 ccm |
KW |
125/168/170 HP |
RPM Max |
3300 |
Fuel |
Diesel |
Angle α (compressor housing) |
90° |
Angle β (turbine housing) |
110° |
Bearing Housing |
53241500004 (858705) $150.34 |
Turbine Wheel |
53261202124/53261205001 (Ind. 64.3 mm, Exd. 54.5 mm, 12 Blades) $291.41 NEW IN STOCK |
Comp. Wheel |
53271232227/53271232035/53271232217 (313713)(Ind. 49.1 mm, Exd. 81.3 mm, Trm 3262MGB, 7+7 Blades) (1301027425) $127.29 NEW IN STOCK |
Back plate |
53271515738/53271515739 $61.73 |
Heat shield Number |
53261652005 (53261652007) (858668) $22.75 |
Repair Kit |
53267110039/53267110001 (1301026752) $86.00 NEW IN STOCK |
Turbine Housing (water-cooled) |
53261006423/53261006422 (3261006422) $1495.21 |
Compressor Cover |
53271015333/53271015111/53271015226 (3271015333) |
Turbine Housing AR |
8 |
Gasket (turbine inlet) |
210294 |
Gasket oil inlet |
210023 (147837) $4.48 |
Gasket (oil outlet) |
210060 |
1979-05 Sigma Marine with 4M-EU / 5M-GEU II Engine
1989-05 Yanmar Ship with 4LH-DTE Engine
1989-05 Yanmar Ship with 4LH-DTE Engine
