Isuzu Sewage Suction Truck,8000 Liters Sinotruck HOWO Sanitary Truck Combined Vacuum and Jet Suction Truck With Jetting Pump
US$ 12000 - 78000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
Focus
Place of Origin:
China
Model Number:
Focus 206
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
20 days
Related Products
-
China Compactor Garbage Truck,New Design Garbage Collection Truck 10cbm Kitchen Compactor Garbage Waste TruckUS$ 6000 - 23650MOQ: 1 Unit -
China Factory Direct Foton10-14cbm Garbage Compactor Truck Compressed Garbage Rubbish TrucksUS$ 6000 - 99999MOQ: 1 Unit
-
Cheap 12cbm Diesel Agitator Tank Truck Concrete Mixer Cement Mixer Truck, Construction Mixing Drum Truck HOWO Mobile Concrete Mixer TruckUS$ 6000 - 99999MOQ: 1 Unit
-
Sinotruk 6X4 8X4 4X2 Cement Mixer Pump Tank Construction Mixing Drum Truck HOWO Mobile Concrete Mixer TruckUS$ 6000 - 36500MOQ: 1 Unit
-
2.5m3 Self Loading Mixture Cement Howo Mobile Self Loading Concrete Mixer 12 Cubic Meters Concrete Mixer Truck For Sale PriceUS$ 6000 - 99999MOQ: 1 Unit
Brand Name
Focus
Place of Origin
China
Model Number
Focus 206
Condition
New
Transmission Type
Manual
Fuel Type
Diesel
Emission Standard
Euro 2
Horsepower
150-250HP
Dimension (L x W x H)
8400×2500×3450
Tank Volume
6000-7000L
8000 liters SINOTRUCK HOWO sanitary truck combined vacuum and jet suction truck with Jetting pump
| SER | ITEM | PARAMETER | UNIT | DATA | REMARK |
| 1 | WHOLE VEHICLE | WHOLE MODEL | FCS5160GQW | ||
| MANUFACTURE DATE | 2021 | ||||
| OVERALL DEMENSION | MM | 8400×2500×3450 | |||
| GVW | KG | 16000 | |||
| CURB WEIGHT | KG | 7705 | |||
| MAX GRADABILITY WHEN FULL LOADING | DEG | 32° | |||
| MAX SPEED | KM/H | 90 | |||
| FRONT/REAR HANGING | MM | 1250/2030 | |||
| CLOSE/DEPARTURE ANGLE | DEG | 23/14 | |||
| LEAF SPRING | PCS | 9/10+8 | |||
| DRIVE WHEEL | 4*2 | ||||
| 2 | CHASSIS | CHASSIS MODEL | DFL1140B(DongFeng) | ||
| MANUFACTURER | DongFeng Motors Co.,Ltd. | ||||
| MANUFACTURE DATE | 2021 | ||||
| WHEELBASE | 4500 | ||||
| ABS | Equipped | ||||
| FRONT AXLE | 6T | ||||
| REAR AXLE | 10T | ||||
| TYRE SPECIFICATION | 10.00R-20 | ||||
| NO OF TYRES | PCS | 6+1 spare tyre | |||
| 3 | ENGINE | ENGINE MODEL | B190 33 | ||
| MANUFACTURER | DongFeng Cummins Engine Co.,Ltd. | ||||
| ENGINE HORSEPOWER | PS | 190 | |||
| DISPLACEMENT | ML | 5900 | |||
| EMISSION STANDARD | Euro III | ||||
| ENGINE DETAILS MORE | 6 cylinders | ||||
| Direct injection | |||||
| Watercooled Turbocharged | |||||
| 4 | GEARBOX | NO OF GEARS | DF6S900 6 forward gears and 1 reverse | ||
| RATIO | 5.286 | ||||
| 5 | SUCTION& WASHING | BRAND | FOCUS | ||
| BASIC CONFIGURATION | As sewage windows, hand-washing device, gravity mouth, Pressure gauge, self-absorption since the row. | ||||
| THICHNESS | MM | 5 | |||
| VOLUME | L | Water tank:4000L Suction tank:7000L |
|||
| MATERIAL OF TANKER | Carbon steel | ||||
| SPECIFICATIONS OF SUCTION PUMP | China-Yifeng brand Speed(r/mm):950 Flow:350m³/h | ||||
| SPECIFICATIONS OF JETTING PUMP | China brand Flow:170L/min Working pressure:240bar |
||||
| HIGH PRESSURE PIPE | 60M | ||||
| NOZZLES | 10pcs | ||||
| REEL | Automatic return reel | ||||
| 6 | CAB | MODEL | DongFeng Tianjin single cabin with Left hand drive | ||
| SEATS | 3 | ||||
| COLOR | according to you | ||||
| A/C | Equipped | ||||
| OTHERS | With FM RADIO,Spare tire stents and so on | ||||
The sewage suction truck is mainly used for cleaning urban sewers, pipeline sediments, and dredging of dead-angle mud ditches.
It can also be used for cleaning industrial drainage pipes and walls, etc. It can also be used for sprinkling, transporting water and flushing roads, and can be used for fire fighting in emergency.
The sewage suction truck adopts a special sewage suction pump, which has large suction power and long suction range.
It is especially suitable for the suction, shipment and discharge of sludge in the sewer, especially for sucking sewage mud, sludge, stones, bricks, etc. Objects, substances with low water content, etc.
Pumping time for full sewage (feces) tank: s5min, suction range: ≥10m. Self-priming and self-discharging, long life, fast working speed and convenient transportation. The discharge of the sewage suction truck has two methods: pressurized discharge and self-flow discharge.
