Top entry mixing equipment
USD $1000 - $6000
/ Set
1 Set(Min.Order)
- 60 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A
- 60 days
You May Like
Product Details
Brand Name: | Hengfengtai | Place of Origin: | China | Certification: | CE |
After-sales Service Provided: | Engineers available to service machinery overseas | Warranty: | 1 Year | Dimension(L*W*H): | Customized |
Condition: | New | Product Type: | Cosmetic | Voltage: | 120-480V |
Application: | Viscous Fluid | Power(W): | 1.5 kW | Max. Loading Capacity: | 20000L |
Additional Capabilities: | Other, react | Mixer Type: | Agitator |
Product Description
Agitator tank/mixing tank
1, Method: Single layer, insulated or heated structure,volume optional: such as 50L, 100L, 200L, 300L, 500L, 600L, 1000L ~ 10000L or other volumes. 2, optional heating: the use of electric heating rod inserted into the jacket, heating uniform without cold zone. Heat transfer oil or water is injected into the jacket as the heating medium to generate heat energy to heat the materials in the tank. 3, optional heating function, material heating temperature: ≤150℃; Material heating time: 20min ~ 90min(depending on process requirements). 4, optional heating function, temperature control: the electric couple measurement temperature and temperature controller connection to measure and control the temperature (temperature difference ±≤1°C), and can adjust the material temperature level. The temperature controller is installed in the electric control box, and the temperature transmission rod is inserted directly into the bottom of the tank, so that the material liquid can indicate the temperature when it is used in the lowest position. 5, tank body: internal surface mirror polishing treatment, roughness Ra≤0.4μm. 6, top cover: EHA standard oval head can be equipped with atmospheric pressure manhole cover, but also for two open movable cover, easy to clean, internal and external surface mirror polishing treatment (roughness Ra≤0.4μm). 7, the inner tank bottom structure: EHA standard oval bottom head, the bottom is in the center of the sanitary discharge port, can also be made into a conical bottom or diagonal bottom side according to customer needs. 8, optional jacket: If you need heat transfer, you can choose a full jacket, for adding heat transfer oil or water, so that the work to achieve the best heating and cooling purposes. 9, optional insulation materials: If you need heat insulation, you can optionally use filled pearl cotton, rock wool or polyurethane casting foam, to maintain the temperature difference with the outside world, to achieve thermal insulation effect. 10, outer shell surface treatment: mirror polishing or 2B primary color matte or matte finish or overall mirror treatment can be. 11, mixing device: top center mixing, reducer output shaft and mixing paddle shaft using looping or flange connection, easy disassembly and cleaning. 12, optional mixing speed: 15 ~ 120r/min(constant speed); Impeller type: frame type, anchor type, blade type, turbine type, etc. (according to process requirements). Also according to the actual demand by the use of frequency control motor and frequency converter, frequency control can be achieved. 13, equipment configuration: electrical control box, temperature meter, feed and liquid import and export, media import and export (into and out of oil), air outlet (oil spill hole), etc. 14, material: inner tank SUS304 or SUS316L; The jacket is SUS304; The outer protective housing is SUS304. 15, the inlet and outlet of the pipe orifice process and the welding of the inner tank are using flanging process arc transition, smooth and easy to clean without dead corners, beautiful appearance.
