Help CenterBENTLY 3500/91 161204-01 EGD GATEWAY MODULE
Related Products
-
Bently Nevada 3500/22M 138607-01 TRANSIENT DATA INTERFACE MODULENegotiableMOQ: 1 Piece -
Bently Nevada 3500/42M 140734-99 PROXIMITOR SEISMIC MONITORNegotiableMOQ: 1 Piece
-
Bently Nevada 3500/05-02-04-00-00-00 SYSTEM RACKNegotiableMOQ: 1 Piece
-
Bently Nevada 3500/92 136180-01 COMMUNICATION GATEWAY MODULENegotiableMOQ: 1 Piece
-
Bently Nevada 3500/32 125712-01 4-CHANNEL RELAY MODULENegotiableMOQ: 1 Piece
The 3500 system now meets reliability requirements and can use the results of process failure analysis to better determine the required 3500 configuration. Various options include:
1. Standard system
2. Standard system with redundant power supply
3. TMR3500 framework with a single sensor input (TMRI/O: bus system) and a single final stage component.
4. TMR3500 framework with a single sensor input (TMRI/O: bus system) and TMR final stage components.
5. TMR3500 framework with triple sensor inputs (TMRI/O: discrete) and a single final stage component.
6. TMR3500 framework with triple sensor inputs (TMR1/O: discrete) and TMR final stage components.
To operate as a TMR system, the 3500 monitoring system must have the following modules installed:
A TMR type framework interface module
Two power sources (if one is found to be faulty, the other can automatically supply all power without interruption).
Two keyphasor modules in the same slot (if required for keyphasor signals).
● Two TMR relay modules in the same slot (if required)
Three monitoring modules of the same type in adjacent slots.
2-3 communication channel modules in adjacent slots (if required for communication with peripherals).
| 3500/32M 149986-02 | 125720-01 | |
| 3500/33 149986-01 | 149992-01 | |
| 3500/40M 140734-01 | 125680-01 | |
| 3500/40M 176449-01 | 135489-04 | |
| 3500/42M 176449-02 | 128229-01 | |
| 126632-01 | ||
| 3500/44M 140734-03 | 126599-01 | |
| 3500/44M 176449-03 | ||
| 3500/45 176449-04 | ||
| 3500/50 133388-02 | 133442-01 | |
| 3500/53 133388-01 | 133396-01 | |
| 3500/60 163179-01 | 136711-01 | |
| 133819-01 | ||
| 3500/62 163179-03 | 136483-01 | |
| 3500/65 145988-02 | ||
| 3500/92 136180-01 | 136188-01 | |
| 3500/93 135799-01 | ||
| 140471-01 | ||
| 3500/64M 140734-05 | ||
| 3500/91 161204-01 | 161216-01 |
