3500/94M is a VGA Display Module developed by Bently Nevada. It belongs to the 3500 series of components. Up to nine unique screens can be configured using the 3500 Rack Configuration Software. One bar graph panel displays all of the 1X-filtered vibration readings by default, while another displays proximity transducer gap values. Custom screens can be organized into machine train groups. On the custom screen, you may also organize system data into various pages. This VGA module displays information from all machinery protection systems, including:
List of alarm events
List of system events
Data from all modules and channels
Status of the alarm and OK
Nine modes to customize the display
The System is made up of the following components:
VGA module
An input/output module
A touch screen display with a VGA resolution of 10 inches or 15 inches.
Standard cables up to 6 m from a 3500 rack or a supported Keyboard Video Monitor Extender up to 10 km from the 3500 racks can be used to mount the VGA display monitor.
Displays with touch screensUse the Advantech VGA touch screen displays in 10 inches or 15-inch sizes. These tiny, long-lasting screens are ideal for industrial applications that require great viewing quality. The Advantech 10-inch display is approved for use in hazardous settings. A separate power supply is required for each display. Both display drivers are supported by the 3500 Rack Configuration Software.
Keeping the number of displays to a minimumYou can view data from up to four 3500 racks on one display using a normal cable and the optional Display Router Box. In the upper right corner of the VGA display, the alarm and OK status are constantly shown. If any rack connected to the Display Router Box is Not OK or in Alarm status, a rack choose button changes color.
VGA Display Unit SpecificationsInputsMaximum power usage is 4.6 watts.
High-capacity network- Monitor status, values, and data.
RS232 port (I/0)- Data from the touch controller
LED (OK LED): Indicates that the module is working properly.
TX/RX LED: Indicates that other system components are communicating with each other.
(I/O) VGA port: The display receives analog red, green, blue, and sync signals.
Front Port
