Indonesia Paper Cone Machine/automatic Paper Cone Machine

    Trz-2024 automatic production line of paper cone textiles does not require manual control of paper raw materials. The whole production process is controlled by PLC program, and the main transmission mechanism adopts the time mechanism of cam distribution. Each position adopts dual speed variable frequency adjustment technology, and there is a wide range of photoelectric control elements without mechanical wear, Contactless control, pneumatic delay and so on are the complete embodiment of mechatronics. Suitable for different specifications of paper cone tube products.
Process automation
Winding large roll - inside and outside roll - edge cutting - cone winding - drying - semi-finished product collection - V-groove cutting - Press Crimp chapter - winding - finished product
General setting
Power required: 49.2kw
Speed: 48 / min
Equipment size: 14000mm * 6000mm * 3800mm
Service by 1 operator.

1. Reeling part

Trz-2024 paper reeler is a special equipment for manufacturing various tapered sleeves. After rolling up the large paper roll, the cover has internal and external seals, processing edge, cutting, winding cone, cutting concentric reducer, half bag paper The coil will be sent to the drying device using dual speed AC technology. The speed winding will be adjusted automatically. Through the connection with the drying box, the hole process is simple.
General setting
Spool type: different taper, taper diameter
Speed: 48 points
Power required: 49.2kw
External dimension: 6080mm * 2240mm * 1500mm

2. After finishing part

After completing the trz-2024 design, the semi-finished product needs to be converted into a cone-shaped paper tube, and then V-notch, curling, curling head, Back and back.
The speed can be adjusted freely with overload protection, and it can stop automatically in case of abnormal operation, Ensure the stability and safety of work and reduce waste.
Main options:
Taper pipe with different taper
Speed: 48 units / minute
Air pressure: 0.3-0.4 MPa
External dimension: 2600mm * 1600mm * 1580mm

3. Dryer

The automatic control temperature trz-2024 of drying oven adopts the drying cycle circuit. Once the temperature is determined, it can be adjusted freely, with low consumption and high performance. The paper cartridge can be a power supply and automatically assembled to connect to another device.
Main options:
Speed: 48 / min
Efficiency: 10.1-24.5kw
External dimension: 5620mm*1700mm * 3800mm
