Most Advanced Good Service Firecracker Paper Tube Machine

The Trz-2022 paper cone textile automation production line does not require manual control of paper raw materials. The entire production process is controlled by a PLC program, and the main transmission mechanism adopts time allocation. Each workstation of the mechanism adopts dual speed variable frequency regulation technology and has various optoelectronic control components without loss. Contactless control and mechanical delay are the complete embodiment of mechatronics integration. Suitable for automated coiling of paper cone tube products of different specifications - inner coil processing - edge cutting - cone coiling

-Off duty - collection of semi-finished products - V-groove cutting - edge stamping - coiling - completion of routine

set up

Required size power: 49.2kw

Speed: 48/minute

Equipment: 14000mm * 6000mm * 3800mm

One person operation

1. Roll up section

Trz-2022 paper roll machine is a specialized equipment for producing various cone sleeves. After the large paper is rolled up, it is covered with an outer seal, which is used for processing edge banding, cutting, wire cone, and cutting concentric edge banding machines. The half bag paper roll will be dried using a dual speed AC technology drying device. The winding speed will be automatically adjusted. Connected to the drying oven, with simple and universal opening process. Valve core type: different taper, cone diameter signal: 48 points. Power demand: 49.2kw. Overall dimensions:

6080mm

*2240mm * 1500mm

2. After the completion of the trz-2022 design for the rear organizational part, the semi-finished product needs to be transformed into a conical paper tube, and then the V-shaped notch, curling edge, curling head, and back speed rotation can be freely adjusted, with overload protection and automatic stop in case of abnormal operation, ensuring the stability and safety of the working speed, Main options for reducing losses: Tapered pipes with different tapers: 48 units/minute Air pressure: 0.3-0.4 MPa Boundary dimensions: 2600mm * 1600mm * 1580mm

3. Dryer

The automatic temperature control TRZ-2022 of the drying oven adopts a drying cycle circuit. Once the temperature is determined, it can be freely adjusted, with low consumption and high performance. The cardboard box can serve as a power source and automatically connect to other devices. Main options: Speed: 48/

minute

efficiency

10.1-24.5kw

External dimensions: 5620mm * 1700mm * 3800mm
