road race Timing system
The timing system commonly used in road races provided by our company (including software and hardware
equipment, among which the hardware equipment provides rental services). For large-scale competitions such as
marathons, race walking, and road races, using this system can not only save a lot of manpower and material resources,
but also provide more and higher quality services in a short period of time, improve the accuracy of race results, and
make the competition more fair and just.
Hardware Devices
There are three main devices in our system, they are timing readers, timing mats and tags.
1. Time-keeping Reader
The reader has the ability to read many tags (up to 120 tags simultaneously), waterproof design, work around
the clock and withstand a certain degree of external electronic interference.
Power requirements: 12V DC, 3A(gives 4 hours continuous operation).
Physical size: 340*220*440mm, weight: 12KG.
Operating frequencies: 125kHz transmit, 6.8MHz receive.
Read Performance: 0.6m range with 57*43mm STK shoe tag.
Antenna type: can connect two 2.5m*1.2m timing mats.
2. Time-keeping Mat Antenna
The mat antennas are used together with the reader to provide a complete sport time-keeping. When the
antenna picks up the response signal from a tag, the reader records the time and participant's tag number. The
antennas are robust and waterproof, and can be used for timing of running and cycling events. They are hard-wearing
and can even withstand being driven over by motor vehicles.
Power requirements: None.
Physical size: 2.5*1.2m and 5*1.2m
Material: Blue fabric by AKO.
Operating frequencies: 125kHz transmit, 6.8MHz receive.
3. RFID Tag
The RFID tag was designed very portable just like a small card with four holes. And the player could place it
on the shoes, then the reader can pick up signal to get athlete's information conveniently. The tag has long read range,
strong reliability, high tag transmission rate and read rate. At the same time, it can be waterproofed, high temperature
born, UV resistant.
Power requirements: None.
Physical size: 46*57*1.8mm,
weight: 6.3g.
Read range: >0.6m.
Data rate: 128kbit/s.
