triathlon timing system

                                                                                triathlon timing system

             The triathlon timing system is an automatic timing system that combines software and hardware. It works together through multiple systems such as timing software, electronic signaling system, chip timing host, timing chip, endpoint detection coil, competition timing and LED screen display software, endpoint camera timing system, and competition result management server, By adopting high-speed color CCD digital camera and advanced image data processing technology, the equipment's timing accuracy meets the requirements of professional competitions. It has the characteristics of high timing accuracy, fast and accurate interpretation, strong stability, simple operation, easy carrying and installation, and low consumables.

1 Competition timing and LED screen display software

                  Features::

                                              Support simultaneous operation of shooting and grade evaluation.

                                             When the computer crashes and the software restarts, the timer can be restored with just one click.

                                             The output accuracy of the grade is 0.0001 seconds to 1 second, which is optional.

                                             Support multiple commands and reset command timing.

                                             Support zero time calibration function.

                                             Support stopping timing to continue shooting.

                                             Automatic image cropping, filtering out excess images.

                                             Support large screen display of grades and images.

                                             Support automatic score calculation for grades.

                                             Support printing transcripts, generating Excel spreadsheets and txt documents for grades.

                                             Support image association with corresponding groups after selecting the wrong group for the competition.

2 Chip timing host

                Specification:

                                     Chip timing host model: KS-Prochip Decoder

                                     Size: 180x160x45 (mm)

                                     Weight: 720 g

                                     Track width: 2-16 m

                Features:

                                     By connecting the detection coil, the signal from the timing chip can be converted into the ID information of the contestant and the precise time of passing through the detection coil.

3 timing chip

                Specification:

                                     Model: KS-STM100

                                     Order host size: 23 × thirteen point five × 5.5 cm

                                    Weight: 1.5 KG

                                    Speaker size: 31 × twenty-six × 33 cm

                                    Weight: 7 KG

                Features:

                                    Supports wired and wireless audio.

                                    Supports electronic command guns.

                                    The maximum distance for issuing orders is 2000 meters.

                                    Support wireless command button for sending commands.

                                    Supports microphone voice input.

                                   Dual output of voice and firing gun sound.

                                   The host can work continuously for 8 hours without external power.

                                   The sound system can work continuously for 8 hours without external power.

                                   Support zero point calibration of the electric meter.

                                   Support multiple commands and multiple triggers for record storage.

4 Color endpoint camera timing system

                Specification:

                                      Model: KS-PHFC10

                                      Host size: 29.8 × fourteen × 15.6 cm

                                      Weight: 2 KG

                                     Power adapter: 14.8-16.8V/1-2A

                                     Color: Full color image

                 Features:

                                     Supports automatic image exposure processing.

                                     Support positioning athlete sprint images.

                                     Support frontal capture of sprinter chest number fabric.

                                     Support multiple commands and reset command timing.

                                     Support zero time calibration function.

                                     Support stopping timing to continue shooting.

                                     Support local image enlargement function.

                                     Automatic image cropping, filtering out excess images.

                                     Support remote image interpretation, with one computer capturing and one computer interpreting images.

                                     Support thumbnail display and quickly locate athletes.

                                     Support video recording playback.

                                     Supports PNG and BMP image generation.

5 Meet Management Server (OVR)

                 Specification:

                                      Model: KS-MMS-MINI

                                      Size: 260x135x35 (mm)

                                      Weight: 1.0 KG

                  Features:

                                      Easy to create a match, and import the match entry information.

                                      Arrangement the match with variants of game systems. Including

                                      elimination, round-robin, etc.

                                      Provide the match information to the scoring software on each

                                      venue/court.

                                      Gather the real time score and statistics information from the scoring

                                      software. Monitor the progress of the match.

                                      Summary and print integrated report.

                                      Generate standard reports for the match, including start-list, results,

                                      combined results, ranking, etc.

                                      Print certifications with adjustable print templates.

                                      Print the team score report.

                                      Open interface with ODF compatible data feed.

6 Display Board Time

                 Specification:

                                      Model: KS-SPLIT-D

                                      Size: 159×55×54 CM

                                      Weight: 32 KG

                                      Power: 42V / 2A

                                      Waterproof grade: Outdoor waterproof IP65

                 Features:

                                      Multiple interception systems can be used at the same time (through

                                      wireless series connection).

                                      Computer control or wireless key control can be selected.

                                      It can display the timing time or Beijing time.
