49SMD 14.31818mhz ECS-143-20-3X-EN-TR ECS Crystals 14.31818MHz 20pF 50ppm -40C +85C
US$ 0.05 - 0.25
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
ECS
Place of Origin:
China
Model Number:
ECS-143-20-3X-EN-TR
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
7 days
Related Products
-
49SMD 16.9344 ABLSG-16.9344MHZ-D2Y-T ABRACON Crystals CRYSTAL 16.9344MHZ 18PF SMDUS$ 0.04 - 0.45MOQ: 10 Pieces -
ABLS-27.120MHZ-B4-F-T ABRACON Crystals CRYSTAL 27.120MHZ 18PF SMDUS$ 0.04 - 0.25MOQ: 10 Pieces
-
FL3740015 3225 37.4MHZ Diodes Incorporated Crystals 37.400MHz 16pF 15ppm -40 to +85US$ 0.2 - 0.52MOQ: 10 Pieces
-
ABS06-32.768KHZ-9-T ABRACON Crystals 32.768 KHZ +/-20PPM 9.0PFUS$ 0.2 - 0.75MOQ: 1 Piece
-
FC-12M 32.7680KA-AC0 Epson Timing Crystals SMD XTL KHZ +/-20PPM,-40-85C 9PF 1K TRUS$ 0.1 - 0.68MOQ: 1 Piece
Brand Name
ECS
Place of Origin
China
Model Number
ECS-143-20-3X-EN-TR
ECS-143-20-3X-EN-TR
Manufacturer: ECS
Product Category: Crystals
RoHS: Details
Termination Style: SMD/SMT
Package / Case: 7.6 mm x 4.1 mm
Load Capacitance: 20 pF
Frequency: 14.31818 MHz
Tolerance: 30 PPM
Frequency Stability: 50 PPM
ESR: 60 Ohms
Drive Level: 100 uW
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 85 C
Length: 7.6 mm
Width: 4.1 mm
Height: 2.3 mm
Diameter: -
Series: CSM-3X
Packaging: Reel
Packaging: Cut Tape
Packaging: KXXReel
Brand: ECS
Mounting Style: SMD/SMT
Product Type: Crystals
factory pack quantiy: 3000
Subcategory: Crystals
Type: Quartz Crystal
