Good price rose essential oil distiller unit Original and New

Name: Good price rose essential oil distiller unit Original and New
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Good price rose essential oil distiller unit Original and New

Low temperature evaporation under low temperature and vacuum condition. Suitable for extracting essential oils of various plant and animal proteins with alcohol, methane and butane etc.

Product details

Name	Extraction and Evaporation Equipment
Application	various plant and animal proteins with alcohol, methane and butane
Capacity	50L to 5000L
Material	SUS304
Product Keywords	rose essential oil distiller unit

Good price rose essential oil distiller unit Original and New

Main Datas of Ultrasonic Herb Solvent Extraction Equipment

Model	Capacity	Hot water generator power	Material	Heating Area of Extraction Tank	Condensing Area of Condenser	Vacuum pump power
GYS10	10L	6KW	SUS304	0.21M2	0.22 M2	0.55KW
GYS20	20L	8.8KW		0.28 M2	0.5 M2	0.55KW
GYS30	30L	10KW		0.33 M2	0.72 M2	1.5 KW
GYS50	50L	12KW		0.5 M2	0.83 M2	3KW
GYS100	100L	24KW		0.98 M2	0.95 M2	4KW
GYS150	150L	25KW		1.45 M2	1.2 M2	4KW
GYS200	200L	27KW		1.85 M2	1.5 M2	6.5 KW
GYS300	300L	35KW		2.85 M2	2.3 M2	8KW

Remark: capacity (10L ,20L,50L ,100L ,500L,1000L,1500L,2000L,3000L,4000L,5000L and more) available according to requirements.We have rich experience and can also design and manufacturing according to your demand.

***

We also have extraction and vacuum concertration machine

(solvent extraction technology,it include Alcohol, butane, n-hexane,Fluid co2 etc),can get more essential oil from plant or animal dry powder.

The essnetial oil output rate can get 20~30%!

Parameters of Ultrasonic Herb Solvent Extraction Equipment

Ultrasonic generator: 28 KHZ ,55 KHZ).
Filter material: stainless steel material basket,stainless steel filter.
Ultrasonic control: digital ultrasonic control
The extracting tank heating area: 0.25 M2
Ultrasonic timer: digital
Heating timer: digital
Interlayer water pressure: the atmospheric pressure
Water extraction temperature: room temperature to 95 degrees,adjustable
Alcohol extraction temperature: room temperature to 73 degrees,adjustable
Power supply: single 50 HZ, 220 V
Extraction tank volume: 20L (Three layers of insulation hot water heating system.)
Extraction tank inside the water cycle: small heat pumps.
Material: the whole machine all adopt high quality food grade SUS304 2B, suitable for weak acid,
weak alkali cleaning equipment
The equipment surface treatment: mirror polishing tank surface, outer surface drawing inferior smooth processing.
Device size: 450*250*550 (length * width * height,can be customized according to customer's requirement

We are factory and good at essential oil extracting plant and machines,design and manufacturing.welcome your inquiry!
