canned fruit vegetable processing line

Canned fruit vegetable processing line

It is customized line based on raw material, processing capacity and way of packing.

1.Raw mateial → 2.Core removing →3.Turnover→4.Soda water spraying→5.Peeling and washing→ 6.Pre-cooking

→ 7.Cooling → 8.Sorting → 9.Hair removing→10.Slicing →11.Fruit filling(←Botte washing←Cans unloading)

→12.Syrup filling→13.Exhauster→14.Vacuum sealing→15.Canned fruit→16.Sterilization→17.Drying

→18.Cans Palletizer→19.Storage→20.Labeling→21.Final product→22.Case packing→23.Case Palletizer→24.Shipping.

Item	Name	Product Description
2	Digging nuclear	Through the high-speed rotation twist open peach to achieve digging nuclear.
3	Turnover	Roll the peach, make it skin up one side up.
4	Soda water spraying	To the peach skin side sprinkled with soda.
5	Peeler and cleaner	Remove the peach skin and wash it.
6	Pre-cooked	Cook peaches
7	Cooling	Cool and clean peaches
8	Pick	Pick peaches, sort the size level.
9	Remove hair	Remove the hair that may fall in the fruit.
10	Slicer	Cut the peaches into strips.
11	Filling	Pour the peach into the can bottle.
↑	Botte washing	Wash the glass can bottle.
↑	Depalletizer	Unload the glass bottle onto the assembly line.
12	Pouring juice	Add sugar water to the cans.
13	Exhauster	Drain the inside air of the fruit in the can.
14	Sealing	Capping on the can,Sealing can.
16	Sterilization	To the canned water bath sterilization.
17	Dryer	Dry the cans outside.
18	Cans Palletizer	Palletizer fruit cans.
20	Labeler	Fruit canned Labeler.
22	Case packer	Put the fruit cans in the box.
23	Case Palletizer	The cartons are palletized.
