Product Description
5000-6000pcs per hour ice cream popsicles production line
Product Detail
| Product Keywords | con ice cream machine |
Quality assurance:
Full Automatic Ice Cream Processing Line
The whole milk production line consists of the following systems:
1. Water treatment system
2. Suger melt system
3. Sterilizer system
4. Filling and packing system
5. CIP cleaning system
6. After treatment equipments, like conveyor, package or pallet, etc.
7. There are other assistant equipments used such as steam boilers, air compressor, cold water unit, etc.
8. Installation materials for the process pipline, utility pipeline as well as electrical installation are provided.
Filling and packing types can be decided by the customer then designed accordingly.
Our company can design customized milk production lines in accordance to the customers' requirements. The production capacity varies from 200L/h to 10000L/h according to customer's need
Note: this milk production lines can be widely used to produce UHT milk, pasteurized milk, setted milk, stirred milk, milk drink, yogurt, ice cream, condensed milk and milk powder, and so on.
|
MILK RECEIVESTORAGEAND CREAM SEPARETOR UNIT |
|
|
electron pound scale |
maximum weighing 500KG |
|
milk weighing tank |
made of SUS stainless steal,single layer,product feeded in through 40 mesh filter net,CIP cleaning ball |
|
milk acceptor |
SUS304 stainless steel,single layer,CIP cleaning ball |
|
milk pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
|
twin piping filter |
SUS304 stainless steel,two pipe,Stainless Steal Filter Element 100 Mesh |
|
dish separator |
auto residue discharge |
|
chiling tank |
SUS304 stainless steel,alveolate jacket,attached with compressor |
|
milk pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
|
PREPARING UNIT |
|
|
blending tank |
SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet |
|
milk pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
|
mini set of plate-type heat exchanger |
SUS304 stainless steel,two stages, |
|
high speed emulsification tank |
SUS304 stainless steel,heat insulated,bottom high speed emulsifier,digital readout thermometer,supporters with adjustable feet |
|
milk pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
|
twin piping filter |
SUS304 stainless steel,two pipe,Stainless Steal Filter Element 100 Mesh |
|
sterilizing,homogenizing unit |
|
|
UHT sterilizer |
tub-type,sterilzing temperature 137 C,holding time 4S,full automatic control |
|
high pressure homogenizer |
40MPa,(starting box included) |
|
temperature holding |
SUS304,holding 300S |
|
distributing plate |
SUS304,3 holes |
|
cheesebutter processing unit |
|
|
bufferying tank |
SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet |
|
milk pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
|
cream seperator |
|
|
bufferying container |
SUS304,with cover |
|
milk pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
|
butter-churner |
SUS304,stepless timing |
|
cheese vat |
SUS304,with heating jacket and insising device |
|
pressor |
SUS304,6 heads |
|
mould |
SUS304,10L,with cover |
|
yogurt fermentation unit |
|
|
fermentation tank |
SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet |
|
rotary pump |
SUS304 stainless steel,Hard Alloy Mechanical Seal,manual stepless shift |
|
plate cooler |
SUS304,single stage,milk discharge at 4C |
|
rotary pump |
SUS304 stainless steel,Hard Alloy Mechanical Seal,manual stepless shift |
|
filling unit |
|
|
higher position tank |
SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet |
|
pasteurized milk filling machine |
|
|
yogurt filling machine |
|
|
CIP system |
|
|
semi-auto CIP system |
outer coat of SUS304 stainless steel material,inner shell of SUS316,single cleaning way,Concentrated acid/alcali tank adding system based on US technology, 100L×2 acid/alcali Concentrate tanks |
|
CIP return pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
|
installation part |
whole milk processing line installation and commissioning |
as the manufacture,ice-Cream Processing Line are products of a new generation which,by majorization,continuously accomplish mixing material,disinfection,even quality,cooling,aging,congealment,filling and hardening.
so our poduction line can realize the changes of many varieties only by replacing its feeding head.It can produce cup ice cream, stick ice cream,chocolate-coated ice cream,kernel ice cream and ice sucker, milk popsicle ect.
About us
PACKAGE:
Standard export carton packing.
DELIVERY TIME:
3-40 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
