Machine Description
Hot air circulation drying oven uses alow noise and high temperature proof axial flow blower and an antomatic temperature control system.The whole circulation system is the fully enclosed to make that the heat efficiency of the drying oven increases from 3-7% of the traditional drying oven to 35%-45% of the present one.The highest heat efficiency can reach 50%.The successful design of hot air circulation drying oven makes that the hot air circulation drying oven in our country catch the advanced level both at home and abroad.In order to save a large quantity of the energy in our country,enhance the economic results of the enterprises.
Machine Features
1.Most of hot air is cricled inside the oven.The hot eiffciency is high,the energy source can be saved.
2.It uses enhanced ventilation and equips with adjustable air divider plate inside the oven,raw material can be dry evenly,the hot source can be steam,hot water,electricity or far infrared.
3.The machine has low noise and stable operation,the temperature can be controlled automatically,the installationn and maintenance are very convenient.
4.The applied fields are wide and can be suitable for all kinds of raw materials.It is a comprehensive drier.
Technical Patameters
| Type | Drying capacity/batch | Power | Steam to be consumed | Heat radiation area | Air capacity | Temperature difference | Tray | Dimensiom(mm) | Trolly |
| RXH-5-C | 25kg | 0.45kw | 5kg/h | 5 m2 | 3450 m3/h | 0℃ | 16pcs | 1480*1100*1750 | 0set |
| RXH-7-C | 50kg | 0.45kw | 10kg/h | 10 m2 | 3450 m3/h | ±2 ℃ | 24pcs | 1400*1200*2000 | 1set |
| RXH-14-C | 120kg | 0.45kw | 18 kg/h | 20 m2 | 3450 m3/h | ±2 ℃ | 48pcs | 2300*1200*2000 | 2set |
| RXH-27-C | 240kg | 0.9kw | 36 kg/h | 40 m2 | 6900 m3/h | ±2 ℃ | 48pcs | 2300*2200*2000 | 4set |
| RXH-27A-C | 240kg | 0.9kw | 36 kg/h | 40 m2 | 6900 m3/h | ±2 ℃ | 96pcs | 4460*1200*2290 | 4set |
| RXH-41-C | 360kg | 1.35kw | 54 kg/h | 80 m2 | 10350 m3/h | ±2 ℃ | 144 pcs | 2300*3220*2000 | 6set |
| RXH-42A-C | 360kg | 1.35kw | 54 kg/h | 80 m2 | 10350 m3/h | ±2 ℃ | 144 pcs | 3430*2200*2000 | 6set |
| RXH-54-C | 480kg | 1.8kw | 72 kg/h | 100 m2 | 13800 m3/h | ±2 ℃ | 192 pcs | 4460*2200*2290 | 8set |
| RXH-25-C | High effect and high temperature far infrared sterilization oven | 1200*1000*1600 | 1set | ||||||
