Freeze Dryer for Food / Freeze Dried Rose Petals / Lyophilized Durian Machine
- T/T Credit Card
You May Like
-
Food Freeze Dryer / Freeze Dried Rose Petals / Lyophilized Royal Jelly Powder Machine
-
Lyophilizer for Food Freeze Vacuum Drying Processing
-
High Frequency Vacuum Timber Kiln /microwave Dryer
-
High Frequency Heating And Vacuum Drying Working Principle Spinach Microwave Dryer
-
Fast Drying And Sizing Microwave Drying Machine for Drying Kraft Paper
-
960kg per Day Air Circulation Drying Oven
Product Description
FD FOOD is it with fresh fruits and vegetables as the main raw material, edible vegetable oil as a heat medium, the use of low-temperature vacuum frying (FD FOOD) and other advanced technology, in a very short period of rapid dehydration, get moisture low fruit and vegetable food, low oil content, crisp and not greasy, preserved fruits and vegetables original shape, color, smell, taste, and rich in nutrients vitamins, minerals, fiber, etc., with sugar, salt, low-fat, low heat and other features.
FD FOOD applicable scope
1, fruits: such as apples, bananas, kiwi, pineapple, jujube, strawberries, pineapple, etc.
2,Vegetables: such as carrots, turnips, sweet potatoes, squash, garlic, onion, mushroom, melon, okra, etc.
3, meat categories: such as beef, fish, shrimp, octopus and so on.
Vacuum frying process
Raw materials→screening→ washing→slicing (cut)→fixation (color guard)→de water→freeze Drying→packing
Working principle of vacuum freeze dryer
Instead of traditional vaporization dehydration method, the vacuum freeze drying technology is dehydrate products by sublimation directly from ice to vapor. During the Freeze drying process, the materials will be frozen to -18°c, then move into the vacuum drying tank for dehydration, automatic control system will set the vacuum and heating temperature according to the freeze drying cirve of each products to maintain the proper circumstances for FD processing. The materials stay in frozen status during the drying process and water vapor will be condensed on the surface of cold trap coils to absort the water out from the materials.
Application
The vacuum freezing and drying machine can be widely used in various fields, such as vegetables, fruits, condiments, seafood, biological products, medicine, beverage, specimen, etc.
Parameter
|
Parameters |
Model |
FDGY-0.5 |
FDGY-10 |
FDGY-20 |
FDGY-50 |
FDGY-100 |
FDGY-150 |
FDGY-200 |
FDGY-280 |
|
Drying area (m2) |
0.5 |
10 |
20 |
50 |
100 |
150 |
200 |
275 |
|
|
Mean dehydrating amount (kg/h) |
0.6 |
12 |
20 |
50 |
100 |
150 |
200 |
275 |
|
|
Size of material tray (m) |
310×540×30 |
745×635×30 |
435×555×30 |
540×635×30 |
|||||
|
Number of material tray (pcs) |
3 |
21 |
80 |
144 |
288 |
480 |
576 |
792 |
|
|
Size of pot (M) |
1.5×1.6×1.6 |
φ1.4×2.1 |
φ1.8×2.4 |
φ2.4×4.8 |
φ2.4×8.9 |
φ2.4×12.8 |
φ2.4×16.6 |
φ2.4×21.9 |
|
|
Operation vacuum (pa) |
13.3~200 |
26.6~200 |
|||||||
|
Heating plate T (°C) |
Normal temperature~+120°C |
||||||||
|
Electric heating (Kw) |
2 |
21 |
40 |
|
|
|
|
|
|
|
Steam consumption (Kg/h 0.7Mpa) |
|
|
|
140 |
270 |
450 |
540 |
750 |
|
|
Cold load consumption (Kw) |
1.5 |
21.6 |
36 |
90 |
180 |
280 |
360 |
490 |
|
|
Installed power (Kw) |
6.5 |
55.8 |
104.5 |
41.2 |
69.7 |
92.5 |
117.5 |
125.5 |
|
